EMPTYING THE DUST CUP

IMPORTANT: Unplug the power cord before performing any maintenance.
To remove Dust Cup, press the Dust Cup
Release button next to the handle. Tilt dust cup,
then lift to remove.
To remove collected debris from Lint Screen,
press Top Release button and lift handle to
open. Gently brush lint screen to clean.
s h a r kc l e a n . c o m
To empty debris into trash, press Lower
Release button and bottom of dust cup will
drop open.
To reinstall, place bottom of dust cup into
pod and then tilt until it clicks into place.

CLEANING AND REPLACING THE FILTERS

CLEANING FILTERS
Regularly rinse and replace the filters to maintain your vacuum's suction power.
To prevent damage from cleaning chemicals, rinse filters with cold water only. Allow all filters
to air-dry for at least 24 hours before reinstalling them to prevent liquid from being drawn into
electric parts.
IMPORTANT: DO NOT use soap when cleaning the filters.
Foam Filter
Felt Filter
Post-Motor
Filter
REPLACING FILTERS
Follow the previous instructions for removing filters. The Pre-Motor foam and felt filters should be replaced
every 2.5 years. The Post-Motor Filter should be replaced every 3 years.
Replacement
Pre-Motor Foam &
Felt Filter Kit
XFF80
NOTE: To order replacement parts and filters, visit sharkaccessories.com.
Pre-Motor (foam and felt):
With the dust cup removed, take out the
Foam and Felt Filters.
CLEAN PRE-MOTOR FILTERS EVERY
3 MONTHS.
Post-Motor Filter:
To access the Post-Motor Filter, press the
tab, tilt the Filter Cover, and lift it away from
the vacuum. Remove the Post-Motor Filter.
CLEAN POST-MOTOR FILTER EVERY YEAR.
Replacement
Post-Motor Filter
XHF80
