Please be sure to read the enclosed Shark® Owner's Guide prior to using your unit.
QUICK START GUIDE
WHAT'S INSIDE
A
Vacuum Pod
Motorized Floor Nozzle
B
C
Handle Assembly
D
Flexible Hose
A
C
B
ASSEMBLY
(Click)
1
2
(Click)
(Click)
4
DLX
E
Extension Wand
Upholstery Tool
F
G
5.5" Crevice Tool
E
F
D
G
(Click)
(Screw)
(Click)
3
(Click)
(Wrap)
5
6
EMPTYING THE DUST CUP
Empty the dust cup after each use.
MAINTENANCE
Wash foam and felt filters
Foam
every 3 months and the
post-motor filter once a year
Felt
to keep the suction strong.
Rinse filters with water
only and allow to air-dry
Post-Motor
completely. Tap loose dirt
Filter
from filters as needed
between washes.
Cleaning the Brushroll
1 Detach the pod from
the floor nozzle.
2 Remove any blockages or buildup
from the airways in the nozzle.
Carefully cut away any fibers,
hair, or string wrapped around
the brushroll. Avoid damaging or
cutting the bristles.
