Lippert Vela Owner's Manual

Pop up roof system
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
Vela Pop Up Roof System
Class B
OWNER'S MANUAL

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Vela and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Lippert Vela

Summary of Contents for Lippert Vela

  • Page 1 Vela Pop Up Roof System Class B OWNER'S MANUAL...

  • Page 2: Table Of Contents

    Cleaning External Pop-up Roof Surfaces Cleaning Internal Pop-up Roof Surfaces Introduction The Vela Pop-up Roof is a manually operated, van roof-mounted sleeper. The Pop-up Roof has a solid roof with a canvas body that includes: • a double bed, • screened windows, •...

  • Page 3: Safety

    Safety Read and understand all instructions before installing or operating this product. Adhere to all safety labels. This manual provides general instructions. Many variables can change the circumstances of the instructions, i.e., the degree of difficulty, operation and ability of the individual performing the instructions. This manual cannot begin to plot out instructions for every possibility, but provides the general instructions, as necessary, for effectively interfacing with the device, product or system.

  • Page 4: Preparation

    Preparation Make sure camper van is level. Make sure camper van is properly supported and secured. Engage brakes. Chock all tires. Make sure wind speeds do not exceed 25mph, if so the pop-up MUST remain in the closed position or damage could occur. Operation Do NOT open pop-up roof if wind speeds exceed 25mph.
  • Page 5 Grab the handle with one hand (Fig. 4A), then at the same time press the release button (Fig. 4B) and push the handle upwards. After unlocking the roof, grab both handles (Fig. 4A) and push the roof upwards. Fig. 4 Brightness inside the sleeping area can be adjusted by means of two flexible lamps (Fig. 5) located on the lower part of the pop-up.
  • Page 6 Located at the interior of the entrance frame, there is at least one module with two 5V DC USB ports (Fig. 8). Note: Various kinds of electronic devices can be recharged and used, if they meet the provided current limits and voltages. Fig.
  • Page 7 Opening all pop-up windows improves ventilation against heat build-up and helps to refresh the sleeping area (Fig. 13). Fig. 13 Open Window The Vela Pop-up Roof System comes equipped with a 51" x 78" (1300 mm x 2000 mm) double bed (Fig. 14). Fig. 14 Page 7 Rev: 07.27.2021...

  • Page 8: Closing The Pop-Up Roof System

    To reach the bed, attach the supplied ladder to the two hooks (Fig. 15). Fig. 15 Ladder Hooks Climb the ladder to the bed, sit on the surface of the sleeping area, then rotate your torso. Closing the Pop-up Roof System To close the pop-up, do as follows: Attach the supplied ladder on the hooks (Fig.
  • Page 9 Fig. 18 Handles To make sure the pop-up's locking system has been engaged, perform the following: Grab the handles on the roof with both hands and push upwards. If the upward pressure on the roof does not change its position significantly on both sides, then the locking system is properly engaged.

  • Page 10: Troubleshooting

    Do NOT exceed the product's maximum speed limit of 80 mph (130 km/h). Troubleshooting The following troubleshooting chart only covers basic operational concerns. If other concerns exist other than what is listed in the troubleshooting chart, contact the Lippert Care Center at (574) 537-8900. What is Happening Why?

  • Page 11: Maintenance

    Maintenance Periodically clean the canvas to prevent dirt and grime build-up. Dirt and grime build-up may penetrate the fabric. Use a soft bristled brush, sponge or clean cloths to remove dirt from the fabric before washing. Care and Maintenance To preserve the integrity of the canvas and extend its lifespan, take the following steps when caring for the canvas: Inspect and treat the canvas every 12-14 months.
  • Page 12 The contents of this manual are proprietary and copyright protected by Lippert Components, Inc. (LCI). LCI prohibits the copying or dissemination of portions of this manual unless prior written consent from an authorized LCI representative has been provided.  Any unauthorized use shall void any applicable warranty. ...
