HIP BENCH
411
412
1
PLEASE READ INSTRUCTIONS COMPLETELY BEFORE BEGINNING.
Carefully remove contents from box. Make sure that all parts and hardware are in-
cluded using the Parts List below.
Tools Required:
HAIRPIN LEG (411)
M6 SCREW
M6 SPLIT WASHER
Actual Size
x 12
WARRANTY QUESTIONS OR COMMENTS PLEASE CALL TOLL FREE AT 1-800-809-3114
Seaside Casual Furniture | 11 Industrial Drive Coventry, RI 02816 | 800-809-3114 | sales@seasidecasual.com
ASSEMBLY INSTRUCTIONS
4mm Allen Wrench (included); #2 Phillips Head Screwdriver;
(Recommended: Rubber Mallet; Power Drill)
TOP
Actual Size
M6 WASHER
Actual Size
x 1
x 4
x 12
3/4" PHILLIPS PAN HEAD SCREW
x 12
FRAME
ANCHOR LEG (412)
5mm ALLEN WRENCH
Actual Size
Actual Size
x 1
x 2
x 1
x 26
Page 1
