Summary of Contents for Schacht MATCHLESS 75-900009

  • Page 1 MATCHLESS 75-900009 75-900010 SPINNING WHEEL pgrading the readle Upport Find out more at schachtspindle.com Schacht Spindle Company 6101 Ben Place Boulder, CO 80301 p. 303.442.3212 f. 303.447.9273 © 2018 Schacht Spindle Company, Inc. 05.18...
  • Page 2 MATCHLESS SPINNING WHEEL pgrading the readle Upport PARTS (ST) OnlY (dT) OnlY ingle readle OuBle readle 16-900010S ST assembly 16-900010 DT assembly 14-400052 large nylon washer 14-400052 large nylon washer 16-900012 footman assembly 16-900012 footman assembly 12-200184 treadle yoke 12-200184 treadle yoke 20-12072 1-1/2"...
  • Page 3 flyer assembly mother-of-all (MOA) bolt Don’t remove black Phillips these mother-of-all head screws fasteners! (MOA) upper rear drive band leg bolts crank front leg footman assembly treadle yoke lower rear treadle cross brace lower front leg bolt leg bolt FIGURE 1: PARTS OF THE WHEEL –...
  • Page 4 REMOVING THE METAL TREADLE SUPPORT BAR Remove the flyer assembly. Drop the drive band toward the back of the wheel. Detach the old footman/footmen from the crank. If the footman attaches with retainer rings (Figure 2A), cut the rings with diagonal cutting pliers to remove.
  • Page 5 While lifting up on the front leg, pivot the cross brace downward. treadle(s) Remove the old treadle(s). ASSEMBLING THE NEW TREADLE front leg SUPPORT BAR short rod Set the new treadle assembly in place. Pivot the cross brace upward, then position the front leg in front so the holes align.
  • Page 6 crank and make sure the footman footman footman leather wood doesn’t hit anything; if necessary, cotter adjust placement of footman on the treadle yoke crank by moving the e-clips. clevis pin Attach the footman to the treadle yoke (Figure 7). Thread the 1-1/2" yoke small small nylon nylon...
  • Page 7 Attach the treadle yoke to the footman footman leather wood treadle (Figure 9). Thread the 1-1/2" treadle yoke screw through the metal washer cotter yoke and split lock washer, then through clevis pin the bottom of the treadle. Screw the yoke screw into the treadle yoke small nylon...
  • Page 8 Rotate the yoke clockwise to raise the treadle and counterclockwise to lower the treadle. Make only 2 or 3 turns and reassemble the footman and treadle treadle yoke. Repeat this adjustment until you support bar are satisfied with the position of the lock nut treadle.
