  • Page 1 Gas-Pro All manuals and user guides at all-guides.com User & Operator Manual Gas-Pro Multi-gas monitor M07995/Eng Issue 11 Dec 2016...
  • Page 2 All manuals and user guides at all-guides.com NAVIGATION INSTRUCTIONS The symbols in the left-hand margin of each page of the manual will enable you to carry out the following functions: Contents Click on this button to display the Contents page. Click on this button to display the previous page.

  • Page 3: Table Of Contents

    1.2 Gas-Pro orientation ........
  • Page 4 2.6 Gas-Pro functions ........
  • Page 5 All manuals and user guides at all-guides.com 2.9 Tank Check Mode ......... . .34 2.9.1 Dual-Range Operation .
  • Page 6 All manuals and user guides at all-guides.com 8. Specification ......... 47 9.

  • Page 7: Prologue

    Gas-Pro is a portable monitor capable of detecting up to 5 gases in a compact and wearable design featuring an optional internal pump. Focused on users and fleet managers alike, Gas-Pro offers application focused solutions giving greater operating time and reduced set up time.

  • Page 8: Safety Information

    Safety Information • Gas-Pro is a hazardous area certified gas detector and as such must be operated and maintained in strict accordance with the instructions, warnings and label information included in this manual. Gas-Pro must be operated within the limitations stated.
  • Page 9 All manuals and user guides at all-guides.com • Gas-Pro may be used in Zones 1 and 2, for Group llA, llB and llC gases and vapours and for Temperature Classes T1, T2, T3 and T4. (see Certification labels below). •...
  • Page 10 All manuals and user guides at all-guides.com ATEX EN 60079-0: 2012 + A11: 2013 Explosive atmospheres – Part 0: Equipment - General requirements EN 60079-1:2007 Explosive atmospheres – Part 1: Equipment protection by flameproof enclosures “d” EN 60079-11: 2012 Explosive atmospheres - Part 11: Equipment protection by intrinsic safety “i” II 2 G Ex d ia IIC T4 Gb Tamb -20°C to +55°C DEMKO 11 ATEX 1031772X Gas detector use in hazardous locations Class 1 Division 1, Groups A, B, C and D only as to...

  • Page 11: Unpacking

    Should the unit be deep discharged, the charging indication will not be shown until the unit has been charging for 1 hour and the operator button has been pressed. When on and charging a warning will advise the user to turn the Gas-Pro off after 12 hours or remove from charge.

  • Page 12: Set-Up

    Before use, the Gas-Pro should always be checked for any signs of physical damage. Gas-Pro uses a Lithium Ion (Li-ion) battery pack and should arrive with sufficient charge to be used straight out the box. However, if this is the first time of use, you may need to charge the battery to...

  • Page 13: Charging

    Á À When off, to show the Gas-Pro is charging, both LEDs within the alarm bars will flash red and will change to green once fully charged. This state will continue until the trickle charge is complete. Charging will then terminate showing no indication.

  • Page 14: Fitting A Flow Plate

    A flow plate can be used for a number of applications including pumped operation (remote sampling), manual gas test/calibration or for manual sampling. If the pumped flow plate is attached before turning the Gas-Pro on and the Gas-Pro includes a pump, a pump test will commence as part of the start up process (see...

  • Page 15: Quick View

    All manuals and user guides at all-guides.com 1.5 Quick view Even when the detector is off, users can display details about the configuration of the Gas-Pro by momentarily pressing the operator button for one audible blip. The LED to the left of the display will...

  • Page 16: Operation

    2.2 Turn on In ‘clean air’, turn on the Gas-Pro by holding down the operator button for 3 audible blips. The Gas- Pro will warm up, going through a series of automatic processes as follows: Firstly a test screen pattern will be generated.
  • Page 17 All manuals and user guides at all-guides.com If the Gas-Pro is configured for regular Gas Testing (Bump Test), the date of the last Gas Test will also be shown (for more information on Gas Testing, see Gas testing and calibration page 37).
  • Page 18 The Autozero Confirm screen will be displayed next. Figure 11: Autozero confirm screen An Autozero should not be performed unless the Gas-Pro is in clean air. Press the operator button to enter the Autozero mode, otherwise the countdown will progress and will not perform a zero.
  • Page 19 When the autozero has finished or been skipped, the next screen is the home screen (Figure and displays the gas levels. The next screen on the Tank-Pro edition of Gas-Pro is the Tank Check screen. See the Tank Check Mode section (see Section 2.9...

