Forest garden OPA810DD Manual

10' x 8'
Overlap Workshop
IMPORTANT, RETAIN FOR FUTURE REFERENCE; READ
CAREFULLY
This building is pressure treated to ensure longevity of all
timber components and to protect against rot. This may leave
a colour difference on some parts that will even out as the
moisture content stabilises. This will not need additional
treatment.
- This product must be built on a solid level base.
- Please keep all plastic bags and small parts away from
children.
- The roof of this building is not a load bearing structure.
- Timber is a natural material. It will shrink and swell as a
result of varying moisture content.
- Due to the nature of the material the doors may need some
trimming for a neater fit.
0333 7777 089
Technical Help line: 8.30 am and 5.00
pm Monday to Friday.
Please check all parts prior to assembly
Assembly of damaged parts may be deemed to be
acceptance and this may affect the remedies you are entitled
to.
If the product is not constructed in accordance with the
instructions, or is altered in any way (e.g. painted), the
manufacturer cannot be held liable for any resulting damage.
Fixing Pack (OPA812DDFP) Not to Scale
This fixing pack is used for several products.
There may be additional fixings.
Turn Button
Qty 2
Flush Hinge
Qty 4
Z' bracket
10mm Felt tacks
Qty 16
Qty 110

REQUIRED TOOLS :

(NOT SUPPLIED)
SHARP KNIFE
TAPE MEASURE SCISSORS
POZI DRIVE
FLAT HEAD
SCREWDRIVER
SCREWDRIVER LADDER HAMMER
Important : Assembly of
this shed requires a
Must Pre-drill for
minimum of two adults.
each screw used.

OPA810DD PARTS LIST

A B C
OPA810WS
OPA8DE
OPA8PE
WINDOW PANEL
DOOR END
PLAIN END
H J
60151710PTR
1710mm CORNER STRIP QTY 6
N
O
28120675PARPTR
45281462PTR
675mmm STRIP QTY 2
1462mm BATTEN QTY 8
1
D
A
Place the two floor sections together and position the panels on top of the completed floor. Make
sure that all the panels are tight and flush before fixing them to each other using 3x50mm screws.
When the panels are secured to each other, make sure they are flush and fix to the floor using
3x50mm screws for each panel. Make sure that the screws locate into the bearers underneath.
3
J Q
S
Place the 1695mm batten against
the inside of the door end so that
Fix the 1645mm batten against the
the batten is covering the gap
end of the door using 3x70mm
between the door end and the
screws. Make sure it is flush with
door. Fix this in place using
the door end framework.
2x30mm screws.
Fix a turn button to the top and
Repeat for the opposite side of
bottom of the batten using
1x30mm (zinc) screw for each.
the door way.
D E
OPA810PS 154013408
PLAIN PANEL ROOF SHEET
QTY 2 QTY 4
QTY 2
L
K
45281540PTR
1540mmm BATTEN QTY 4
P
45451630PT
1630mm BATTEN QTY 1
R
FIN20010512PT
FINIAL QTY 2
Top View
B
Floor
C
4
H
P
Board
Q
O
Place the window from the outside so that the lip sits on the bottom board as shown.
Place the plastic strips at the top and bottom of the window so that one side butts up
against the cladding. Fix each strip in place using 2 x security screws.
Position the remaining strip vertically against the outer edge of the window so that one
side of the strip butts up against the cladding.
Place one 675mm wooden strip in the middle so that it overlaps the window equally on
both sides and the remaining strip on the door side of the window. Again fix each
wooden strip in place using 2 x security screws.
H
F G
PCWIN1
WINDOW QTY 4
The windows are packed
DDRPT WS10X8BRDFL
together tightly, separate
DOOR QTY 2 FLOOR
before assembly.
QTY 2
M
90121375AII74PT
60360200A1
1375mm BARGE BOARD QTY 4
TRUSS SUPPORT QTY 2
Q
84996
675mmm PLASTIC STRIP QTY 8
S
32161695PTR
1695mm STRIP QTY 2
2
F
Place the hinge against the inside of the door frame and position the large section of the hinge so
that it is flush with the inside of the framing as shown and fix with 25mm screws.
Open the hinge and fix the smaller section to the door framing. Again make sure that the hinge is
flush and that the holes are positioned so that the 25mm screws locate correctly into the batten.
5
Lip
Attention:
Take care when
placing the
screws. These
can not be
backed out.
You may need to
cut the plastic
strips to size using
a pair of scissors
Place and secure each angled block using 2x70mm screws. Make
sure these are 1470mm from the floor level and are tight against the
framework.
Place the truss so that is sits on the angled blocks. Secure this in
place by screwing down through the truss into the blocks using 2 x
90mm screws for each end.
I
OPA8TRUSS
TRUSS
85052 QTY 3
I
M
Issue 0215
