M-system EtherCAT R3-NECT1 Instruction Manual page 2

COMPONENT IDENTIFICATION
■ FRONT VIEW
RUN Indicator LED
ERR Indicator LED
RJ-45 Modular Jack for
EtherCAT Communication
■ STATUS INDICATOR LED
ID COLOR
RUN Green
ERR Red
L/A Green
Flickering 50 msec.-ON, 50 msec.-OFF
Blinking 200 msec.-ON, 200 msec.-OFF
Single Flash 200 msec.-ON, 1000 msec.-OFF
Double Flash 200 msec.-ON, 200 msec.-OFF, 200 msec.-ON, 1000 msec.-OFF
50 msec.
ON
Flickering
OFF
ON
200 msec.
Blinking
OFF
ON
200 msec.
Single Flash
OFF
ON
200 msec. 200 msec. 200 msec.
Double Flash
OFF
×10
Fixed Address Setting
Dev ID
×1
Rotary SW
CONFIG
USB Connector
L/A
for Configuration
L/A
1
4
2
5
3
6
FUNCTION STATUS
OFF
Blinking
Device State
Single Flash
ON
OFF
Blinking
Error Single Flash
Double Flash
ON
OFF
Port status Flickering
ON
200 msec.
1000 msec.
5-2-55, Minamitsumori, Nishinari-ku, Osaka 557-0063 JAPAN
Phone: +81(6)6659-8201 Fax: +81(6)6659-8510 E-mail: info@m-system.co.jp
■ SIDE VIEW
DESCRIPTION
Initialization
PRE-OPERATIONAL
SAFE-OPERATIONAL
OPERATIONAL
No error
Invalid Configuration
Unrequested Configuration
Application Watchdog Timeout
PDO Watchdog Timeout
LINK of Physical Layor is unestablished
Operationg after LINK is established
LINK of Physical Layor is established
1000 msec.
R3-NECT1
Function Setting
DIP SW
SW3
4
3
INPUT DATA
2
DUAL
1
COMMUNICATION
ON
EM-8274 P. 2 / 18
