Flexcom TK306 Installation And Operating Instructions Manual page 19

Flexcom Communication Ltd
General settings
Function Description
Factory default setting Reset the device to factory settings.
Change password Change the factory default password (123456).
Administrator phone number After setting the administrator phone number (s), the device only accepts calls and SMS commands from this number (s) and sends alerts to this phone number (s). Up to 5 such phone numbers can be set on the machine. After setting the first phone number, further ones can only be entered with SMS sent from this number.
Delete administrator phone number Delete a previously set administrator phone number.
Setting time zone The device default time zone is set to GMT + 0. This is changed (eg in the case of Hungary, the time zone is GMT + 1), as follows.
Query device status Querying the operating data and status of the device.
Query IMEI number Retrieve the IMEI of the device.
Redirect messages Forward third-party messages received on the device's SIM card to the administrator's phone (eg SMS received from the SIM card provider).
Switch between SMS / GPRS mode Switch between controlling your device via SMS or an Internet connection. The factory default mode is SMS.
Reduced GPRS mode By setting it, the device switches to reduced (economy) GPRS mode 5 minutes after the vehicle is stopped. It has switched to full operation again for an alarm or to start the vehicle.
Full GPRS mode Switch back from reduced GPRS mode.
Restart the device Restart the GPS and GSM modules of the device.
Query the position of the device
Description
Call the phone number of the device's SIM card from your
phone.
After receiving the call, the device cancels it and then sends the
data back in an SMS message: latitude and longitude, current
speed, time and link, which, when clicked / tapped, will display the
device's indicator on the Google map in our phone's browser.
If the device cannot connect to GPS satellites (eg inside a building
or in another shaded area), use the cell information of the GSM
transmission towers to determine its position (LBS, Location Based
Service). Its accuracy depends largely on the distance from the
towers and the mobile network coverage.
Automatic tracking
You can set your device to send position data continuously under certain conditions.
Any of the auto-tracking settings discussed below can result in a series of SMS messages
between the tracking device and the owner's phone - this can have significant cost
implications.
If you want to operate the device in this way, it is definitely recommended to use the
service provider's software tracking service, which provides these functions - regardless
of the frequency and amount of data transmissions - for a fixed monthly fee.
Function
Send position data at
specified intervals, in
specified quantities.
Description
The device sends position
messages every XXX
seconds until you cancel
the command. The value
of the quantity (YYY)
parameter can be up to
255.
Installation and operating instructions (2021/03/08)
SMS message
begin123456
password<old password> <new password>
For example: password123456 876543
The password must be a 6-digit Arabic number.
If you have subscribed to and use the reseller's software service, do not change the default factory password!
admin123456 phone number
For example: admin123456 0036709876543
Use to enter the phone number
country code prefix (eg 0036, Hungary).
noadmin123456 phone number
For example: noadmin123456 003612345678
timezone123456 value wher value: eg. +1, -2,
0 etc.).
For example: time zone123456 +1 (Hungarian time zone
setting)
check123456
imei123456
forwardi123456 <third party phone number>
GPRS123456
less gprs123456 on
less gprs123456 off
reset123456
Device response
SMS message
fixXXXsYYYn123456
For example: fix030s005n123456
19/28
Device
response
Begin Ok
Password OK
Admin Ok
Admin Ok
Time Ok
The device
communicates
via SMS the
external
power supply,
battery
voltage level,
the status of
GPS and GSM
connections,
etc.
The IMEI
number of the
device.
Forward Ok
GPRS Ok
Less gprs on
Ok
Less gprs off
Ok
Reset Ok
Device
response
Position
data
