Brooklyn - Desk
Assembly Instructions -
Dimensions
Width - 101cm
Depth - 39.5cm
Height - 79cm
Important -
Please read these instructions fully before starting assembly
If you need help or have damaged or missing parts, call the Customer Helpline: 08456 400800
Please keep for future reference
709/2688
MADE IN
BRITAIN
Issue 1 - 07/05/13

Advertisement

loading
Need help?

Need help?

Do you have a question about the Brooklyn 709/2688 and is the answer not in the manual?

Questions and answers

Summary of Contents for Argos Brooklyn 709/2688

  • Page 1 Brooklyn - Desk Assembly Instructions - 709/2688 Please keep for future reference Dimensions Width - 101cm Depth - 39.5cm MADE IN Height - 79cm BRITAIN Important - Please read these instructions fully before starting assembly If you need help or have damaged or missing parts, call the Customer Helpline: 08456 400800 Issue 1 - 07/05/13...
  • Page 2: Care And Maintenance

    Safety and Care Advice Important - Please read these instructions fully before starting assembly • Warning: This unit weighs • Make sure you have enough • We do not approximately 18.5kgs. space to layout the parts before recommend the Please lift with care. starting.
  • Page 3 If you have damaged or missing components, call the Components - Panels Customer Helpline: 08456 400800 quoting the reference numbers below Please check you have all the panels listed below 1 Top (D2092A) (995 x 395mm) Left Side 3 Upright (D2093A) (D2095A) (643 x 378mm)
  • Page 4 If you have damaged or missing components, call the Components - Fittings Customer Helpline: 08456 400800 quoting the reference numbers below Please check you have all the fittings listed below Note: The quantities below are the correct amount to complete the assembly. In some cases more fittings may be supplied than are required.
  • Page 5 If you have damaged or missing components, call the Assembly Instructions Customer Helpline: 08456 400800 quoting the reference numbers below Step 1 Prepare the drawer fronts Screw 2 metal dowels into the holes shown on the back of each drawer front Note: Tighten metal dowels up fully against...
  • Page 6 Assembly Instructions Step 4 Fit the drawer base Slide the drawer base down the grooves in the drawer sides and down into the groove in the drawer front Step 5 Fit the drawer back Fit the drawer back down onto the drawer base Make sure that the drawer base...
  • Page 7 Assembly Instructions Step 7 Runners must be Fit runners to the pushed up against drawers the drawer front Turn the 2 drawer assemblies over. Fit runner , marked with ‘R’, to the bottom edge of the right drawer side , as shown, making sure that it is pushed up against the back of the drawer front...
  • Page 8 Assembly Instructions Step 9 screw screw screw Prepare the left side Fit 2 runners the left side The 1st screw uses the 2nd hole in from the Finished front of the runner. front edge The 2nd and 3rd screws use the holes that line up with the other panel holes.
  • Page 9 Assembly Instructions Step 10 Join the left side and back rail Finished Push the back rail Finished front edge onto the left side top edge Use a screwdriver to tighten the 2 large locking nuts fitted to the back rail Note: Turn the large locking nuts as far as...
  • Page 10 Assembly Instructions Step 13 Prepare the upright Fit 2 runners the upright The 1st screw uses Finished the 2nd hole in from the front edge front of the runner. screw screw screw The 2nd and 3rd screws use the holes that line up with the other panel holes.
  • Page 11 Assembly Instructions Step 14 Fit the upright Push the upright onto the assembly. Use a screwdriver to tighten the 3 large locking nuts fitted to the back rail and rail Turn the assembly onto its front edges for the next step. Step 15 Fit the base Note: To make it easier...
  • Page 12 Assembly Instructions Step 17 Prepare the top Screw 4 metal dowels into the top Insert 2 large locking nuts into the top Fix the bracket in the middle of the top flush to the back edge using screw Step 18 Fit the top Push the top onto...
  • Page 13 Assembly Instructions Step 19 The measurement from top corner X to bottom corner X must be equal to the measurement from top corner Y to bottom corner Y Fit the back Square up the unit by making sure that measurement x to x equals y to y.
  • Page 14 Assembly Instructions Step 21 Join the flyover top and flyover support These are through holes These are part-drilled holes Line up the part-drilled holes in the flyover support with the mini blocks on the flyover Tighten the screws of the mini blocks into the part-drilled holes in the...
  • Page 15 Assembly Instructions Step 24 Prepare the modesty Insert 4 large locking Finished nuts into the modesty front edge Step 25 Fit the modesty Push the modesty onto the upright Finished Use a screwdriver to front edge tighten the 2 large p l a i n c locking nuts...
  • Page 16 Assembly Instructions Step 26 Fit the right side assembly Push the right side onto the top modesty Use a screwdriver to tighten the 4 large locking nuts fitted to the top and modesty Step 27 Secure the flyover support Fit 2 screws through the flyover support and into the back edge...
  • Page 17 Assembly is complete If you need help or have damaged or missing parts, call the Customer Helpline: 08456 400800 and quote the reference numbers on the component pages. Argos Ltd, 489-499 Avebury Boulevard, Central Milton Keynes, MK9 2NW...
