Summary of Contents for InfiRay Tianshu C Series
- Page 1 Tianshu C Series Handheld Thermal Camera User Manual V1.0.1 IRay Technology CO., Ltd. www.iraytek.com...
- Page 2 C Series Handheld Thermal Camera ·User Manual ©2020 IRAY TECHNOLOGY CO., LTD. All right reserved worldwide. All contents in this manual, including words, pictures, images, etc., belong to IRAY TECHNOLOGY CO., LTD. (Hereinafter referred to as “THE COMPANY” or “IRAY TECHNOLOGY”). No part of the manual, in whole or in parts, may be copied, photocopied, translated, or transmitted without the prior written permission of IRAY TECHNOLOGY.
-
Page 3: Table Of Contents
C Series Handheld Thermal Camera ·User Manual Table of Contents 1. User Notice ......................... 1 1.1 Calibration ......................1 1.2 Manual Update ....................1 1.3 Scope of Application ................... 1 2. Quick Start Guide ..................... 1 3. Camera Introduction ....................2 3.1 Camera ........................ - Page 4 C Series Handheld Thermal Camera ·User Manual 5.1.2 Setting Ambient Temperature ..............10 5.1.3 Setting Distance ..................11 5.2 Temperature Unit ....................11 5.3 High/Low Temperature Alarm ................11 5.4 Photo-taking Settings ..................12 5.4.1 Automatically Save Photos ..............12 5.4.2 Timed Photo .....................
-
Page 5: User Notice
C Series Handheld Thermal Camera ·User Manual 1. User Notice 1.1 Calibration Annual calibration to the thermal camera is recommended. 1.2 Manual Update Our user manual will be updated from time to time. Please contact us to get the latest version of the manual. 1.3 Scope of Application This manual is applicable to all products in C series, which means that some contents in this manual may not be applicable to a specific model. -
Page 6: Camera Introduction
C Series Handheld Thermal Camera ·User Manual 3. Camera Introduction 3.1 Camera Components： 1. Digital Camera 2. Infrared Lens 3. LED 4. Trigger 3.2 Buttons... -
Page 7: Connector & Memory Card
C Series Handheld Thermal Camera ·User Manual Components： 1. Screen 2. View Memory button：Press to View Saved Pictures. 3. Navigation button ⚫ Press up/down/left/right button to move the cursor to navigate between Menu, Settings, Albums； ⚫ Press the Center Button(Also called Confirm Button) to select. 4. -
Page 8: User Interface
C Series Handheld Thermal Camera ·User Manual 3.4 User Interface Interface Introduction: 1. Main toolbar: measurement mode, image mode, color palette and settings can be set. 2. Secondary toolbar: detailed options can be set here, such as selecting color palette. 3. -
Page 9: Operating Instructions
C Series Handheld Thermal Camera ·User Manual 4. Operating Instructions 4.1 Power On & Off 1. In the shutdown status, long press the power button to power on. 2. In the power-on status, long press the power button to power off. 3. -
Page 10: Cold/Hot Spot Tracing
C Series Handheld Thermal Camera ·User Manual 2. Select the measurement icon on the toolbar，and press the center button to bring up the secondary toolbar 3. Select “Center Point” icon on the secondary menu, and press the center button to enable the Center point temperature measurement(on by default), the temperature of the center point will be displayed in the upper left corner of the screen 4.5 Cold/Hot Spot Tracing... -
Page 11: Imaging Modes
C Series Handheld Thermal Camera ·User Manual 4.7 Imaging Modes 4.7.1 Imaging Mode Introduction ⚫ Thermal image：Infrared images only ⚫ Fusion：Fusion of infrared image and visual image in a certain scale. In the main interface, you can use the left and right navigation keys to adjust the fusion ratio of infrared and visible light. -
Page 12: Steps Of Changing Image Modes
C Series Handheld Thermal Camera ·User Manual ⚫ Digital Camera：Visual camera image only Note: In order to achieve better overlay image effect, when using the picture in picture, and thermal fusion modes, you need to set the alignment distance, which is the approximate distance from the thermal camera to the target. In picture in picture / thermal fusion / digital camera mode, please make sure that the thermal image displayed on the screen is aligned with the target. -
Page 13: Color Palette
C Series Handheld Thermal Camera ·User Manual 3. Select the image mode you need on the secondary toolbar and press the confirm button to switch into the selected image mode. 4.8 Color Palette You can change the color palette to distinguish temperature difference on the thermal camera. -
Page 14: Settings
C Series Handheld Thermal Camera ·User Manual 5. Settings 5.1 Measurement Parameters 5.1.1 Setting Emissivity In order to get more accurate measurement results, you need to set the emissivity according to the target to be measured before each measurement, instead of using the default configuration. Emissivity refers to the ratio of the radiation ability of an object to that of a blackbody at the same temperature, which is relative to the reflectivity of the object. -
Page 15: Setting Distance
C Series Handheld Thermal Camera ·User Manual 5.1.3 Setting Distance Different distances will have different effects on the measurement results. For accurate temperature measurement, the distance information of the object is necessary for compensating for the result. 1. In the thermal imaging interface, click the OK button, and the main menu toolbar will be displayed. -
Page 16: Photo-Taking Settings
C Series Handheld Thermal Camera ·User Manual 5.4 Photo-taking Settings 5.4.1 Automatically Save Photos Turn on this function, the picture will be automatically saved after taking a picture. 5.4.2 Timed Photo The camera supports the function of taking pictures at regular intervals, and users can independently set the time interval and number of pictures taken. -
Page 17: Structural Drawing
C Series Handheld Thermal Camera ·User Manual 6. Structural Drawing... -
Page 18: Precautions
C Series Handheld Thermal Camera ·User Manual 7. Precautions To protect you and others from injury or damage to your device, please read all of the following information before using your device. 1. Do not point the lens directly to the sun or other high-intensity radiation sources. -
Page 19: Company Information
C Series Handheld Thermal Camera ·User Manual 9. Company Information IRay Technology Co., Ltd. Website：www.iraytek.com Phone：86-0535-3410623 FAX：86-0535-3410610 E-mail：sales@iraytek.com Address：11th Guiyang Street, YEDA, Yantai 264006, P.R.China...
