MAD Fusion Chaise
Slat or Woven
(400)
1
PLEASE READ INSTRUCTIONS COMPLETELY BEFORE BEGINNING.
Carefully remove contents from box. Make sure that all parts and hardware
are included using the Parts List below.
Tools Required:
Base Assembly
Woven Seat Insert
Slat Frame Insert
WARRANTY QUESTIONS OR COMMENTS PLEASE CALL TOLL FREE AT 1-800-809-3114
Seaside Casual Furniture | 11 Industrial Drive Coventry, RI 02816 | 800-809-3114 | sales@seasidecasual.com
ASSEMBLY INSTRUCTIONS
4mm Allen Wrench (included); #2 Phillips Head Screwdriver; Rubber Mallet.
3/4" Phillips Pan Head Screw
Actual Size
Part Code: 316-8X3/4PTS
Back Slat Assembly
x 1
x 1
x 1
1/4" Flat Washer
Actual Size
x 33
x 4
316-1/4FW
Seat Slat Assembly
x 1
Base Trim
1-1/2" Phillips Pan Head Machine Screw
Actual Size
Part Code: 316-M5X40PPMS
x 1
x 2
x 4
Page 1
REV C
