Howard Miller HEKMAN 8-1250 Quick Start Manual

A B
ALLEN BOLT ALLEN BOLT
M8 x 40 (4 PCS.) 5
x 2" (4 PCS.)
16
1
TOP ASSEMBLY (1 Pc)

ASSEMBLY TO HEIGHT 30"

Step 1.
ALIGN THE HOLES IN THE COLUMN (4) WITH THE
INSERT MOUNTING PLATE (2). CONNECT USING
FLAT WASHER (E), LOCK WASHER (F), ALLEN
BOLT (B) AND ALLEN KEY (G) PROVIDED.
Step 2.
LAY TOP PANEL UPSIDE DOWN ON A SOFT, CLEAN
AND FLAT SURFACE.
ALIGN THE HOLES IN THE MOUNTING PLATE WITH
THE INSERT IN THE BOTTOM PANEL OF THE TOP
ASSEMBLY. CONNECT USING FLAT WASHER (E),
LOCK WASHER (F), ALLEN
BOLT (A) AND ALLEN KEY (G) PROVIDED.
8-1250 PUB / GAME TABLE
C D
ALLEN BOLT ALLEN BOLT
5 1 5
x 2 " (4 PCS.) x 8" (4 PCS.)
16 2 16
2
MOUNTING PLATE
(1 Pc)

Assembly Instruction

G
A
F
E
HARDWARE LIST
E F
FLAT W. M8
SPRING W. M8
(16 PCS.)
(16 PCS.)
PART INSIDE
3
PED. EXTENDER (1 Pc) COLUMN (1 Pc)
Step 3.
ALIGN THE HOLES IN THE COLUMN (4) WITH THE INSERT
BASE ASSEMBLY (5). CONNECT USING FLAT WASHER (E),
LOCK WASHER (F), ALLEN BOLT (C) AND ALLEN KEY (G)
PROVIDED.
G
F
E
Page 1 of 2
G
ALLEN KEY L5
(FOR BOLT M8)
1 PC.
4 5
BASE ASSEMBLY
(1 Pc)
G
B
F
E
C
