  • Page 2 InfiRay Outdoor - Geni Series- User Manual www.infirayoutdoor.com IMPORTANT SAFETY INFORMATION • Do not expose the device to extreme temperatures below - 20 °C and above + 50 °C. • The product may only be connected to a USB Type-C cable.
  • Page 3 InfiRay Outdoor - Geni Series- User Manual www.infirayoutdoor.com In accordance w i t h state legislation, penalties may be imposed for as a result of unintentional or incorrect use. improper disposal of this type of waste. Function check For business customers within the European Union 1.
  • Page 4 InfiRay Outdoor - Geni Series- User Manual www.infirayoutdoor.com Technical Specifications GH35 GL50 GH50 Model GL35 Microbolometer Type Unrefrigerated 640×512 384×288 640×512 Resolution, pixels 384×288 Pixel size, um NETD, mk ≤35 Frequency, Hz Features of optics F50mm /1.1 Lens F35mm /1.0 12.6×9.4...
  • Page 5 InfiRay Outdoor - Geni Series- User Manual www.infirayoutdoor.com Battery type / Capacity 4400 mAh built-in battery + 3300 mAh replaceable battery Max. operating time (at t=22℃), h ★ 10 h External power supply 5 V (Type C USB) Operating characteristics Max.
  • Page 6 InfiRay Outdoor - Geni Series- User Manual www.infirayoutdoor.com Contents of the package affected. Geni thermal imaging can be widely used in night hunting, field observation and navigation, search and rescue operations, etc. Thermovision ● IRM-030-205-Q1 picatinny clamp ● Functions IBP-2 battery ●...
  • Page 7 InfiRay Outdoor - Geni Series- User Manual www.infirayoutdoor.com Components and controls 1. Lampshade 2. Eyepiece adjustment ring 3. Type C port 4. Down Button / Shooting Button 5. Menu button (M) 6. Up button / Zoom button 7. Power button 8.
  • Page 8 InfiRay Outdoor - Geni Series- User Manual www.infirayoutdoor.com Description of button functions Button Default state Short press Long press Device j off Switching on the device The device is switched on Device standby mode Shutdown Power button Standby mode Waking up the device...
  • Page 9 InfiRay Outdoor - Geni Series- User Manual www.infirayoutdoor.com Batteries ⚫ The Geni thermal imaging camera can only be powered by the battery in the package. Using other batteries may cause irreparable damage to the device, The Geni series thermowells are supplied with an IBP-2 rechargeable Li- a fire can also be caused.
  • Page 10 InfiRay Outdoor - Geni Series- User Manual www.infirayoutdoor.com ⚫ To charge, plug the charging adapter into a 100 - 240 V (20) socket. Note: Two batteries can be charged simultaneously using the two battery slots. Charging using battery chargers ⚫...
  • Page 11 InfiRay Outdoor - Geni Series- User Manual www.infirayoutdoor.com ⚫ The battery capacity may decrease when using the thermal or the charger, it can even cause a fire. imaging system in negative temperature, but this is normal, it is not ⚫ If you plan not to use the battery for a long period of time, you must a malfunction.
  • Page 12 InfiRay Outdoor - Geni Series- User Manual www.infirayoutdoor.com Technical operations and to be shot. ⮚ After installing the thermal imager on the gun for the first time, follow the instructions in Section 9, "Loading". Installing the Thermal Imaging Bracket ⮚ Before using the Geni thermal imaging camera, you need to install the rifle holder (21) on the underside of the thermal imager.
  • Page 13 InfiRay Outdoor - Geni Series- User Manual www.infirayoutdoor.com Shot Switching on and setting the picture ⮚ Remove the lens cap (9). Geni thermal imaging functions for using the Zeroing method Zeroing ⮚ Press and hold the power button (7) to turn on the thermal imaging camera.
  • Page 14 InfiRay Outdoor - Geni Series- User Manual www.infirayoutdoor.com ⮚ Press the M button (5) briefly to switch the direction of movement between submenu or add a new distance (see main menu option Shooting - X (default submenu Shooting distance - Reset shooting distance).
  • Page 15 InfiRay Outdoor - Geni Series- User Manual www.infirayoutdoor.com after 2 sec. Calibration Calibration allows you to equalize the temperature of the sensor and eliminate image defects (e.g. vertical stripes, phantom images, etc.). There are three calibration modes: automatic (A), manual (M) and background (B).
  • Page 16 (Main Menu - Settings - Date and Time Settings, in this guide) or you can sync the date and time in the InfiRay Outdoor app. All rights reserved, content may not be copied or distributed in any form without written permission.
