- Page 1 AT300 / AT600 Series Precise Body Temperature Measurement Thermal Camera Quick Start Guide V1.0.3 IRay Technology Co., Ltd.
- Page 2 Precise Body Temperature Measurement Thermal Camera ©IRay Technology Co., Ltd. 2018 Reserve all the right. All in this manual including texts, pictures, diagrams and other contents belong to IRay Technology Co.,Ltd (Hereinafter referred to as “Our company”or “IRay Photoelectric”). Without the written permission, no one shall copy, photocopy, translate or disseminate all or part of this manual.
-
Page 3: Table Of Contents
Precise Body Temperature Measurement Thermal Camera Contents 1. Overview ......................- 3 - 2. Product Performance ................... - 4 - 3. Installation Guide ....................- 6 - 3.1 Product and Accessories List ........................- 6 - 3.2 Mounting and Connecting Thermal Camera .................... - 7 - 3.3 Introduction of Reference Blackbody ..................... -
Page 4: Overview
Precise Body Temperature Measurement Thermal Camera 1. Overview AT300 / 600 accurate temperature measurement thermal camera can be widely used in medical temperature measurement, body temperature screening, animal husbandry, machine vision, high-precision power detection, high-precision industrial detection and other industries. It can realize real-time temperature information transmission, accurate detection, fast screening and so on. -
Page 5: Product Performance
Precise Body Temperature Measurement Thermal Camera 2. Product Performance Table 1 Product performance parameter Model AT3003F AT6005F Performance Detector type VOx Uncooled Infrared FPA Detector Resolution 384×288 640×512 Lens Model Focal Distance 7.8mm 15mm Lens control Support auto focus Focus Type Athermal Athermal FOV(Horizon×Vertical) - Page 6 Precise Body Temperature Measurement Thermal Camera TCP、UDP、ICMP、IGMP、DHCP、RTSP Network Protocol Image Adjustment Brightness and contrast adjustment Manual / Auto 0 (default) / Auto 1 Polarity Black hot/White hot Palette 18 modes are supportable Image flip Left -right / up-down / diagonal Power Supply Supply voltage 10-36VDC...
-
Page 7: Installation Guide
Precise Body Temperature Measurement Thermal Camera 3. Installation Guide 3.1 Product and Accessory List Before installation, please make sure that the equipment in the package is intact and all parts are available. Standard packaging list Network cable ×1 Power cable ×1 adapter bracket Camera Tripod ×2... -
Page 8: Mounting And Connecting Thermal Camera
Precise Body Temperature Measurement Thermal Camera 3.2 Mounting and Connecting Thermal Camera As shown in the figure below, 4 × M2 mounting holes are reserved at the bottom of the product for fixing the camera to the adapter or bracket. Figure 2 Bottom structure of camera Take the thermal camera mounted on a tripod as an example, as follows: ... - Page 9 Precise Body Temperature Measurement Thermal Camera After the adapter bracket is installed, the bottom of the thermal camera is shown in Figure 4, and it is mounted on the corresponding supporting equipment through the mounting holes 3 / 8-16UNC or 1 / 4-20UNC at the bottom of the adapter bracket. Figure 4 The bottom structure of camera adapter Take the thermal camera mounting on a tripod as an example, the specific steps are as follows：...
- Page 10 Precise Body Temperature Measurement Thermal Camera 2） Plug the power cable and network cable into the ports of the camera and the RJ45 interface of the network, the other end of the network cable is connected to the computer network port, and the other end of the power cable is connected to a DC power adaptor (12V is recommended).
-
Page 11: Introduction Of Reference Blackbody
Precise Body Temperature Measurement Thermal Camera 3.3 Introduction of Reference Blackbody 3.3.1 Specification The specification of reference blackbody is shown in table 2. Table 2 Reference blackbody parameters Reference blackbody Power supply AC180~240V Max. power consumption 260W Environment temperature 0℃~40℃ Accuracy ±0.2℃@35℃... -
Page 12: Quick Start And Attentions
Precise Body Temperature Measurement Thermal Camera Effective heating area 1/4-20UNC Figure 7 Drawing of blackbody 3.3.3 Quick Start and Attentions Connect power supply(AC180~240V), and turn on the power switcher on the blackbody, the power indicator is on, it display 35℃ in default. The blackbody can be used normally when it gets stable after waiting 5 minutes. -
Page 13: Site Layout Solution
Precise Body Temperature Measurement Thermal Camera Avoid using in the humid environment and beyond the operating temperature range, so as not to affect the accuracy of the equipment. 3.4 Site Layout Solution 1）、Reference layout Refer to Figure 8 for the layout plan in a wide space area. The external reference blackbody is placed directly in front of the infrared camera and made it observable in the imaging field of view . -
Page 14: Site Installation And Layout Considerations
Precise Body Temperature Measurement Thermal Camera Reference blackbody 参考黑体 出现区域 appearance area 人 People Figure 9 Infrared imaging on PC Environmental requirements The infrared temperature measuring camera is arranged in an environment where the temperature is relatively constant and there is no direct sunlight, to avoid temperature measurement errors caused by the temperature changing environment affecting the human skin surface temperature. -
Page 15: Quick Start Of Client
4 Quick Start of PC Client Professional temperature screening client will be provided , users can easily get the thermal image and body temperature. If you need “InfiRay Intelligent Infrared Temperature Screening System Operation Manual”, please contact us. Product model... -
Page 16: 5、Troubleshooting
Precise Body Temperature Measurement Thermal Camera 5、Troubleshooting Fault description Possible Causes Method of exclusion Objective focal length does not The thermal camera is aimed at the target match position, click the auto focus on the PC client Image blur Long time without image correction On the host computer, click the shutter correction The supply voltage exceeds the Check if the power supply voltage is between 10 ~... -
Page 17: 6、Maintenance
Precise Body Temperature Measurement Thermal Camera 6、Maintenance 6.1 Notice Make sure the camera is fixed firmly when the camera is installed on wall, ceiling or pillar. The camera shall not fall on the equipment, especially vigorous vibration equipment. Keep the camera away from the presence of magnetic field interference, avoid mounting camera to the surface where occurs vibration or shocks easily.（The camera may be damaged ignoring this item）. -
Page 18: Safety Codes
Precise Body Temperature Measurement Thermal Camera wipe liquid also can not dip in too much, make sure the cloth is wet, but wipe liquid can not be extruded. If still not clean, replace the cloth and repeat operation. 6.3 Safety Codes ...
