Pagnell 5 Drawer Chest
Assembly Instructions
Dimensions
Width - 76.5cm
Depth - 40.5cm
Height - 82cm
Important
- Please read these instructions fully before starting assembly
If you need help or have damaged or missing parts, call the Customer Helpline:
Argos = 0345 6400800
- Please keep for future reference
709/2585
709/2592
325/9274
Version 3 Date: 10/06/14
Advertisement
Related Manuals for Argos 709/2592
Summary of Contents for Argos 709/2592
- Page 1 Width - 76.5cm Depth - 40.5cm Height - 82cm Important - Please read these instructions fully before starting assembly If you need help or have damaged or missing parts, call the Customer Helpline: Argos = 0345 6400800 Version 3 Date: 10/06/14...
- Page 2 IMPORTANT: RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE • Argos Ltd. MK9 2 NW. • This product is intended for • Assembly of this product must children in the age 6 or above.
- Page 3 Components - Panels If you have damaged or missing components, call the Customer Helpline: Argos = 0345 6400800 Please check you have all the panels listed below Drawer front panel x 5 (72.3 x 14.4cm) Top panel (76.2 x 40cm)
- Page 4 Components - Fittings Note: The quantities below are the correct amount to complete the assembly. In some cases mor may be supplied than are required. (This screw is included in the bag of runner) Runner x 10 12mm Screw x 30 39mm Locking pin x 28 30mm Dowel x 6 Plastic support x 3...
- Page 5 Assembly Instructions Step 1 Attaching runners Middle hole Position Runners front edge of the Right side panel Slide top of the Runners 1.7cm on the Right Runners side panel Note: The front part of the runner should be approximately 1.7cm from the front edge of the panel.
- Page 6 Assembly Instructions Step continued Middle hole Position Runners front edge of the Left side panel Slide top of the Runners 1.7cm on the Left Runners side panel Note: The front part of the runner should be Finished approximately 1.7cm front edge from the front edge of the panel.
- Page 7 Assembly Instructions Step 2 Fitting dowels Insert Dowels into the Bottom panel Bottom support Step 3 Attaching plastic supports Plastic supports onto the Front panel Front panel onto the Bottom panel...
- Page 8 Assembly Instructions Step 4 Attaching bottom panel and bottom support Position Bottom panel onto the Left side panel Insert Locking nuts into the Bottom panel back edge Use a screwdriver to turn Locking nuts clockwise to lock. Position Bottom support onto the Left side panel Insert Locking nuts...
- Page 9 Assembly Instructions Step 5 Attaching right side panel Position Right side panel onto the unit. Insert 2 Locking nuts into the Bottom panel and Bottom support Use a screwdriver to turn Locking nuts clockwise to lock. Step 6 Attaching top panel Screw Locking pins into the Top panel Note:...
- Page 10 Assembly Instructions Step continued Carefully locate the Top panel onto the unit. Insert 4 Locking nuts into the Right side panel and Left side panel Use a screwdriver to turn Locking nuts clockwise to lock. Step 7 Fixing back panel Attach Back panel onto the unit using Nails Important:...
- Page 11 Assembly Instructions Step 8 Drawers assembly Screw Locking pins into 4 holes shown on back of the Drawer front panel Note: Insert Locking pins as far as shown. Do not over tighten. Fix Drawer left side panel onto the Drawer front panel Fix Drawer right side panel onto the...
- Page 12 Assembly Instructions Step 8 - continued Insert 2 Locking nuts into the holes (they will only insert one way). Use a screwdriver to turn Locking nuts clockwise to lock. Place a small amount of Glue into the grooves. Carefully slide the Drawer back surface bottom panel into the...
- Page 13 Assembly Instructions Step 8 - continued Position the Drawer back panel onto the unit using Screws Repeat with remaining 4 drawers. Step 9 Inserting drawers With help, carefully stand drawer chest upright. Warning: The drawer chest is heavy. Lift with care. Slide the drawers fully onto the runners so the runners butt up against...
- Page 14 Screw Note: Before use allow glue to dry for 24 hours and make sure the unit is secure. Assembly is complete. If you need help or have damaged or missing parts, call the Customer Helpline: Argos = 0345 6400800...
-
