M2 Series
Instruction Manual 9R000045-A

Units Select

The standard engineering units available on the Smart Manometer
are:
PSI
inH 0 (@20°C, 60°F and 4°C)
2
2
Kg/cm
kPa
mbars
Bars
cmH O (@ 20°C)
2
inHg (@ 0°C)
mmHg (@ 0°C)
User Units
Flow Units
To change the engineering units the manometer should be "ON"
and in Measure Mode. Then follow these steps:
Keystroke
1. Press the PRGM key. Top line reads "PROGRAM
MODE" and bottom line reads
"UNITS SELECT".
2. Press the PRGM key. Top line reads "UNITS
SELECT" and bottom line shows
current engineering units.
3. Press the up or down Engineering units on bottom line
arrow key until desired of display change.
engineering unit is
displayed.
4. Press the PRGM key to Top line reads "PROGRAM
select the engineering unit. MODE" and bottom line reads
"UNITS SELECT".
5. Press the down arrow Bottom line reads "EXIT".
key.
6. Press the PRGM key. Display returns to Measure Mode
in new engineering units.
www.meriam.com
page 6 of 31
APR2007
Display
