- Page 1 Quick Start Guide QG001002 TSL2521 TSL2521 EVM Highly Sensitive Ambient Light Sensor with Selective Flicker Detection and Fast Sampling for Use Behind OLED or Auxiliary to Camera v1-00 • 2020-Dec-14...
-
Page 2: Table Of Contents
TSL2521 ● TSL2521 EVM Document Feedback Content Guide Content Guide Out of the Box ........ 3 Software Installation ..... 4 Connect Hardware ......7 Start the Application ..... 8 Uninstall Application ..... 9 Quick Start Guide • PUBLIC QG001002 • v1-00 • 2020-Dec-14... -
Page 3: Out Of The Box
TSL2521 ● TSL2521 EVM Document Feedback Out of the Box Out of the Box For a detailed description of the TSL2521 TSL2521 EVMTSL2521 EVM, please refer to User Guide: ● UG001001 Each TSL2521 Evaluation Kit comes with the following components:... -
Page 4: Software Installation
Flash Drive will commonly be assigned the next available drive letter for example C: hard drive, D: CD-ROM, E: flash drive The Setup Wizard will open and guide you through the installation of the TSL2521 host software, (Figure 2 through Figure 8) The EVM Controller board requires the installation of FTDI CDM drivers. - Page 5 TSL2521 ● TSL2521 EVM Document Feedback Software Installation Figure 4: Figure 5: Select Installation Folder Select Start Menu Folder Figure 6: Figure 7: Installation in Progress Information Screen Quick Start Guide • PUBLIC QG001002 • v1-00 • 2020-Dec-14 │ 5...
- Page 6 TSL2521 ● TSL2521 EVM Document Feedback Software Installation Figure 8: Installation Completed Successfully Quick Start Guide • PUBLIC QG001002 • v1-00 • 2020-Dec-14 │ 6...
-
Page 7: Connect Hardware
Document Feedback Connect Hardware Connect Hardware Plug the TSL2521 Daughterboard into the Controller board (Figure 1). Always use ESD procedures when handling the EVM. Using the enclosed USB cable, plug the micro-B connector into the EVM module. Using the other end of the cable, plug the USB A-connector into a USB port on the computer. -
Page 8: Start The Application
Start the Application Start the Application To start the application select ams > TSL2521 EVM > TSL2521 EVM on the All Programs menu. The default installation directory depending on the device and the operating system you are using is: C:\Program Files\ams\TSL2521_EVM (Windows 32-bit operating systems) C:\Program Files (x86)\ams\TSL2521_EVM (Windows 64-bit operating systems) A different install path may be selected by the user during the install (Figure 4). -
Page 9: Uninstall Application
AG shall not be liable to recipient or any third party for any damages, including but not limited to personal injury, property damage, loss of profits, loss of use, interruption of business or indirect, special, incidental or consequential damages, of any kind, in connection with or arising out of the furnishing, performance or use of the technical data herein.
