RiverRidge 06-141 Assembly Instructions Manual

Ellsworth double tilt-out laundry hamper
Hide thumbs Also See for 06-141:

Advertisement

Quick Links

Download this manual
ASSEMBLY INSTRUCTIONS
RiverRidge
Ellsworth Double Tilt-Out Laundry Hamper
®
ITEM #: 06-141 White
ADULT ASSEMBLY REQUIRED
This product requires assembly by an adult because of small parts. Care should be taken
in unpacking and assembling this item to keep small parts away from children. During assembly
children should be kept away from the product due to possible risk of injury.
WARNING
SEE FULL WARNING ON PAGE 2
Young children can be seriously injured or killed if furniture tips over.
Don't use this item for a TV stand or place heavy objects on top of item.
Always use angle-braces or anchors to secure furniture to the wall.

Advertisement

loading
Need help?

Need help?

Do you have a question about the 06-141 and is the answer not in the manual?

Questions and answers

Related Manuals for RiverRidge 06-141

Summary of Contents for RiverRidge 06-141

  • Page 1 RiverRidge Ellsworth Double Tilt-Out Laundry Hamper ® ITEM #: 06-141 White ADULT ASSEMBLY REQUIRED This product requires assembly by an adult because of small parts. Care should be taken in unpacking and assembling this item to keep small parts away from children. During assembly children should be kept away from the product due to possible risk of injury.
  • Page 2 THIS UNIT WILL HOLD UP TO 25 POUNDS PER SHELF AND 15 POUNDS PER CLOTH HAMPER OR A TOTAL OF 55 POUNDS. DO NOT LOAD EACH SHELF WITH MORE THAN 25 POUNDS, EACH CLOTH HAMPER WITH MORE THAN 15 POUNDS OR 55 POUNDS TOTAL WEIGHT.

  • Page 3: Parts List

    PARTS LIST ×2 DESCRIPTION 2PCS Hamper Front Door 2PCS Hamper Back Panel 4PCS Hamper Side Panel 2PCS Hamper Bottom Board 4PCS Hamper Support Bar 2PCS Hamper Left Cross Bar 2PCS Hamper Right Cross Bar 4PCS Wooden Rod 2PCS Cloth Hamper Top Board Left Side Panel Right Side Panel...
  • Page 4 PARTS LIST PARTS DESCRIPTION 14PCS Cam Bolt Cam Lock 14PCS Wood Dowel 12PCS Hamper Stopper 4PCS 4PCS Hinge 2PCS Machine Screw (4x18mm) 2PCS Knob 2PCS Screw (4x10mm) 8PCS Screw (4x15mm) 40PCS Screw (4x20mm) Screw (4x30mm) 2PCS Screw (3x12mm) 16PCS Screw (2.5x10mm) 20PCS 2PCS Adjustable Anchor Bracket...
  • Page 5 STEP 1 ×2 Attach 2 hinges (E) to hamper front door (1) by inserting 4 screws (L) through holes on hinges (E), then tighten to hamper front door (1). Attach knob (G) to hamper front door (1) by inserting machine screws (F) through hole on hamper front door (1), then tighten to knob (G).
  • Page 6 STEP 4 ×2 Attach 2 hamper side panels (3) to hamper front door (1) by inserting 6 screws (J) through holes on hamper side panels (3), then tighten to hamper support bars (5). Repeat above step to assemble another 2 hamper side panels (3) to hamper front door (1). STEP 5 ×2 Slide hamper bottom board (4) into groove on hamper front door (1).
  • Page 7 STEP 6 Screw 2 cam bolts (A) into cam bolt holes on bottom board (13). Insert 2 wood dowels into wood dowel holes on bottom board (13) Attach middle support panel (15) to bottom board (13) by inserting cam bolts (A) into cam lock holes and wood dowels (C) into wood dowel holes on middle support panel (15).
  • Page 8 STEP 8 Screw 2 cam bolts (A) into cam bolt holes on left side panel (11). Screw 2 cam bolts (A) into cam bolt holes on right side panel (12). STEP 9 Insert 4 wood dowels (C) into wood dowel holes on left side panel (11) and right side panel (12).
  • Page 9 STEP 10 Screw 6 cam bolts (A) into cam bolt holes on top board (10). Attach 2 adjustable anchor brackets (N) to top board (10) by inserting 2 screws (H) through holes on adjustable anchor brackets (N), then tighten to top board (10). STEP 11 Insert 6 wood dowels (C) into wood dowel holes on top board (10).
  • Page 10 STEP 12 Attach assembled hampers to outside cabinet by inserting 8 screws (L) through 4 hinges (E), then tighten to bottom board (13). STEP 13 Attach 2 back boards (14) to back of cabinet by inserting 20 screws (M) through holes on back boards(14), then tighten to back of cabinet.
  • Page 11 STEP 14 OPTION #1 OPTION #2 DRYWALL DRYWALL WOOD STUD SCREW WALL ANCHOR ONLY WITH SCREW Option #1: Securing to Drywall Position cabinet against wall in desired location. Using a pencil, make 2 small marks on wall through holes on brackets (N). Move cabinet away from wall and screw 2 plastic anchors (O) into wall on pencil marks.

  • Page 12: Care Instructions

    STEP 16 ×2 ×2 Insert 2 wooden rods (8) through tabs on cloth hamper (9). Place wooden rods (8) and cloth hamper (9) into cabinet as shown. Insert wooden rods (8) into grooves on hamper side panels (3) to avoid movement. Repeat above steps to assemble other wooden rods (8) and cloth hamper to unit.
  • Page 13 ® Thank you for purchasing this RiverRidge ® Home item. We hope you enjoy it and consider purchasing other RiverRidge ® items. To order replacement parts at no cost to you, email customer.service@ssi-rr.com, call 1-(844)-223-5201 or order parts online at www.riverridgehome.com. Only valid in the United States.
