Doublebed White - 4Ft
Assembly Instructions
7037076
- Please keep for future reference
Dimensions
Length - 195,3cm
Depth - 126,3cm
Height - 92,6cm
Weight - 22kg
Important
– Please read these instructions fully before starting assembly
If you need help or have damaged or missing parts, call the Customer Helpline:
0045 7668 8055 or e-mail: order@fl exa.dk
Issue 2 - 01/06/17

Advertisement

loading
Need help?

Need help?

Do you have a question about the HOME Doublebed White 4Ft and is the answer not in the manual?

Questions and answers

Summary of Contents for Argos HOME Doublebed White 4Ft

  • Page 1 Doublebed White - 4Ft Assembly Instructions 7037076 - Please keep for future reference Dimensions Length - 195,3cm Depth - 126,3cm Height - 92,6cm Weight - 22kg Important – Please read these instructions fully before starting assembly If you need help or have damaged or missing parts, call the Customer Helpline: 0045 7668 8055 or e-mail: order@fl...
  • Page 2 Safety and Care Advice Important – Please read these instructions fully before starting assembly • We do not • Check you have all the • Do not stand or put weight on recommend the components and tools listed on the product, this could cause use of power pages 2 and 3.
  • Page 3: Components - Parts

    If you have damaged or missing components, Components - Parts call the Customer Helpline: 0045 7668 8055 Please check you have all the parts listed below Leg x2 (33,4x4,3x4,3cm) Leg x2 Leg x2 (92,6x4,3x4,3cm) (33,4x4,3x4,3cm) No. 12-04309261-20 No. 12-04303342-20 No. 12-04303341-20 List x4 Slat x14 (90,4x2,0x2,0cm)
  • Page 4 Components - Fittings Please check you have all the fi ttings listed below Note: The quantities below are the correct amount to complete the assembly. In some cases more fi ttings may be supplied than are required. No. 3922-06013 No. 3901-40030 No.
  • Page 5 Assembly Instructions Step 1 Insert the Ø10 dowels into the holes in bedsides and endrails It may be necessary to tap the dowels in very gently with a small hammer. Apply glue to the list and attach it to the bedside using screws .
  • Page 6 Assembly Instructions Step 5 Push the threaded pin through the middle hole in leg . Attach connecting bolts to the pin. Note the position of the holes in connecting bolt Step 6 Insert threaded bushes into the holes in the bedsides .
  • Page 7 Assembly Instructions Step 8 Attach angles to the lower endrails using 568,5 mm. 568,5 mm. screws Step 9 Attach midsupports to the angles using screws . Attach the midsupports to the using screws...
  • Page 8 Assembly Instructions Step 10 Position three slats into the bed with the distances shown. Push the bedsides together and fasten the slats using screws 715 mm 65 mm 65 mm 65 mm 65 mm Step 11 Position the remaining slats into the bed with the distance of 65 mm between one another.