  • Page 20: Pump Test

    If the Gas-Pro is configured for Bump functionality, the Bump/Pump prompt will be displayed if a flow plate is attached and a gas bump test is due or the Gas-Pro is placed in a Q-Test module during normal use (see...

  • Page 21: Detecting Gas

    2.4.1 Diffusion monitoring If you wish to monitor gases in ambient air for dangerous levels, the Gas-Pro can be worn by either clipping the strong alligator clip to clothing/overalls in the breathing zone or through the use of a chest harness.

  • Page 22: Pumped Mode

    33). Gas-Pro can either be worn or used with hoses and probes to sample from spaces prior to entry. The pump capacity in the Gas-Pro is 0.5l/m and will draw a sample of gas from 30m within 80 seconds. Please note the expected losses for some gases below. Please allow at least 3 seconds per meter of hose used.

  • Page 23: Manual Sampling

    1 minute is recommended to ensure a stable sample is read. If the Gas-Pro being used is fitted with a carbon monoxide sensor (CO) a 5% increase in reading is expected during this process due to the extra pressure placed on the sensor (ie if the sample being tested is 30ppm –...

  • Page 24: Alarms

    2.5.2 Instantaneous alarm The Gas-Pro will go into alarm immediately if the level of any of the gases it is configured to detect become outside acceptable limits. A minimum and maximum acceptable level is set for oxygen, for most other gases the Gas-Pro will go into alarm state 1 or 2 according to which level has been exceeded.

  • Page 25: Accepting And Clearing Alarms

    Alarm can be turned off only when gas has returned to acceptable levels has returned to acceptable levels While in alarm, the Gas-Pro will continue to record levels of all the gases being monitored. 2.5.5 Sensor types The Gas-Pro can be fitted with the following sensor types: •...

  • Page 26: Pellistor Sensors

    While in saver mode and the subsequent stabilise time, the gas level displayed on the LCD screen will indicate over range. If the alarm is so severe as to cause a sensor over-range the Gas-Pro should have a gas test to ensure no lasting damage has occurred.

  • Page 27: Pid

    Isobutylene by changing the correction factor in the PID sensor type options Details of how to change the VOC correction factor can be found in Portables Pro user manual Gas-Pro fitted with a PID sensor may require periodic cleaning and calibration of the sensor to ensure correct performance in normal use.

  • Page 28: Gas-Pro Functions

    When this icon is selected, the Home screen will be displayed. 2.6.3 Manual zero This function should only be carried out in ‘clean air’ and allows the Gas-Pro to be zeroed at any time. Certain operations will only take place if the Gas-Pro has been recently zeroed .

  • Page 29: Pre-Entry Check (Pec)

    This function is intended for sampling air of unknown quality before gaining access to it (e.g. going under ground through a manhole cover) thereby avoiding unnecessary exposure. The Gas-Pro (and any sampling probe) should be in a clean air when the PEC starts and finishes so the TWA accumulation should be insignificant.

  • Page 30: Carrying Out A Pre-Entry Check

    To confirm the end of the purge stage single click the operator button within the 10 seconds or the purge will continue. The Tank-Pro edition of Gas-Pro will not display %VOL readings while in PEC mode. See the Tank Check Mode section (see Section 2.9...

  • Page 31: Peak Review

    2.6.7.2 Pump setting This function, which is only present if the Gas-Pro has an internal pump, allows the user to turn the pump on or off. Double click the operator button to select the function. Single click the operator button to highlight...

  • Page 32: Shut Down

    All manuals and user guides at all-guides.com 2.7 Shut down To turn the Gas-Pro off, press and hold the operator button. A 4 second countdown will start. Hold the button down until the countdown has finished and the Gas-Pro will shut down. If you release the button before the countdown has finished, the Gas-Pro will resume operation.

