Specifications - Go Power 10 AMP RVC-MPPT User Manual

ITEM
Battery Voltage Range
Max Charge Current
Conversion Efficiency
MPPT Tracking Efficiency
Max Panel Input Voltage
Max PV Power Input
No-Load Loss
Grounding
Operating Temperature
Storage Temperature
Humidity
Battery Type
Max Wire Gauge
Dimensions (H x W x D)
Weight
Water Ingress Protection
Altitude
Protection
[page 12] | gpelectric.com

7. SPECIFICATIONS

PARAMETERS
8V – 16V
10A
≤98%
>99%
100Voc
200W
<10mA
Negative
-35 to 45°C
-35 to 75°C
95% N.C.
Lead Acid (AGM, GEL, Flooded), LiFePO4
8 AWG
3.35" x 6.1" x 1.57"
0.67lbs (300g)
IP32
< 3000m
Solar/battery reverse polarity
Solar/battery over voltage
Solar/battery short circuit
Over temperature
