2.3.2 Additional package components
2
1
Power cable: Provides power to the Form Wash L.
1
Wi-Fi antenna: Allows the machine to connect to a network via Wi-Fi.
2
Non-reactive nitrile gloves: Wear gloves when handling liquid resin, resin-coated surfaces,
3
or solvent. Wash skin with plenty of soap and water
Rinse bottle: Remove resin trapped in cavities and internal channels of prints. Use clean
4
solvent. Formlabs recommends isopropyl alcohol.
Flush cutters: Snip to separate prints from their supports. Cut with the flat side on the
5
prints' surface for minimal support marks.
Scraper: Remove prints from the build platform. Do not use the scraper to clean the resin
6
tank interior.
Removal tool: Pry under the raft to remove prints from the build platform. Do not use the
7
removal tool to clean the resin tank interior.
Electric siphon pump: A battery-powered siphon pump for moving solvent into and out
8
of the wash bucket. The pump has a dedicated storage slot underneath the wash bucket.
2.4

User interface

For detailed guidance and visual assistance, visit support.formlabs.com.
The Form Wash L display is a touchscreen interface. The touchscreen displays wash information
(wash time and selected material), settings, and error messages. The touchscreen serves as
the user interface for the machine.
The home screen displays the current solvent, saturation rate, wash type and time, and
serial name.
The following screens and options are accessible via the home screen on the Form Wash
L display:
Settings
Solvent
Select Wash Solvent
Wash Preset
Start
5
3
4
• Connectivity
• Update Firmware
• Washing Guidelines
• Connect to Dashboard
• Current Solvent
• Saturation Rate
• IPA
• TPM
• Quick Wash
• 5 min
• Default Wash
• 10 min
• Start a wash cycle.
7
6
8
• Onboarding
• Machine Sound Volume
• Tilt Mode
• Reboot
• Number of Washes
• Replace Solvent
• Custom
• Long Wash
• 20 min
• Custom
• Guidelines
