Courtyard Creations TCS41CK-WM Assembly Instructions

ASSEMBLY INSTRUCTIONS
ATTENTION: THIS PRODUCT IS NOT FOR COMMERCIAL USE

PARTS LIST

PART
MATERIAL CODE
NO.
1 TCS41CK-CS01
2 TCS42CK-CS02
3 62TCS42CKY101
4 13C??1B29008001
17C33A0709001Y4
5
Note:
The tiles can break easily. Therefore, be careful
when removing them. Do not throw away the residual
tiles. Keep them for future use.
Attention:
Make sure that each bolt needed for all steps matches
the corresponding figure to ensure proper assembly.

Step 1:

Place the table top (#1) onto a non-abrasive surface,
such as a carpet, with its underside facing upwards.
Fasten the legs (#2) to the underside of the table
top (#1) rim by using bolts (#5) and washers (#7).
Keep the bolts loose. See Figure 1.
Do not sit or stand on this table.
!
Do not discard of any of the packaging until you have checked that you have all of the parts and
!
fittings required.
! Keep children away during assembly. This item contains small parts that can be swallowed by
children. Children should always be under direct adult supervision while using this product.
Retain these assembly instructions for future reference.
!
Quote the following FQC NO. when contacting the service center.
!
STOP
INTENDED FOR RESIDENTIAL USE ONLY.
TCS41CK-
PART Q'TY
1
TABLE TOP
4
LEG
1
CENTER
CONNECTOR
6
TILE
4
BOLT M6*25
SERVICE CENTER TOLL FREE NO.
TEL: 1-877-539-7436
FAX: 1-877-539-7439
DON'T RETURN TO STORE!
PAGE 1 OF 2
WM
PART
MATERIAL CODE
NO.
6
17C01A0706001Y4
7 17FA05040301-Y4
8 18000337004
9
18000337001
10 17KAA0101----Y4
FIGURE 1
2
2
1
25
COURTYARD CREATIONS INC.
PART Q'TY
BOLT M6*16
WASHER d6.5*D13*1.0
BOLT CAP
BOLT CAP M6
HEX.KEY WRENCH 4MM
8
2
5
2
7
#5 BOLT M6*25
8
12
4
8
1
