09 SITNSLEEP METAL HIGHSLEEPER FRAME
Assembly Instructions -
Bed unit dimensions
Width - 201cm
Depth - 154cm
Height - 179cm
Important -
Please read these instruction fully before starting assembly
If you need help or have damaged or missing parts, call the Customer Helpline: 08456 400800
Please keep for future reference
Sofa unit dimensions
Width - 202cm
Depth - 85.5cm
Height - 25.5cm
758/5401
758/5418
Issue 1 - 2/01/10

Advertisement

loading
Need help?

Need help?

Do you have a question about the 758/5401 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Argos 758/5401

  • Page 1 09 SITNSLEEP METAL HIGHSLEEPER FRAME Assembly Instructions - 758/5401 Please keep for future reference 758/5418 Bed unit dimensions Sofa unit dimensions Width - 201cm Width - 202cm Depth - 154cm Depth - 85.5cm Height - 179cm Height - 25.5cm Important -...
  • Page 2: Care And Maintenance

    Take to your local authority waste disposal centre. Keep These Instructions For Future Reference This product complies with Argos plc EN 747-1:2007 489-499 Avebury Boulevard Central Milton Keynes MK9 2NW Note: if required the next...
  • Page 3 (88.7 x 2cm) Base frame X 2 Filler bar X 2 Base frame X 1 (91 x 3cm) (88.7 x 2cm) (129 x 3cm) Argos Side rail Side rail l i a (190.7 x 4cm) (191.3 x 1.9cm) (190.7 x 4cm)
  • Page 4 Components Please check you have all the panels listed below Lower desk panel X 1 Back safety barrier X 1 Bed slat X 1 (70 x 40cm) (190.7 x 93.4cm) (190.3 x 37cm) Front safety barrier X 1 Ladder X 1 Base frame X 2 (152 x 37.5cm) (75.3 x 4cm)
  • Page 5: Tools Required

    Components - Fittings If you have damaged or missing components, call the Customer Helpline: 08456 400800 Please check you have all the fittings listed below Note: The quantities below are the correct amount to complete the assembly. In some cases more fittings may be supplied than are required.
  • Page 6 Assembly Instructions Step 1 Note: Please ensure theWASHER is curving i n facing the hole befor e assembling. The washer curving in The washer curving out facing the hole is correct. facing the hole is incorrect. Step 2 - Bed unit Preparing metal leg Please be careful to select metal leg...
  • Page 7 Assembly Instructions Step 5 Attaching metal leg Two people are required here. Attach metal leg the unit by using 2 pcs of bolts and 3 pcs of bolts and washers Step 6 Attaching filler bar Attach filler bar headboard by using 3 pcs of bolts Step 7 Attaching headboard...
  • Page 8 Assembly Instructions Step 8 Attaching base frame Two people are required here. Attach 1 pc of base frame to metal leg by using 1 pc of bolt and washer Attach 1 pc of base frame to metal leg by using 1 pc of bolt washer and nut Step 9...
  • Page 9 Assembly Instructions Step 11 Fitting side rail Two people are required here. Fix side rail to the unit by using 4 pcs of bolts and washers Step 12 Fitting side rail Two people are required here. Fix side rail to the unit by using 4 pcs of bolts and washers...
  • Page 10 Assembly Instructions Step 13 Fitting side rail Two people are required here. Fix side rail to the unit by using 4 pcs of bolts and washers Step 14 Attaching base frame Attach 4 pcs of base frames to the desk frame by using 4 pcs of bolts...
  • Page 11 Assembly Instructions Step 16 Fitting upper desk panel Fix the upper desk panel to the unit by using 4 pcs of screws Step 17 Fitting lower desk panel Fix the lower desk panel to the unit by using 4 pcs of screws Step 18 Attaching bookshelf Two people are required...
  • Page 12 Assembly Instructions Step 19 Preparing bed slat Spread out the bed slat , each hook should be pointed downwards as shown. Step 20 Attaching bed slat Two people are required here. Insert each hook of bed slat into the corresponding holes of the side rails Step 21 Attaching side frame...
  • Page 13 Assembly Instructions Step 22 Fixing back safety barrier Fix back barrier the unit by using 3 pcs of bolts and washers Step 23 Fixing front safety barrier Two people are required here. Fix front barrier to the unit by using 1 pc of bolt and washer and 2 pcs of bolts...
  • Page 14 Assembly Instructions Step 24 Inserting plastic cover Insert 22 pcs of plastic covers into unit by hand. Step 25 Attaching ladder Two people are required here. Attach ladder the side rail Attach ladder the unit by using 2 pcs of bolts , washers and nuts...
  • Page 15 Assembly Instructions Step 26 OPTION 1 Assembly is complete for the bed unit. MAX:200mm There are two option to choose for assembling the ladder and bookshelf. Warning: Top of the mattress shall not come above the line marked on the bed. OPTION 2 MAX:200mm...
  • Page 16 Assembly Instructions Step 27 - Sofa unit Attaching sticky pad Attach the sticky pad onto both end of base against the frames friction between metal frame. Step 28 Attaching base frame Two people are required here. Fix the base frames to the side frames using 4 pcs of bolts and washers...
  • Page 17 Assembly Instructions Step 30 Attaching spring hinge Two people are required here. Attach the spring hinge to the unit by using 2 pcs of bolts , washers and nuts Step 31 Attaching sofa slat Attach the sofa slat onto the spring hinge on the unit by using 4 pcs of bolts , washers...
  • Page 18 Assembly Instructions Step 33 Attaching foot steel Two people are required here. Fix the foot steel the unit by using 1 pc of bolt and washer Step 34 Attaching sofa slat Two people are required here. Attach the sofa slat onto the spring hinge on the unit by using 4 pcs of bolts...
  • Page 19 Assembly Instructions Step 35 Adjusting sofa seat Fold sofa slat shown. Lift sofa slat shown. Lift sofa slat shown. Move simultaneously sections adjust the sofa seat.
  • Page 20 Assembly Instructions Step 36 Assembly is complete for the sofa seat unit. Step 37 Assembly is complete. If you need help or have damaged or missing parts, call the Customer Helpline: 08456 400800...
