M2 Series
Instruction Manual 9R000045-A

User Info Select

The User Info Select registers are designed to provide the user with
information on the hardware and software in the manometer. This
register provides read only information on the sensor's serial
number, software version and date of manufacture. It also allows
the user to edit the Auto Shut-Off, Lockout and Start-Up Header
Name features.
To configure the User Info Select registers follow the steps shown
on the following page.
Keystroke
1. From the Measure Mode Top line reads "PROGRAM
press the PRGM key. MODE" and bottom line reads
"UNITS SELECT".
2. Press the up arrow key Bottom line changes to "USER
twice INFO SELECT".
3. Press the PRGM key. Bottom line shows serial
number.
4. Press the up arrow key. Software version number
shown.
5. Press the up arrow key. Manufacture date shown.
6. Press the up arrow key. Top line reads "AUTO SHUT
Instructions to set AUTO OFF" and bottom line reads
SHUT-OFF are in this "ENTER TO SELECT".
manual.
7. Press the up arrow key. Top line reads "LOCKOUT
Instructions for using CODE" and bottom line reads
LOCKOUT are on page 12. "ENTER TO SELECT".
8. Press the up arrow key. Top line reads "HEADER
Instructions for editing the NAME" and bottom line reads
Header are on page 13. "MERIAM". The cursor flashes
at bottom left.
9. Press the left arrow key Top line reads "PROGRAM
to go back to "USER INFO MODE" and bottom line reads
SELECT" screen. "USER INFO SELECT".
www.meriam.com
page 10 of 31
APR2007
Display
