Owners &
Installation
LISTINGS AND CODE APPROVALS
These gas appliances have been tested
in accordance with AS4553-2000, NZS
5262 and have been certified by the
Australian Gas Association for installa-
tion and operation as described in these
Installation and Operating Instructions.
Your unit should be serviced annu-
ally by an authorised service person.
Freestanding Gas Stove
PLEASE KEEP THESE INSTRUCTIONS
FOR FUTURE REFERENCE
WARNING:
Improper installation, adjustment, altera-
tion, service or maintenance can cause
injury or property damage. Refer to this
manual. For assistance or additional in-
formation consult an authorized installer,
service agency or the gas supplier.
FOR YOUR SAFETY
Do not store or use gasoline or other flam-
mable vapours and liquids in the vicinity of
this or any other appliance.
Installation and service must be performed
by an authorized installer, service agency or
the gas supplier.
918-318b
Models: FG37-NG
FG37-LPG
FOR YOUR SAFETY
What to do if you smell gas:
Do not try to light any appli-
ance
Do not touch any electri-
cal switch: do not use any
phone in your building.
Immediately call your gas
supplier from a neighbour's
phone. Follow the gas sup-
plier's instructions.
If you cannot reach your
gas supplier, call the fire
department.
01/02/14

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the FireGenie FG37-NG and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Regency FireGenie FG37-NG

  • Page 1 Owners & Installation Freestanding Gas Stove Models: FG37-NG FG37-LPG PLEASE KEEP THESE INSTRUCTIONS FOR FUTURE REFERENCE WARNING: FOR YOUR SAFETY Improper installation, adjustment, altera- What to do if you smell gas: tion, service or maintenance can cause Do not try to light any appli- injury or property damage.
  • Page 2: Specifications Diagram

    Please take a moment now to acquaint yourself with these instructions and the many features of your Regency Rear Flued Room Sealed Freestanding Gas Stove.
  • Page 3: Table Of Contents

    Gas Pipe Pressure Testing ........17 Valve Description ............17 Warranty Louvre Installation ............. 17 Optional Remote Control Installation ......18 Warranty ..............31 Final Check..............18 Wiring Diagram ............18 FG37 Regency Rear Flued Room Sealed Freestanding Gas Heater...
  • Page 4: Data Plate

    Check the label on the unit and if Freestanding Gas Stove. We have printed a down pedestal door. there is a difference, the label on the unit is the correct one. (Australia Only) FG37 Regency Rear Flued Room Sealed Freestanding Gas Heater...
  • Page 5: Installation

    Make it a practice to have all of your gas It may be installed in a recessed position, appliances checked annually. framed out into the room, or across a corner. 13) Do not slam shut or strike the glass door. FG37 Regency Rear Flued Room Sealed Freestanding Gas Heater...
  • Page 6: Installation Checklist

    114 mm FG37-NG & FG37-LPG Reference Dimensions C Floor to Flue Centerline 635 mm D Side Wall to Flue Centerline 521 mm Minimum ceiling height is 914 mm from top of unit. FG37 Regency Rear Flued Room Sealed Freestanding Gas Heater...
  • Page 7: Exterior Flue Terminal Locations

    (IV) A flue terminal of this type shall not be located under a roofed area unless the roofed area is fully open on at least two sides and a free flow of air at the appliance is achieved. FG37 Regency Rear Flued Room Sealed Freestanding Gas Heater...
  • Page 8: Fluing Installation Precautions

    *If this is an outside corner, the minimum distance both dimensions must be met. For corner installation, Restrictor must For straight rear installation, Restrictor be set at 1-1/4" (32mm) open. must be set at 1-1/8" (29mm) open. FG37 Regency Rear Flued Room Sealed Freestanding Gas Heater...
  • Page 9: Fluing Arrangements - Vertical Terminations

    Tighten the screws. Vent Restrictor Vent Restrictor Vent Vent (fully open) Restrictor Restrictor Plate Plate FG37 Regency Rear Flued Room Sealed Freestanding Gas Heater...
  • Page 10: Fluing: Residential And Manufactured

    MOBILE HOMES INSTALLATIONS You will require the following components with your new Regency Rear Flued Room Sealed Freestanding Gas Stove. Please review your product to make sure you have everything you need. In the event that you are missing any part, contact your dealer.
  • Page 11: Horizontal Installations

    The four wood screws provided should be replaced with appropriate fasteners for stucco, brick, concrete, or other types of sidings. Dia. 3. 5) If installing termination on a siding Diagram 4 FG37 Regency Rear Flued Room Sealed Freestanding Gas Heater...
  • Page 12: Vertical Termination With Co-Linear Flex System

    System Data - FG37 with flashing Burner Inlet Orifice Sizes: Max. Input Rating 31.7 mj Min. Input Rating 16 mj Supply Pressure min. 1.13 kPa min. 2.75 kPa Manifold Pressure .89 kPa 2.55 kPa FG37 Regency Rear Flued Room Sealed Freestanding Gas Heater...
  • Page 13: Conversion From Ng To Lpg

    15) Carefully pull out the control box. Pilot Tube Note: The control box is held in place by velcro. 16) Remove the control box cover by undoing the 3 screws. Maneuver through antenna. FG37 Regency Rear Flued Room Sealed Freestanding Gas Heater...
  • Page 14 Put back the modulator plastic cap. WARNING: To ensure the correct operation of the modulator it is necessary that the plastic cap (A) is returned to its original location. FG37 Regency Rear Flued Room Sealed Freestanding Gas Heater...
  • Page 15: Aeration Adjustment

