Shark Rotator Powered Lift-Away NV650 / 750 Series Manual

ASSEMBLY

Assembly - Step 1

  1. Insert Wand into Floor Nozzle.
  2. Insert Handle into wand.
  3. Place Pod onto wand and slide down to connect.
  4. Connect Hose into back of pod, until it clicks into place.

For proper operation, ensure all parts are firmly clicked into place.
Assembly - Step 2

WHOLE-HOME CLEANING

SETTINGS

Choose the appropriate setting.

Thick Carpet/Area Rug Cleaning
Set floor selector to Carpet.
Carpet/Low Pile Cleaning
Set floor selector to Carpet/Low Pile.
Hard Floor Cleaning
Set floor selector to Hard Floor.
NOTE: For deep cleaning per ASTM F 608 (embedded dirt in carpets) please set to Carpet/Low Pile.

BRUSHROLL INDICATOR LIGHT

WHAT DOES THE BRUSHROLL INDICATOR LIGHT MEAN?
Brushroll Indicator Light
Solid Green: The brushroll is spinning and working as it should.
Solid Red: There is a jam in the brushroll area. Turn your vacuum off and remove any blockages.
Flashing Red*: The motorized floor nozzle is overheating. Turn your vacuum off and wait for it to cool down.
No Light: The brushroll is off because the vacuum is in Hard Floor mode.
* See Troubleshooting section for further instructions.

CLEANING MODES

UPRIGHT
To engage brushroll, turn power on, select a surface setting, then place foot on floor nozzle and tilt handle back.
Cleaning Modes - Part 1 - Upright

LIFT-AWAY®
Press Lift-Away button to lift pod off motorized floor nozzle. You are now ready to clean those hard-to-reach places. Attach cleaning tools directly to the handle or to the wand for extended reach.
Cleaning Modes - Part 2 - LIFT-AWAY

ABOVE-FLOOR
Press the Handle button to detach the handle to clean above-floor areas or with attachments. Insert cleaning tools directly into wand or handle.
Cleaning Modes - Part 3 - Above-floor

ABOVE-FLOOR — EXTENDED REACH
Press the Wand Release button to detach the wand to clean with more reach. Insert cleaning tools directly into wand or handle.
Cleaning Modes - Part 4

AVAILABLE ACCESSORIES

  1. 11" Crevice Tool
    This slim tool is great for cleaning in tight spaces, between couch cushions, and in hard-to-reach areas.
  2. Upholstery Tool
    Perfect for large-particle pickup, dusting, and removing stubborn pet hair and lint from furniture and other upholstered surfaces.
  3. Dusting Brush
    This brush dusts and cleans delicate surfaces. Great for use on fans, blinds, lampshades, and keyboards.
  4. Duster Crevice Tool
    Two cleaning tools in one: the crevice tool gives you extended reach to clean in tight spaces, while the soft brush lets you dust delicate surfaces.
  5. Dust-Away™ Hard Floor Attachment
    Durable enough for cleaning big crumbs and debris but gentle enough for delicate dusting on hardwood and tile floors.
  6. Canister Caddy
    Transforms your Rotator into a canister ® vacuum, giving you the freedom to roll the pod along while keeping cleaning tools close by.

NOTE: Not all accessories come with all units. Please see the enclosed Quick Start Guide for your unit's configuration. To order additional accessories, visit sharkaccessories.com.

EMPTYING THE DUST CUP


Unplug the power cord before performing any maintenance.

Pull up on Dust Cup, release latch and lift dust cup off pod
Emptying The Dust Cup - Step 1

Press top dust cup release latch to access dust screen and remove built-up debris as necessary.
Emptying The Dust Cup - Step 2

Hold dust cup over a trash bin and press the empty-release latch on the bottom to empty dust and debris into trash.
Emptying The Dust Cup - Step 3

CLEANING AND REPLACING THE FILTERS

CLEANING FILTERS

Regularly clean and replace your filters to keep your vacuum's suction power optimal.
To clean filters, rinse with cold water ONLY to prevent damage from cleaning chemicals. Allow all filters to air-dry for at least 24 hours before reinstalling them to prevent liquid from being drawn into electric parts.

DO NOT use soap when cleaning the filters.

Pre-Motor (foam and felt):
With the dust cup removed, take out and rinse the foam and felt filters with water. Tap loose dirt off filters between washes as needed.

CLEAN PRE-MOTOR FILTERS EVERY 3 MONTHS.

