Thank you for purchasing your shed. No matter what size garden, a shed is the most practical of garden
structures. Simply follow these step by step instructions and our top tips and you'll be enjoying your shed for
many years to come. If you have any questions or need advice, our friendly team is here to help.
SHED
LARGE SHEDS SINGLE DOOR
FIXING PACKS CONTAIN:
M6 Nut
QTY: 4
M6 x 25mm Washer
QTY: 4
INSTRUCTIONS
Flush Hinges
Hasp & Staple
QTY: 2
(8x6)
Z-Brackets(28mm)
QTY: 8
QTY: 1
U-Brackets
(MSUB)
Felt Tacks
QTY: 124
50mm L-Brackets
QTY: 8
Truss Support Brackets
(MSMTJB)
Support Bracket Hangers
QTY: 2
(MSTSB)
QTY: 2
QTY: 2
Advertisement
Related Manuals for Forest garden ODA68M
Summary of Contents for Forest garden ODA68M
- Page 1 Thank you for purchasing your shed. No matter what size garden, a shed is the most practical of garden structures. Simply follow these step by step instructions and our top tips and you’ll be enjoying your shed for many years to come. If you have any questions or need advice, our friendly team is here to help. SHED INSTRUCTIONS LARGE SHEDS SINGLE DOOR...
-
Page 2: Before You Start
BEFORE YOU START Please read through these instructions to familiarise yourself with your shed. We recommend that you check all the components using the lists found on the front and back pages before you start to build. All of our sheds are constructed in the same way. They simply come with different components depending on the type of shed you have. - Page 3 CARE & ATTENTION To help you get the most out of our products it’s useful to know a little more about the properties of timber, what’s normal and how your shed may behave as the seasons change. Wood is an extremely durable material for construction but as a natural product when used outdoors it is susceptible to changes in the environment.
- Page 4 IDENTIFY YOUR SHED From the section layout below, identify your shed based on the width and depth dimensions of your shed – eg 8x6. You’ll need this to identify the side panel positions. APEX SHED REVERSE APEX SHED 1ft Panel (295 x 1603mm) 3ft Panel (885 x 1603mm) PLEASE NOTE (With &...
- Page 5 CONSTRUCTION PRE-DRILL FLOORS & SIDES WITH 2MM BIT FOR ALL STEPS BELOW. Position the floor in your desired location. Turn the Layout the panels around your shed base. We recommend to start in a back corner then work from the back panels floors upside down to secure the sections together by screwing through the adjoining bearers.
- Page 6 WINDOWS PRE-DRILL WITH 2MM BIT FOR ALL STEPS BELOW. Fix interior sills at the base of windows with L-brackets and screws at a Secure windows by screwing through the window cover strips and 1002mm distance from the floor. Repeat this for multiple windows, as shown window into the panel frame.
- Page 7 PRE-DRILL ROOF WITH 2MM BIT FOR ALL STEPS BELOW. Assemble the truss and screw the Secure the support bracket hanger Screw the truss to the support bracket hangers. As with screws into the center of your shed. a result the truss will be centralised inside your shed U-brackets into the center of each beam as shown below.