  • Page 17 InfiRay Outdoor - Geni Series- User Manual www.infirayoutdoor.com ⮚ Press and hold the button Photography Stop shooting (14) to save the ⮚ Press button video. Take a photo (4) on the home ⮚ All photos and videos will be screen. The image freezes for stored in the device's built-in 0.5 s and...
  • Page 18 5. Calibration mode ( instead of thecalibration mode, a countdown called "Infiray" - double-click to open the device called "Internal timer appears with 5 seconds remaining until automatic calibration). Storage" to access the built-in memory. The timer appears only after the microbolometer temperature has ⮚...
  • Page 19 InfiRay Outdoor - Geni Series- User Manual www.infirayoutdoor.com 6. Compass (when on) All rights reserved, content may not be copied or distributed in any form without written permission.
  • Page 20 9. Wi-Fi status ( : Wi-Fi off; : Wi-Fi on) 10. Clock (set the clock in the "InfiRay Outdoor" app or in the main and shooting distance) can be changed in the quick menu. menu) ⮚ From the home screen, briefly press the M button (5) to enter 11.
  • Page 21 InfiRay Outdoor - Geni Series- User Manual www.infirayoutdoor.com ⮚ Edit the current parameters or enter the submenus by briefly the distance stored in profile A). pressing the M button (5). ⮚ Press and hold the M button (5) to save your changes and exit ⮚...
  • Page 22 InfiRay Outdoor - Geni Series- User Manual www.infirayoutdoor.com Main menu options and description Turning Ultra-bright mode on/off Ultra-bright ⚫ Press the M button (5) to enter the main menu. mode ⚫ Select the Ultra-bright mode menu option using the Up (6) / Down (4) button.
  • Page 23 InfiRay Outdoor - Geni Series- User Manual www.infirayoutdoor.com ⚫ Press the Up (6) / Down (4) button to select one of the following modes: - Automatic - The software determines the need for calibration in automatic mode. The calibration process will then start automatically.
  • Page 24 InfiRay Outdoor - Geni Series- User Manual www.infirayoutdoor.com ⚫ Select the Intentional Cross menu option with the Up (6) / Down (4) button. ⚫ Press the M button (5) briefly to enter the viewfinder submenu as shown below. Select the spray profile ⚫...
  • Page 25 InfiRay Outdoor - Geni Series- User Manual www.infirayoutdoor.com Select the colour of the intentional cross ⚫ Select the Reticle Color option with the Up (6) / Down (4) button in the intentional cross submenu. ⚫ Press the M button (5) briefly to enter the Intentional Cross Colors submenu.
  • Page 26 InfiRay Outdoor - Geni Series- User Manual www.infirayoutdoor.com If the firing distance is the same as the preset distance, you can fire the thermal imager directly as follows: ⚫ In the Shooting Distances submenu select the target distance to be shot with the Up button (6) / Down (4).
  • Page 27 InfiRay Outdoor - Geni Series- User Manual www.infirayoutdoor.com ⚫ Press the M button (5) briefly to enable the range restart. Two triangle icons will appear above and below the distance number. ⚫ Reset the number value from 0 to 9 using the Up (6) / Down (4) button.
  • Page 28 InfiRay Outdoor - Geni Series- User Manual www.infirayoutdoor.com ⚫ Press the M button (5) briefly to enter the Range submenu. ⚫ In order from left to right, you can select from the menu: effective range, target type or target height.
  • Page 29 InfiRay Outdoor - Geni Series- User Manual www.infirayoutdoor.com ⚫ The PIP (Picture in Picture) window appears in the bottom left corner of the screen. ⚫ To the right of the PIP window is information about cursor movement on the X (horizontal) and Y (vertical) axis, including the number of pixels corrected.
  • Page 30 InfiRay Outdoor - Geni Series- User Manual www.infirayoutdoor.com ⚫ The PIP and other information will move to the top left corner of the screen if the cursor moves to the bottom left corner. ⚫ Hold down the M button (5) until the display shows "Do you want to save these settings?"...
  • Page 31 InfiRay Outdoor - Geni Series- User Manual www.infirayoutdoor.com Selecting general settings ⚫ Press the M button (5) to enter the main menu. ⚫ Select the Settings menu option using the Up (6) / Down (4) button. ⚫ Press the M button (5) briefly to enter the submenu.
  • Page 32 InfiRay Outdoor - Geni Series- User Manual www.infirayoutdoor.com ⚫ In the Settings submenu, briefly press the M button (5) to activate the Time submenu. Two triangle icons will appear above and below the selected value. ⚫ The time format is displayed as HH:MM in 24-hour format (14:48).