  • Page 33: Data And Event Logging

    Threshold levels can be set using Portables Pro, extending log capabilities. The data log interval is set as part of the Gas-Pro configuration and can be adjusted using Portables Pro. Event logging records significant events occurring during Gas-Pro operation.

  • Page 34: Tank Check Mode

    All manuals and user guides at all-guides.com 2.9 Tank Check Mode Tank Check Mode is unique to devices with a Dual-Range Flammable IR sensor fitted, or ‘Tank-Pro’ branded devices. The device should under no circumstances be used as personal protection equipment whilst in Tank Check Mode.

  • Page 35: Dual-Range Operation

    All manuals and user guides at all-guides.com Tank Check Mode can be identified over the Home Screen as the text will be displayed in place of the current user name, the tank check icon will be displayed in the bottom-right corner, and the alarms disabled icon will be displayed to the left of the tank check icon.

  • Page 36: Confidence Tone

    All manuals and user guides at all-guides.com 2.9.2.4 Confidence Tone The Tank Check Mode confidence tone is different to other operational modes to give an audible indication of the operating mode. The Tank Check Mode confidence tone is four short ‘pips’ which are low pitch while in LEL range, and high pitch in VOL range.

  • Page 37: Gas Testing And Calibration

    Gas-Pro offers two types of bump test. A speedy bump test which is a gas test to the first alarm level and smart bump test, a gas test to a specified level of test gas.

  • Page 38: Bump Test Functionality

    Gas-Pro screen during start up. If Gas-Pro is turned off and on again within 24 hours of the gas test, the Gas-Pro will not inform the user of a need for a bump test. However on applying a magnetised flow plate, or placing Gas-Pro into the Q-Test the user will be given the option to complete a gas test (or proceed to pumped operation).

  • Page 39: Speedy Bump

    It is a fail if the detector does not go into alarm. 3.2.1.1 Procedure X Either place the Gas-Pro in a Q-Test module or attach a flow plate to the Gas-Pro. X Select Bump (see Bump/Pump functionality page 33).

  • Page 40: Calibration After Bump Fail

    All manuals and user guides at all-guides.com 3.2.3 Calibration after bump fail If any channel fails speedy bump or smart bump then Gas-Pro can be configured (via Portables Pro) to perform a ‘calibration after bump fail’ immediately after the test failure.

  • Page 41: Gas Test Screen Flow

    All manuals and user guides at all-guides.com 3.4 Gas test screen flow The following sequence of screen shots should be viewed with reference to the sections on ‘Speedy Bump’, ‘Smart Bump’ & ‘Calibration after bump fail‘. The screen shots show the general flow of the gas test functionality dependant upon the actual test and the decisions made.

  • Page 42: Icon Overview

    All manuals and user guides at all-guides.com 4. Icon overview The table below details the icons shown during regular operation as well as warning messages. This table is intended as a quick overview please refer to specific functional sections within this manual for further details.

  • Page 43: Service And Maintenance

    Ensure maintenance, service and calibration are carried out in accordance with the procedures in the manual and only by trained personnel. For further service or maintenance, contact your local Crowcon agent or regional office, for details reference the ‘Contacts’ section of the manual.

  • Page 44: Pc Interface And Portables Pro

    6.2 PC interface cable Portables Pro allows the download and viewing of data and event logs from the Gas-Pro using an interface cable via the USB socket on a laptop or desktop computer. Please see Portables Pro instructions for details.

  • Page 45: Accessories

    CH0103 USB communications lead (not powered) CH0104 USB communication and power lead CH0105 Gas-Pro charger cradle (no power) CH0106 Vehicle charging adaptor (use with CH0102) CH0107 5 Way multi-region power supply (Note: only for use with charging leads with serial numbers greater than Wxxxxx)
  • Page 46 All manuals and user guides at all-guides.com Part Number Description AC0301 1m reactive gas tubing (Tygothane® 3.2mm ID including tube insert) AC0303 3m reactive gas tubing (Tygothane® 3.2mm ID including tube insert) AC0512 Ball float probe AC0103 Calibration flow plate for PC Calibration (no magnet)

  • Page 47: Specification

    USB interface cable USB power & communications cable 5 Way multi-region power supply * Gases not available in Gas-Pro with the internal pump option are CL , CLO & O  Sensors may be degraded at the higher temperatures subject to individual sensor specifications ...

