Amersham -
Solid Pine Large Sideboard
Assembly Instructions -
Please keep for future reference
706/1262
Dimensions
Width - 131cm
Depth - 42cm
Height - 84cm
Important –
Please read these instructions fully before starting assembly
If you need help or have damaged or missing parts, call the
Customer Helpline: 03456 400 800
Issue 2 - 08/08/18
Advertisement
Related Manuals for Argos Amersham 706/1262
Summary of Contents for Argos Amersham 706/1262
- Page 1 Amersham - Solid Pine Large Sideboard Assembly Instructions - Please keep for future reference 706/1262 Dimensions Width - 131cm Depth - 42cm Height - 84cm Important – Please read these instructions fully before starting assembly If you need help or have damaged or missing parts, call the Customer Helpline: 03456 400 800 Issue 2 - 08/08/18...
-
Page 2: Care And Maintenance
Safety and Care Advice Important – Please read these instructions fully before starting assembly Check you have all the This product has been produced We do not components and tools listed on from natural timber; you may recommend the pages 2 and 3. notice some variation in the grain use of power and colour of different component... - Page 3 Components - Panels Please check you have all the panels listed below 6 Right side panel (82 x 40cm) 1 Top panel (131 x 42cm) underside Left side panel 2 Base panel (125.6 x 38.4cm) (82 x 40cm) Right front frame underside (82 x 9.2cm) 3 Shelf...
- Page 4 Components - Fittings If you have damaged or missing components, call the Customer Helpline: 03456 400 800 Please check you have all the fittings listed below Note: The quantities below are the correct amount to complete the assembly. In some cases more fittings may be supplied than are required.
- Page 5 Assembly Instructions Step 1 Fixing right front frame to the right side panel (Two people required for an easier assembly). Insert right side panel into right front frame through joints. Yes! Note: Before fixing blocks into place it is important to ensure that the slot and groove of parts are fully pushed together...
- Page 6 Assembly Instructions Step 3 Fitting Metal dowels. Screw metal dowels into right side panel left side panel and top panel Note: Insert metal dowels as far as shown. Do not over tighten. Step 4 Insert dowels into the indicated parts. Insert shelf supports into the right side panel and left side panel...
- Page 7 Assembly Instructions Step 5 Fixing side drawer runners. Fit side drawer runner to the right side panel . Fit and push dowels into the front frame first. Attach side drawer runner using screw Repeat step 5 for the left side panel side drawer runner.
- Page 8 Assembly Instructions Step 7 Insert the assembled frame into the holes on left side panel Step 8 Fixing base panel. With help, fit base panel to the left side panel. Insert 2 locking nuts into base panel where shown. Use a screwdriver to turn locking nuts clockwise to lock.
- Page 9 Assembly Instructions Step 9 Fixing right side panel. With help, place right side properly panel ensuring dowels and front frames are all fit into their holes at the same time. Insert 2 locking nuts into base panel where shown. Use a screwdriver to turn locking nuts clockwise to lock.
- Page 10 Assembly Instructions Step 11 Position shelf into place. Make sure round edge is facing front. Note: This shelf is adjustable it can be placed near the back panel and leave a gap in the front or it can be placed near the doors, leaving a gap in the back.
- Page 11 Assembly Instructions Step 13 Fixing back column. Fit back column middle drawer runners and base panel Attach back column to middle drawer runners using screws Step 14 Fixing top panel. With help, f it top panel to the cabinet. Insert locking nuts into anel where...
- Page 12 Assembly Instructions Step 15 Attach bottom support to the base panel using screws Step 16 Fitting hinges to doors. Attach hinges in the pre marked holes on doors using screws as shown.
- Page 13 Assembly Instructions Step 17 Hanging doors. With help, centralise the doors in the opening of the cabinet using the door spacer to ensure correct spacing, as shown. From inside the View from behind cabinet fix the hinges using screws shown. Note: To ensure the alignment of the doors is...
- Page 14 Assembly Instructions Step 19 Fitting door lock. Screw clip in place using screws Ensure that the 2 small wheels are flush with the edge of the base as shown in the diagram. Insert plug into clip , ensuring they are leveled as shown in the diagram.
- Page 15 Assembly Instructions Step 21 Drawer assembly. Attach drawer sides to the drawer front using screws Slide drawer bottom into slots on drawer sides and position drawer back in place. Holding the drawer back , press the drawer sides and fix them using screws Using bolts attach...
- Page 16 Assembly Instructions Step 23 Fixing back panels. Important: Cabinet MUST ‘square’ when back panels are attached. Attach back panels using nails Step 24 Fixing to wall Furniture must be fixed to Note: Wall plugs not supplied. a wall. The correct type of fixing must be used for your wall, seek Fix wall straps professional advice if in doubt.
-
Page 17: A Guide To - Wall Mounting & Fixings
A Guide to - Wall Mounting & Fixings Important: When drilling into walls always Important note: check that there are no hidden wires or pipes etc. If plastic wall plugs Make sure that the screws and wall plugs being used are supplied with your are suitable for supporting your unit. - Page 18 Argos store Key exclusions applying to both the Manufacturer’s Guarantee and Furniture Care include where the fault is due to misuse, abuse, deliberate damage, wear and tear, neglect, use in contravention...