Post-Motor (HEPA):
To access the HEPA Filter, pull the latch under the filter cover and take off the cover. Take out the HEPA filter and rinse it.
Cleaning Filters
CLEAN HEPA FILTER EVERY YEAR.

REPLACING FILTERS

Follow the previous instructions for removing filters. The pre-motor filters should be replaced every 2.5 years. The post-motor HEPA filter should be replaced every 3 years.
Replacement Pre-Motor Foam & Felt Filter Kit
XFF650
Replacement HEPA Filter
XHF650
NOTE: To order replacement parts and filters, visit sharkaccessories.com.

CHECKING FOR BLOCKAGES & MAINTAINING BRUSHROLL

Use the edge of a coin to open the 3 locks on the bottom of the floor nozzle.

With scissors, carefully cut along the groove in the brushroll to remove any debris, hair, or fibers.

Lift up the lid on the bottom of the nozzle to access the brushroll. Use a flashlight to check for blockages.

To reinstall the lid, line it up along the front of the nozzle and press it closed. Use the coin to close the 3 locks.

TROUBLESHOOTING

PROBLEM POSSIBLE REASONS & SOLUTIONS
Vacuum is not picking up dirt. No suction or light suction. Check filters to see if they need cleaning. Follow instructions for rinsing and drying the filters before reinstalling.
Dust cup may be full; empty dust cup.
Check hoses, hose connections, nozzle, and accessories for blockages; clear blockages if required.
Remove any string, carpet fibers, or hair that may be wrapped around the brushroll.
Vacuum lifts area rugs. Turn off unit to disengage the brushroll. Move switch to Hard Floor setting for suction-only cleaning, and turn unit back on.
Suction is powerful. Take care when vacuuming area rugs or rugs with delicately sewn edges.
Brushroll does not spin. If Brushroll Indicator Light on the motorized floor nozzle turns red, the brushroll has stopped spinning. Immediately turn off and unplug vacuum, disconnect the nozzle, and remove any blockages before reconnecting and turning vacuum back on.
With the power on, recline the handle, which will automatically turn on the brushroll.
Make sure the carpet height selector is NOT set to Hard Floor.
Vacuum turns off on its own, or indicator light flashes red. This vacuum is equipped with a motor-protective thermostat. If your vacuum overheats, the thermostat will automatically turn the suction motor off. Perform the following steps to restart the thermostat:
  1. Turn vacuum off and unplug it.
  2. Empty dust cup and clean filters.
  3. Check for blockages in hoses, accessories, and inlet openings.
  4. Allow unit to cool for a minimum of 45 minutes.
  5. Plug in vacuum and turn it on.
If hose is not fully connected to the pod, it can cause a poor electrical connection and the hose can come loose, turning the vacuum off.
  1. Turn vacuum off and unplug it.
  2. Empty dust cup and clean filters.
  3. Check for blockages in hose, accessories, and inlet openings.
  4. Remove cord from cord hook so hose latch can be seen and engaged.
  5. Make sure all parts are securely clicked into place at all connection points:
    1. Where hose meets back of pod (pull on hose to ensure latch is fully engaged)
    2. Where wand plugs into floor nozzle
    3. Where handle plugs into wand
  6. Plug in vacuum and turn it on.
Note: If vacuum still does not start, contact Customer Service at: 1-800-798-7398.

REGISTER YOUR PURCHASE
registeryourshark.com
Scan QR code using mobile device

Benefits of registering your product and creating an account:

  • Get easier, faster product support and access to warranty information
  • Access troubleshooting and product care instructions
  • Be among the first to know about exclusive product promotions

TIP: You can find the model and serial numbers on the QR code label on the bottom of the back of the vacuum body.

TECHNICAL SPECIFICATIONS

Voltage: 120V, 60Hz
Watts: 1150W
Amps: 9.5A

IMPORTANT SAFETY INSTRUCTIONS

FOR HOUSEHOLD USE ONLY
PLEASE READ CAREFULLY BEFORE USE
If the plug does not fit fully into the outlet, reverse the plug. If it still does not fit, contact a qualified electrician. DO NOT force into outlet or try to modify to fit.