  • Page 48: Troubleshooting

    All manuals and user guides at all-guides.com 9. Troubleshooting 9.1 Pump test failure In the event of a pump test failure, check the following: • Ensure a pumped flow plate was used for the test • Remove the flow plate and check the gasket for damage (scratches, tears, etc.) •...

  • Page 49: Fault Descriptions

    All manuals and user guides at all-guides.com 9.2.1 Fault Descriptions Fault Symtom/Error Icon Cause Action codes Message 0 or 9 Instrument won’t Flat Battery. Recharge battery. switch on. No confidence Function disabled. Reconfigure with PC beep/flash. software. 26 - 30, Gas Reading with Zero drifted.
  • Page 50 Battery depleted. Recharge battery. empty battery symbol during startup. Switched on and Unit full and on charge Remove Gas-Pro from fully charged. for over 12 hrs. charge. Cannot switch off. Instrument configured Move to clean air then for “No switch off in switch off.

  • Page 51: Fault Codes

    All manuals and user guides at all-guides.com Fault Symtom/Error Icon Cause Action codes Message Bump Test Fail The monitor has not The monitor needs Lock. been gas tested in the calibration. defined period and the gas test lock function has been activated. Battery low Battery Low (about 20 Exit the hazardous area...

  • Page 52: Appendices

    All manuals and user guides at all-guides.com 10. Appendices 10.1 Sensors 10.1.1 Toxic Sensor part no Range CO/H SS0300 0-500/0-100PPM SS0306 0-100PPM SS0305 0-5PPM SS0308 0-1PPM SS0304 0-20PPM SS0309 0-1PPM SS0301 0-500PPM SS0301 0-2000PPM SS0302 0-2000PPM (H Filtered) SS0303 0-100PPM SS0310 0-100PPM SS0311...

  • Page 53: Flammable Pellistor Sensors

    Propane* SS0201 0-100% LEL Butane* SS0201 0-100% LEL * For Dual Range IR Gas-Pro & Tank Pro the same spare part number should be used as detailed above 10.1.4 Oxygen Sensor Part No. Range SS0500 0-25% VOL (2 years) SS0501 0-25% VOL (3 years) 10.1.5 IR...

  • Page 54: Sensor Limitations

    If unsure, contact Crowcon or your local agent. Use of high power radio transmitters in close proximity to the instrument may exceed RFI immunity levels and cause erroneous indications.

  • Page 55: Charging And Run Times

    Run time is equal to the expected operating time following a full charge/discharge cycle. Should the Gas-Pro completely discharge, charge within 3 days. This will maintain the internal clock. Gas-Pro in a fully charged state will last for 3 months from new.

  • Page 56: Contacts

    +65 6745 2936 Fax: +65 6745 0467 Email: sales@crowcon.com.sg Crowcon Detection Instruments Ltd (Beijing), Unit 316, Area 1, Tower B, Chuangxin Building, 12 Hongda North Road, Beijing Economic & Technological Development Area, Beijing, China 100176 Tel: +86 10 6787 0335...

  • Page 57: Warranty

    All manuals and user guides at all-guides.com Warranty This equipment leaves our factory fully tested and calibrated. If within the warranty period of two years from despatch, the equipment which includes pump, battery and common sensors (see sensor chart below) is proved to be defective by reason of faulty workmanship or material, we undertake at our option either to repair or replace it free of charge, subject to the conditions below.
  • Page 58 Crowcon spares for replacement parts (including sensors) or has been serviced or repaired by any party not authorised and certified by Crowcon to do so. The warranty does not cover misuse or abuse of the unit including use outside of specified limits.
  • Page 59 All manuals and user guides at all-guides.com Crowcon reserves the right to apply a handling and carriage charge whereby units returned as faulty, are found to require only normal calibration or servicing, which the customer then declines to proceed with.
