Courtyard Creations TCS18SK Assembly Instructions

ASSEMBLY INSTRUCTIONS
ATTENTION: THIS PRODUCT IS NOT FOR COMMERCIAL USE
PARTS LIST
PART
MATERIAL CODE
NO.
1
TCS18SK-CS01
2
TCS19SK-CS02
3
62TMS20SKY101
4
13C??B30008001
Note:
The tiles can be easily broken, be careful when
removing them.
Attention:
Make sure that each bolt needed for all steps matches
the corresponding figure to ensure proper assembly.
Step 1:
Place the table top (#1) onto a non-abrasive surface,
such as a carpet, with its underside facing upwards.
Fasten the legs (#2) to the
rim by using bolts (#5). Keep the bolts loose.
See Figure 1.
! Use the correct bolts as indicated. Do not tighten any of the bolts until the table is completely assembled.
Do not sit or stand on this table.
!
Do not discard of any of the packaging until you have checked that you have all of the parts and
!
fittings required.
Keep children away during assembly. This item contains small parts that can be swallowed by
!
children. Children should always be under direct adult supervision while using this product.
! Retain these assembly instructions for future reference.
!
Quote the following FQC NO. when contacting the service center.
V-3
INTENDED FOR RESIDENTIAL USE ONLY.
TCS18SK
PART Q'TY
TABLE TOP
LEG
CENTER CONNECTOR
TILE
underside of the table top (#1)
SERVICE CENTER TOLL FREE NO.
TEL: 1-877-539-7436
FAX: 1-877-539-7439
DO NOT RETURN TO STORE!
STOP
PAGE 1 OF 2
PART
MATERIAL CODE
NO.
1 5
17C40A0705001YX
4 6
17C40A0709001YX
1 7
17KAA0101----Y4
4 8
17KAC3101----Y3
FIGURE 1
2
PART
BOLT M6*15
BOLT M6*25
HEX. KEY WRENCH 4MM
HEX. KEY WRENCH 10MM
2
2
2
1
15
#5 BOLT M6*15
COURTYARD CREATIONS INC.
Q'TY
4
4
1
1
5
