- Page 1 AT31F/AT61F Online Temperature Measurement Thermal Camera User Manual V1.0.2 IRay Technology Co., Ltd. www.iraytek.com...
-
Page 2: Table Of Contents
5. Product Introduction ................6 6. Product Figure and Explanation ............7 7. Product Models Reference ..............8 8. Lens Parameters ..................9 9. Quick Start Guide ................. 10 10. Product and Accessories List .............. 12 11. Technical Data..................13 11.1 AT31F ....................13... - Page 3 AT31F61F Online Temperature Measurement Thermal Camera User Manual 11.2 AT61F ....................15 12. Mechanical Drawings ................17 13. Common Troubleshooting ..............18 14. Cleaning Thermal Camera ..............19 14.1 Camera Housing, Cables and Other Items ........19 14.1.1 Liquids ..................19 14.1.2 Cleaning Tools ................
-
Page 4: Legal Disclaimer
AT31F61F Online Temperature Measurement Thermal Camera User Manual 1. Legal Disclaimer 1.1 Legal Disclaimer The thermal cameras manufactured by IRAY TECHNOLOGY are warranted for a period of two-year and the accessories are warranted for a period of three-month form the delivery date of the original purchase, provided such products have been under normal storage, use and maintenance. -
Page 5: Copyright
AT31F61F Online Temperature Measurement Thermal Camera User Manual 1.2 Copyright ©IRay Technology Co., Ltd. 2021. All rights reserved worldwide. All contents in this manual, including words, pictures, images, etc., belong to IRAY TECHNOLOGY CO., LTD. (Hereinafter referred to as “THE COMPANY” or “IRAY TECHNOLOGY”). -
Page 6: Safety Information
AT31F61F Online Temperature Measurement Thermal Camera User Manual 2. Safety Information WARNING Make sure you read all applicable Material Safety Data Sheets (SDS) and warning labels on containers before you use a liquid. The liquids can be dangerous. Injury to persons can occur. WARNING It is prohibited to use the product in a high temperature above 85 °C or in a low temperature below-45 °C. -
Page 7: Notice To User
AT31F61F Online Temperature Measurement Thermal Camera User Manual 3. Notice to user 3.1 Calibration IRAY TECHNOLOGY recommends that you verify your calibration yearly in order to ensure accuracy. You can verify the calibration through IRAY TECHNOLOGY or third-party organizations. 3.2 Accuracy For very accurate results, we recommended that you wait 30 minutes after you have started the camera before measuring a temperature. -
Page 8: Customer Help
AT31F61F Online Temperature Measurement Thermal Camera User Manual 4. Customer Help 4.1 FAQ You can find answers to FAQ about this model on the service support page of our official website. 4.2 Download You can download the following contents from our website: ⚫... -
Page 9: Product Introduction
AT31F61F Online Temperature Measurement Thermal Camera User Manual 5. Product Introduction Main Features： ·Compact Size ·Quick Installation ·Several optional lenses · I/O Alarm ·Simultaneous output of temperature data and image data Typical Applications: ·Power detection ·Industrial detection ·Environmental Monitoring ·Fire Warning... -
Page 10: Product Figure And Explanation
AT31F61F Online Temperature Measurement Thermal Camera User Manual 6. Product Figure and Explanation Table 6.1 Explanation of Product Appearance Explanation infrared lens power/data interface mounting screw holes ATF connecting cable... -
Page 11: Product Models Reference
1: 4mm 2: 6.2mm 3: 9.7mm 4: 13mm AT31F 5: 19mm 6: 25mm 7: 35mm 8: 50mm 1: 4.1mm 2: 5.8mm 3: 9.1mm 4: 13mm AT61F 5: 19mm 6: 25mm 7: 35mm 8: 55mm E.G.：AT31F3X(AT21F-3-X) stands for AT31F with 9.7mm lens. -
Page 12: Lens Parameters
AT31F61F Online Temperature Measurement Thermal Camera User Manual 8. Lens Parameters Table 8.1 AT31F Lens Parameters Resolution Focal Length FOV（H×V） IFOV 384×288 90.3°×68.7° 4.250mrad 384×288 6.2mm 61.5°×45.7° 2.742mrad 384×288 9.7mm 37.9°×28.7° 1.753mrad 384×288 13mm 28.2°×21.3° 1.308mrad 384×288 19mm 19.5°×14.7° 0.895mrad 384×288... -
Page 13: Quick Start Guide
AT31F61F Online Temperature Measurement Thermal Camera User Manual 9. Quick Start Guide Please follow the steps: 1. Install IRT_VMS if the thermal camera is with other networking equipments, and IRT_TAS_AT can be installed on a single thermal camera for temperature measurement and analysis. - Page 14 AT31F61F Online Temperature Measurement Thermal Camera User Manual 9. The I/O alarm output of the thermal camera can be realized through the ALARMOUT interface on the cable. Non-alarm information remains high, and becomes low when there is alarm information. After the alarm disappears, it will continue to be maintained for 30 seconds and then return to high level.