    Caution: Carbon will be produced if the air shutter is closed too much. Note: Any damage due to carboning result- ing from improperly setting the aera- tion controls is NOT covered under Embers Embers warranty. FG37 Regency Rear Flued Room Sealed Freestanding Gas Heater...
  • Page 16: Door Installation

    If they are too hard or too easy to close, you may want to adjust them by loosening the locking nut and turning the E)02-45 latch catch. See diagram 3. Notch Cutout Diagram 3 FG37 Regency Rear Flued Room Sealed Freestanding Gas Heater...
  • Page 17: Gas Pipe Pressure Testing

    6) When finished reading manometer, turn off the gas valve, disconnect the hose and tighten the screw (clockwise) with a 1/8" flat screwdriver. Note: Screw should be snug, but do not over tighten FG37 Regency Rear Flued Room Sealed Freestanding Gas Heater...
  • Page 18: Optional Remote Control Installation

    This appliance is equipped with a three pronged (grounding) plug for your protection against shock hazard and should be plugged directly into a properly grounded three-prong receptacle. Do not cut or remove the grounding prong from this plug. FG37 Regency Rear Flued Room Sealed Freestanding Gas Heater...
  • Page 19: Operating Instructions

    Never operate the appliance with any of the glass removed or with the door open. 5) Verify that all flueing and the cap is unob- structed. 6) Verify log placement. FG37 Regency Rear Flued Room Sealed Freestanding Gas Heater...
  • Page 20: Normal Operating Sounds Of Gas Appliances

    Rear of Burner Different types and thicknesses of steel will expand and contract at different rates resulting in some "cracking" and "ticking" sounds will be heard throughout the cycling process. Front of Burner FG37 Regency Rear Flued Room Sealed Freestanding Gas Heater...
  • Page 21: Copy Of Lighting Plate Instructions

    Feb. 8/06: Changed AG 601 to AS5601-2004 as per Paul Watters. WARNING: DO NOT SPRAY AEROSOLS IN THE VICINITY OF Apr. 19/18: Changed to AS/NZS 5601 as per R/D THIS APPLIANCE WHILE IN OPERATION. FG37 Regency Rear Flued Room Sealed Freestanding Gas Heater...
  • Page 22: Maintenance

    5) Keep the area near the appliance clear and free from combustible materials, gasoline and other flammable vapours and liquids. 6) Verify proper operation after servicing FG37 Regency Rear Flued Room Sealed Freestanding Gas Heater...
  • Page 23: Latch Adjustment

    & bottom inside corners (2) 1) Remove the door from the unit and place on a soft surface to prevent scratching. 8) Tighten the 10 nuts on center glass retainer. FG37 Regency Rear Flued Room Sealed Freestanding Gas Heater...
  • Page 24: Fan Maintenance

    Reverse the above steps (1 - 4). Make sure the 3) Unclip the wires from the fan motor. 4) Lift fan off of the 2 pins, tip back and pull FG37 Regency Rear Flued Room Sealed Freestanding Gas Heater...
  • Page 25: Removing Valve

    See diagram below. 13) To replace the burner tray assembly, reverse these instructions. 6) Disconnect the manual switch cable and reset cables. Manual Switch Reset Cables Cable FG37 Regency Rear Flued Room Sealed Freestanding Gas Heater...
  • Page 26: Parts List

      *Note: The Control Box Cable wires for the FG38 come separately: 910-502, 910-505, 910-506, 910-507, 910-509 The Control Box Cable wires for the IG35 come separately: 910-530, 910-504, 910-528 FG37 Regency Rear Flued Room Sealed Freestanding Gas Heater...
  • Page 27: Replacement Parts List

    Side Panel Door Assy (Left Side) 21) 560-031 Side Panel Door Hinge 23) 904-258 Side Panel Door Magnet 24) 948-255 Door Latch - c/w J-Hook 25) * Flex Pipe (3" ID) FG37 Regency Rear Flued Room Sealed Freestanding Gas Heater...
  • Page 28 Pilot Assembly Gasket Front Right Log 730-528 Log Stand Front Left Log 904-390 Pilot Orifice #52 - NG 732-930 Log Set *Not available as a replacement part. 730-550 Burner Assy - NG/LP FG37 Regency Rear Flued Room Sealed Freestanding Gas Heater...
  • Page 29 940-323/P Side Glass 107) 936-243 Glass Gasket 108) 940-322/P Centre Glass 111) Door Frame Fibre Paper 112) 750-015 Door Glass Extrusion 208) 940-325/P Wrap Glass *Not available as a replacement part. FG37 Regency Rear Flued Room Sealed Freestanding Gas Heater...
  • Page 30 NOTES FG37 Regency Rear Flued Room Sealed Freestanding Gas Heater...
  • Page 31: Warranty

    Regency codes. Also, all service work must be carried out by an Fireplace Products.
  • Page 32 Register your Regency warranty online ® www.regency-fire.com.au Reasons to register your product online today! • View and modify a list of all your registered products. • Request automatic email notification of new product updates. • Stay informed about the current promotions, events, and special offers on related products.
