INSTALLATION AND START-UP MANUALFOR KOMPACT AMC DOSING
Below are the technical and pump performance data:
Model
200
INTRODUCTION
The pump is composed of a part that houses the control electronics and the magnet and a hydraulic side always in contact with
the liquid to be dosed.
Check the rating plate of the main features of your pump
We recommend checking the chemical compatibility between the product and the materials in contact.
PUMP HEAD MATERIALS
Pump body:
•
Valves:
•
Balls:
•
Diaphragm:
•

SPECIFICATIONS

Weight:
•
Power Supply:
•
Consumption:
•
Fuse:
•
Protection rating:
•
Level control input:
•
Pulse input:
•
EM00136401
PUMP
PVDF-T
Pressure Flow rate
bar l/h
100% = 5
8
20% = 1
100% = 3
10
20% = 0,6
PVDF-T
PVDF-T
Ceramic
PTFE
1.5 Kg
100 - 240 Vac (50-60 Hz)
13W @ 100 Vac – 19W @ 240 Vac
2A 250V T 5x20
IP65
Dry contact (on-off)
Dry contact (on-off) maximum frequency 80Hz
rev.1.0
Connections
(mm)
cc /stroke
Int / Ext
0.52
4 / 6
0,31
1. Adjustments area
2. Dosing head
3. Priming valve
4. Delivery connector
5. Suction connector
6. Base fixing bracket (optional)
EN
Stroke / min
100% = 160
20% = 32
100% = 160
20% = 32
1
