BY
LC36
LIBRARY CARREL
IM P O RTA N T !
Assembly may require the assistance of
another person.
Before you begin assembly:
READ THE DIRECTIONS all the way through one
time. This will speed up the process and help you
understand the sequence of steps.
COUNT THE PARTS AND HARDWARE before
assembly. This ensures you have received all
necessary parts before you begin.
TOOLS: You may need a Phillips head screwdriver,
a medium slotted screwdriver or a plastic mallet. To
protect your new furniture from damage during
assembly, it is recommended to work on a carpeted
surface.
0920
In the event any parts are missing from
this package, send your name, address,
telephone number, and a description of
the missing part(s) to: PARTS, Box 1420,
Missoula, MT 59806 or call:
1-800-769-5693 or FAX 1-800-445-5281.
CAUTION: On assemblies requiring glue, make
sure the unit is assembled correctly before gluing.
Once this unit is assembled with glue, the
manufacturer will not be responsible for damaged
parts. Keep a damp cloth or sponge handy to wipe
off excess glue.
To care for this furniture, simply wipe with a cloth
dampened with glass cleaner containing ammonia-D.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Glacier LC36 and is the answer not in the manual?

Questions and answers

Summary of Contents for Ironwood Glacier LC36

  • Page 1 LC36 LIBRARY CARREL IM P O RTA N T ! In the event any parts are missing from Assembly may require the assistance of this package, send your name, address, another person. telephone number, and a description of Before you begin assembly: the missing part(s) to: PARTS, Box 1420, Missoula, MT 59806 or call: READ THE DIRECTIONS all the way through one...
  • Page 2 PARTS DIAGRAM Left Side 01012941 1 ea. Right Side 01012941 1 ea. 01012901 1 ea. Back 01012952 1 ea. Shelf 01012921 1 ea.
  • Page 3 HARDWARE Flush Rafix 909911 8 ea. Rafix Cam 909909 12 ea. Leveler Insert 274650 4 ea. Leveler Bracket 402302 4 ea. Leveler 300870 4 ea. Rafix Bolt 909925 20 ea. Wire Trough 412990 1 ea. 6 X .625 901216 2 ea. Panhead Screw Grommet 286580...
  • Page 4 Using the Rafix System: Insert the Rafix Cams into the appropriate holes. The flat edge of the cam should be facing the edge Flat of the panel. edges must be Slide Rafix Cams of the panel to be aligned attached onto the corresponding posts. When screwing post into hole, Do Not over tighten.
  • Page 5 Place the Back (D) onto a clean, carpeted surface with the pre-drilled holes facing up. Insert eight Flush Rafix Cams (H1) into the Back. Insert two Rafix Bolts (H8) into the predrilled holes at the top of the Back where indicated. Choose your desired height for the Top (C) Panel and screw two Rafix Cams (H8) into the predrilled holes on the Back (D).
  • Page 6 Install Leveler Inserts (H3) into the bottom holes of the Left Side (A) and Right Side (B) and tap until flush with the surface. Press a Leveler Bracket (H4) over each Leveler Insert. Screw the Levelers (H5) into the Leveler Inserts.
  • Page 7 With the help of an assistant, position the Left Side (A) with the front and top edge as shown. Now position the Back (D) with the Top edge as shown onto the bolts. Tighten cams to secure. Position the Right Side (B) onto the unit and tighten cams to secure.
  • Page 8 Peel the paper backing from the adhesive strip on the Wire Trough (H9). Attach the Wire Trough to the Back of the unit and secure in place by driving two Panhead Screws (H10) through the predrilled holes in the Wire Trough.
