- Page 1 Courtesy of:DiscountCarStereo.com Serving the internet community since 1995 A2DIY-JAG98R QUICK START BLUETOOTH INSTALL GUIDE FOR 1997-06 XK (X100) AND 1998-03 XJ (X308) STANDARD AUDIO WITH CD CHANGER Created June 9, 2020 Revised: March 14, 2021...
- Page 2 Keep original radio and CD changer while enjoying Bluetooth features only available in newer cars. Note: The A2DIY-JAG98R does not interfere with the functionality of existing AM/FM/radio, but requires and retains use of the 6-disc auto changer. See Frequently Asked question at the end of this guide for more details.
- Page 3 Fig. 7 Fig. 4 8. Disconnect CD Auto Changer plug from radio as seen in Fig. 8 5. Remove center console veneer panel (See Fig. 5) Fig.8 9. Connect factory CD changer plug (from step 8) to module Female Fig. 5 connector (See Fig.
-
Page 4: Aux Input
Red wire requires 12V accessory supply (Do not connect to constant Fig. 12 battery supply). See table below for possible 12V accessory supply. 13. Tap black wire to factory black wire at PIN 6 Playback options explained These options are available at checkout: 1. - Page 5 3. Route audio cable plug to where audio device will reside (within 3 ft.) Optional button Microphone Proceed to installation step 3 below. For added installation flexibility, we offer optional button microphone. (See Fig. 16a). Adding this option replaces visor microphone shown in Fig. 16). To install, connect 1/8”...
- Page 6 Optional USB “Fast Charge” Kit 2. Insert male terminal from supplied 3ft. cable (See Fig. 19) through hole (not for thumb drives etc.) created in step 1 and connect to installation harness charging port (See Fig. 20) Fig. 19 Flush mount 3 ft. USB cable Fig.
-
Page 7: Bracket Mount
3. Snap USB cable head (See Fig. 24) to bracket until flush (See Fig. 25) Fig. 22 Flush mounted to dash Fig. 25 4. Connect red or yellow wire to 12V. To maintain ability to charge without 4. Tuck and secure any extra wire from moving parts and test operation ignition key, connect red wire to Battery (Always on) power at pin 1 or 2 of factory radio 10-pin plug. -
Page 8: Feature Comparison
Ensure Bluetooth is enabled on your device (e.g. Smartphone/Tablet etc.) scan/search for available devices and select BT009 Feature JAG-HF JAGCD-HF BT45-JAG A2DIY-JAG98 A2DIY-JAG98R from list. Media button can be paired with multiple devices but can only operate CD changer retention ✓ ✓ ✓ one at a time. -
Page 9: Bluetooth Pairing
Media button Operation: Bluetooth Pairing: Once paired with smartphone/Tablet, users may perform the following functions This process is done upon initial install and will not have to be repeated. on iOS devices with Bluetooth 3.0 and later and Android 4.0 or later. These functions do not apply to the Jaguar radio. -
Page 10: Test Operation
What is the difference between the A2DIY-JAG98 and A2DIY-JAG98R? Press “CD” button. The A2DIY-JAG98R connects at the radio and applies to 1997-06 XK, 1998- 03 XJ Standard audio system only. 2000+ vehicles with Premium Audio system (amplifier in trunk—See Fig. 27) requires our A2DIY-JAG98. To be... - Page 11 In order to listen to CD’s or AUX, press push-to-talk button or play/pause button on remote control. 7. Can I install the A2DIY-JAG98R at the CD changer plug in trunk/hatch? the A2DIY-JAG98R module connects to the radio behind the dash.