-
Page 15: Product And Accessories List
AT31F61F Online Temperature Measurement Thermal Camera User Manual 10. Product and Accessories List Table 10.1 Product and Accessories List Product and Accessories ATF online temperature measuring thermal camera ATF dedicated cable... -
Page 16: Technical Data
AT31F61F Online Temperature Measurement Thermal Camera User Manual 11. Technical Data 11.1 AT31F Table 11.1.1 AT31F Performance Parameters Imaging and Optical Data Resolution 384×288 Thermal Sensitivity/NETD ＜50mK(40mK is optional) @25℃, F#1.0 Image Frequency 50Hz Detector Data Detector Type VOx, Uncooled FPA detector Spectral Range 8～14μm... - Page 17 AT31F61F Online Temperature Measurement Thermal Camera User Manual Compression Standard Compression Standard for Videos H.264/H.265 Video Format MP4, mov Alarm Alarm Function Area, line and other individual alarms configurable and support external equipment to trigger alarms Alarm Output I/O output, log, and save image Power System Typical power consumption@25℃...
-
Page 18: At61F
AT31F61F Online Temperature Measurement Thermal Camera User Manual 11.2 AT61F Table 11.2.1 AT61F Performance Parameters Imaging and Optical Data Resolution 640*512 Thermal Sensitivity/NETD ＜50mK(40mK is optional) @25℃, F#1.0 Image Frequency 25Hz Detector Data Detector Type VOx, Uncooled FPA detector Spectral Range 8～14μm Pixel 12μm... - Page 19 AT31F61F Online Temperature Measurement Thermal Camera User Manual Alarm Alarm Function Area, line and other individual alarms configurable and support external equipment to trigger alarms Alarm Output I/O output, log, and save image Power System Typical power consumption@25℃ ≤3W Connector type for external power supply DC Voltage 9-26VDC Power Protection...
-
Page 20: Mechanical Drawings
AT31F61F Online Temperature Measurement Thermal Camera User Manual 12. Mechanical Drawings... -
Page 21: Common Troubleshooting
AT31F61F Online Temperature Measurement Thermal Camera User Manual 13. Common Troubleshooting Table 13.1 Product Common Troubleshooting Troubles Possible Cause Solutions No image calibration for Click the shutter correction button Images are blurred a long time in the software supply voltage Check whether the power supply exceeds normal... -
Page 22: Cleaning Thermal Camera
AT31F61F Online Temperature Measurement Thermal Camera User Manual 14. Cleaning Thermal Camera 14.1 Camera Housing, Cables and Other Items 14.1.1 Liquids One of the following liquids can be used. ⚫Warm water ⚫Mild detergent solution 14.1.2 Cleaning Tools A soft cloth 14.1.3 Cleaning Procedure Please follow this procedure: 1. -
Page 23: Cleaning Tools
AT31F61F Online Temperature Measurement Thermal Camera User Manual 96% ethyl alcohol (C ⚫ 14.2.2 Cleaning Tools Dustless cloth, cotton wool 14.2.3 Cleaning Procedure Please follow this procedure (Take dustless cloth as an example). 1.Soak the dustless cloth in the liquid. 2.Gently wipe the lens with the dustless cloth. -
Page 24: Terms And Definitions
AT31F61F Online Temperature Measurement Thermal Camera User Manual 15. Terms and Definitions Terms Definition FPA (Focal Plane Array) A type of infrared detector IFOV (Instantaneous Field of A resolution measure method of infrared thermal camera View) (that is, the field of view of a pixel) FOV(Field of View) The angle of view that the infrared camera can see H is the horizontal angle and V is the vertical angle. -
Page 25: Appendix A Emissivity Of Common Materials
AT31F61F Online Temperature Measurement Thermal Camera User Manual Appendix A Emissivity of Common Materials Temperature（℃） Material Emissivity Water 0～100 0.95～0.98 Soil(dry) 0.92 Soil(wet) 0.95 Woods 0.962 Sand Sandstone 0.909～0.935 PVC plastic 0.93 Asphalt 0.967 Paint 0.92～0.94 Wallpaper 0.85～0.90 Cloth 0.98 Concrete 0.92 Pavement surface...
