MikroTik wAP 60G Series Quick Manual

EN - English - Quick Guide:
This device needs to be upgraded to RouterOS v6.49 or the latest stable version, to ensure compliance with local authority regulations!
It is the end user's responsibility to follow local country regulations, including operation within legal frequency channels, output power, cabling
requirements, and Dynamic Frequency Selection (DFS) requirements. All MikroTik radio devices must be installed according to instructions.
This "wAP 60G" series Quick Guide covers models: RBwAPG-60ad (wAP 60G), RBwAPG-60adkit (Wireless Wire), RBwAPG-60ad-SA (wAP 60Gx3
AP), RBwAPG-60ad-A (wAP 60G AP).
This is a wireless network device. You can find the product model name on the case label (ID).
Please visit the user manual page on
The most important technical specifications for this product can be found on the last page of this Quick Guide.
Technical specifications, brochures, and more info about products at
Configuration manual for software in your language with additional information can be found
If you need help with configuration, please seek a consultant
This Device accepts input of a 24V DC power adapter, which is provided in the original packaging of this device. This Device can also be powered using a PoE
injector (Provided in the packaging).
First steps:
Connect the device to the included PoE injector with Ethernet cable to the data+power end;
Connect the data end of the PoE injector into the computer;
Connect the power adapter to the PoE injector;
Download WinBox configuration tool
Default IP: 192.168.88.1, user name:
Set an IP address of your computer to 192.168.88.2;
In case the IP connection is not available, please use the Neighbors tab and connect through MAC address;
Once connected configure the device, so it has an active Internet connection
Upgrade the RouterOS software to the latest version
Choose your country, to apply country regulation settings;
Secure your device and set a strong password;
For more configuration information, please visit
wAP60G AP units come pre-configured with WISP Bridge default configuration;
Wireless Wire and wAP60G units come pre-configured with PTP Bridge default configuration;
Wireless Wire devices have already, randomly generated, matching SSID, and Wireless passwords.
Safety Information:
Before you work on any MikroTik equipment, be aware of the hazards involved with electrical circuitry, and be familiar with standard practices for preventing
accidents. The installer should be familiar with network structures, terms, and concepts.
Use only the power supply and accessories approved by the manufacturer, and which can be found in the original packaging of this product.
This equipment is to be installed by trained and qualified personnel, as per these installation instructions. The installer is responsible for making sure, that the
Installation of the equipment is compliant with local and national electrical codes. Do not attempt to disassemble, repair, or modify the device.
This product can be installed both indoors and outdoors. Please read the mounting instructions carefully before beginning installation. Failure to use the correct
hardware and configuration or to follow the correct procedures could result in a hazardous situation for people and damage to the system.
We cannot guarantee that no accidents or damage will occur due to the improper use of the device. Please use this product with care and operate at your own
risk!
In the case of device failure, please disconnect it from power. The fastest way to do so is by unplugging the power adapter from the power outlet.
This is a Class A product. In a domestic environment, this product might cause radio interference in which case the user might be required to take adequate
measures!
Exposure to Radio Frequency Radiation:
uncontrolled environment. This MikroTik device should be installed and operated no closer than 20 centimeters from your body, occupational user, or the general
public.
Manufacturer: Mikrotikls SIA, Brivibas gatve 214i Riga, Latvia, LV1039.
BG - Български. Бързо ръководство:
Това устройство трябва да бъде надстроено до RouterOS v6.49 или най-новата стабилна версия, за да се гарантира спазването на местните
наредби!
Крайните потребители са задължени да следват местните разпоредби, включително работа в рамките на законни честотни канали, изходна
мощност, изисквания за окабеляване и изисквания за динамичен избор на честота (DFS). Всички радиоустройства MikroTik трябва да бъдат
инсталирани съгласно инструкциите.
Това серия "wAP 60G" Бързо ръководство обхваща модели: RBwAPG-60ad (wAP 60G), RBwAPG-60adkit (Wireless Wire), RBwAPG-60ad-SA (wAP 60Gx3
AP), RBwAPG-60ad-A (wAP 60G AP).
Това е устройство за безжична мрежа. Можете да намерите името на модела на продукта на етикета на регистъра (ID).
https://mt.lv/um for the full up-to-date user manual. Or scan the QR code with your mobile phone.
https://mikrotik.com/consultants
https://mt.lv/winbox ;
admin and there is no password, for the paired models, please find the password on the sticker;
https://mt.lv/upgrade
https://wiki.mikrotik.com/wiki/Manual:Interface/W60G
This MikroTik equipment complies with the FCC, IC, and European Union radiation exposure limits set forth for an
https://mikrotik.com/products
at https://mt.lv/help
https://mt.lv/configuration
;
;
;