  • Page 33 InfiRay Outdoor - Geni Series- User Manual www.infirayoutdoor.com ⚫ In the settings submenu, select the "Unit" menu option using the Up (6) / Down (4) button. ⚫ Enter the units submenu by briefly pressing the M button (5). ⚫ Select the desired unit between meter and yard by briefly pressing the Up (6) / Down (4) button.
  • Page 34 InfiRay Outdoor - Geni Series- User Manual www.infirayoutdoor.com ⚫ Press the M button (5) briefly to enter the Factory Reset submenu. ⚫ Briefly press the Up (6) / Down (4) button and select Yes or No. ⚫ Confirm your selection by briefly pressing the M button (5).
  • Page 35 InfiRay Outdoor - Geni Series- User Manual www.infirayoutdoor.com PIP function The PIP (Picture in Picture) function allows you to see a magnified image in a specific window, but also the main image. ⮚ Press the Zoom (6) + Menu (5) button on the home screen turn on the PIP function.
  • Page 36 InfiRay Outdoor - Geni Series- User Manual www.infirayoutdoor.com ⮚ From the home screen, press and hold the Up (6) + M (5) to enter the stadiametric rangefinder interface, two horizontal lines appear at the top and bottom cursor positions. ⮚ Place the object in the middle of these lines, then move the lines and find the destination between the lines by clicking the button Up (6) / Down (4).
  • Page 37 InfiRay Outdoor - Geni Series- User Manual www.infirayoutdoor.com ⮚ The distance between two ⮚ Select the Settings menu option using the Up (6) / Down (4) button. horizontal lines indicates ⮚ Press the M button (5) briefly to enter the submenu.
  • Page 38 Wi-Fi features To set a Wi-Fi name and password The Wi-Fi name and password can be reset in the InfiRay Outdoor app The Geni thermal imaging camera has a built-in Wi-Fi module for wireless for the Geni thermal imager.
  • Page 39 About InfiRay Outdoor Technical inspection ⮚ The InfiRay Outdoor app can be purchased on the official website, or via Google Play or t h e App Store, and can also be used scanned QR code. It is recommended to perform a technical i n s p e c t i o n before using the ⮚...
  • Page 40 InfiRay Outdoor - Geni Series- User Manual www.infirayoutdoor.com Maintenance ⮚ Clean the electrical contacts and battery slots on the thermal imaging camera with a non-greasy organic solvent. ⮚ Check the optics of the lens and eyepiece. If necessary, remove dirt Maintenance should be carried out at least twice a year and includes the and sand from the optics (it is ideal to use the non-contact method).
  • Page 41 InfiRay Outdoor - Geni Series- User Manual www.infirayoutdoor.com Troubleshooting The table lists all the faults that can o c c u r when using thermal imaging. Perform the recommended checks and troubleshooting steps in the order listed in the table. If you encounter a fault that is not listed in the table, or if you cannot repair the fault yourself, return the thermal imaging unit for repair.
  • Page 42 InfiRay Outdoor - Geni Series- User Manual www.infirayoutdoor.com camera. Check that the thermal imaging system is securely mounted. Make sure you use the same type and calibre of bullets as were used for priming. All rights reserved, content may not be copied or distributed in any form without written permission.
  • Page 43 InfiRay Outdoor - Geni Series- User Manual www.infirayoutdoor.com If your thermal imaging was shot in summer but used in winter (or vice versa), a slight shift of the shot point is possible. Missing Image of the Observation through Remove the glass from the field of view.
  • Page 44 InfiRay Outdoor - Geni Series- User Manual www.infirayoutdoor.com When using thermal imaging in Under higher temperature conditions, the observed objects (surroundings and background) heat up low temperature conditions, the differently due to thermal conductivity. Accordingly, the image quality produced by the thermal imager will be image quality of the surroundings higher.
  • Page 45 InfiRay Outdoor - Geni Series- User Manual www.infirayoutdoor.com Legal and regulatory information Frequency range of the wireless transmitter module: WLAN: 2.412-2.472GHz (For EU) Wireless transmitter module power < 20 dBm (EU only) IRay Technology Co., Ltd. therefore declares that the Geni GL35R complies with Directives 2014/53/EU and 2011/65/EU.
  • Page 46 InfiRay Outdoor - Geni Series- User Manual www.infirayoutdoor.com this equipment shall accept any interference received, including interference that may cause undesired operation. Information for users Any changes or modifications not expressly approved by the party responsible for authorizing them may void the user's authority to operate the equipment.
  • Page 47 InfiRay Outdoor - Geni Series- User Manual www.infirayoutdoor.com interference cannot occur. If this equipment is causing harmful Equipment accessories that do not meet these requirements may not interference to radio or television reception, which can be determined by meet RF exposure requirements and should be avoided. Use only the turning the equipment off and on, the user is then advised to attempt to supplied or approved antenna.