To reduce the risk of fire, electric shock, injury, or property damage:

GENERAL WARNINGS

  1. Your vacuum cleaner may consist of a motorized nozzle, wand, hose, and/ or vacuum pod. This device contains electrical connections, electrical wiring, and moving parts that potentially present risk to the user.
  2. Use only identical replacement parts.
  3. Carefully observe and follow the instructions provided below to avoid improper use of the appliance. DO NOT use the vacuum for any purpose other than those described in this manual.
  4. Before use, carefully inspect all parts for any damage. DO NOT use if any parts are damaged.
  5. The use of an extension cord is NOT recommended.
  6. This vacuum cleaner contains no serviceable parts.

USE WARNINGS

  1. DO NOT allow the appliance to be used by children. Close supervision is necessary when used near children. This is not a toy.
  2. Always turn off the vacuum cleaner before connecting or disconnecting any motorized nozzles or other accessories.
  3. DO NOT handle plug or vacuum cleaner with wet hands.
  4. DO NOT use without filters in place.
  5. Only use Shark® branded filters and accessories. Failure to do so will also void the warranty.
  6. DO NOT damage the power cord:
    1. DO NOT pull or carry vacuum cleaner by the cord or use the cord as a handle.
    2. DO NOT unplug by pulling on cord. Grasp the plug, not the cord.
    3. DO NOT run the vacuum cleaner over the power cord, close a door on the cord, pull the cord around sharp corners, or leave the cord near heated surfaces.
  7. DO NOT put any objects into nozzle or accessory openings. DO NOT use with any opening blocked; keep free of dust, lint, hair, and anything that may reduce airflow.
  8. DO NOT use if nozzle or accessory airflow is restricted. If the air paths or the motorized floor nozzle become blocked, turn the vacuum cleaner off and unplug from electrical outlet. Remove all obstructions before you plug in and turn on the unit again.
  9. Keep nozzle and all vacuum openings away from hair, face, fingers, uncovered feet, or loose clothing.
  10. DO NOT use if vacuum cleaner is not working as it should, or has been dropped, damaged, left outdoors, or dropped into water.
  11. Use extra care when cleaning on stairs.
  12. DO NOT leave the vacuum cleaner unattended while plugged in.
  13. When powered on, keep the vacuum cleaner moving over the carpet surface at all times to avoid damaging the carpet fibers.
  14. DO NOT place vacuum cleaner on unstable surfaces such as chairs or tables.
  15. Your Shark® vacuum may not be designed to stand up on its own. When taking a break from cleaning, you may need to lean it against furniture or a wall, or lay it flat on the floor. Using the vacuum for an application where the unit lacks stability may result in personal injury.
  16. DO NOT use to pick up:
    1. Liquids
    2. Large objects
    3. Hard or sharp objects (glass, nails, screws, or coins)
    4. Large quantities of dust (drywall dust, fireplace ash, or embers). DO NOT use as an attachment to power tools for dust collection.
    5. Smoking or burning objects (hot coals, cigarette butts, or matches)
    6. Flammable or combustible materials (lighter fluid, gasoline, or kerosene)
    7. Toxic materials (chlorine bleach, ammonia, or drain cleaner)
  17. DO NOT use in the following areas:
    1. Poorly lit areas
    2. Wet or damp surfaces
    3. Outdoor areas
    4. Spaces that are enclosed and may contain explosive or toxic fumes or vapors (lighter fluid, gasoline, kerosene, paint, paint thinners, mothproofing substances, or flammable dust)
  18. Turn off all controls before plugging in or unplugging the vacuum.
  19. Unplug from electrical outlet when not in use and before any maintenance or cleaning.
  20. Hand wash with water only. Washing with cleaning chemicals could damage the unit.
  21. During cleaning or routine maintenance, DO NOT cut anything other than hair, fibers, or string wrapped around the brushroll.
  22. Allow all filters to air-dry completely before replacing in the vacuum to prevent liquid from being drawn into electric parts.
  23. Make sure the dust cup and all filters are in place after routine maintenance.
  24. If provided, secure the power cord around the two cord hooks during storage.

To reduce the risk of electric shock, this appliance has a polarized plug (one blade is wider than the other). This plug will fit in a polarized outlet only one way. If the plug does not fit fully in the outlet, reverse the plug. If it still does not fit, contact a qualified electrician to install the proper outlet. Do not change the plug in any way.

SharkNinja Operating LLC
US: Needham, MA 02494
CAN: Ville St-Laurent, QC H4S 1A7
1-800-798-7398
sharkclean.com
Illustrations may differ from actual product. We are constantly striving to improve our products; therefore the specifications contained herein are subject to change without notice.
For SharkNinja U.S. Patent information, visit www.sharkninja.com/uspatents

@sharkcleaning
