Courtyard Creations TCS73SC Assembly Instructions

ASSEMBLY INSTRUCTIONS
ATTENTION: THIS PRODUCT IS NOT FOR COMMERCIAL USE
PARTS LIST
PART
MATERIAL CODE
NO.
1
TCS73SC-CS05-1
2
TCS73SC-CS04-1
3
TCS73SC-CS04-2
4
62TCS73SCY101
5
13C??7B29008001
6
13C??BCEP008001
Note:
The tiles can be easily broken, be careful when you remove
them.
Attention:
Make sure that each bolt needed for all steps matches the
corresponding figure to ensure proper assembly.
Step 1:
Place the table top (#1) onto a non-abrasive surface, such
as a carpet, with its underside facing upwards. Fasten the
legs (#2) and the supports (#3) to the underside of the table
top (#1) rim by using bolts (#8). Keep the bolts loose.
See Figure 1.
!
Use the correct bolts as indicated. Do not tighten any of the bolts until the table is completely assembled.
!
Do not sit or stand on this table.
!
A weighted umbrella base must be used when using an umbrella with this table.
!
Do not discard of any of the packaging until you have checked that you have all of the parts and fittings
required.
!
Keep children away during assembly. This item contains small parts that can be swallowed by children.
Children should always be under direct adult supervision while using this product.
!
Retain these assembly instructions for future reference.
!
Quote the following FQC No. when contacting the service center.
E-3
INTENDED FOR RESIDENTIAL USE ONLY.
TCS73SC
PART Q'TY
1
TABLE TOP
4
LEG
2
SUPPORT
1
CENTER
CONNECTOR WITH RING
4
TILE A
12
TILE B
SERVICE CENTER TOLL FREE NO.
TEL: 1-877-539-7436
FAX: 1-877-539-7439
PAGE 1 OF 2
PART
MATERIAL CODE
NO.
7
13C??1B29008001
8
17C40A0705001YX
9
17C40A0709001YX
10
17KAA0101----Y4
11
17KAC3101----Y3
12
1422
FIGURE 1
2
2
8
#8 BOLT M6*15
PART
TILE C
BOLT M6*15
BOLT M6*25
HEX. KEY WRENCH 4MM
HEX. KEY WRENCH 10MM
TOUCH-UP PAINT
2
3
3
1
