  • Page 1 Gas-Pro Tel: +44 (0)191 490 1547 Fax: +44 (0)191 477 5371 Email: northernsales@thorneandderrick.co.uk User & Operator Manual Website: www.heattracing.co.uk www.thorneanderrick.co.uk Gas-Pro Multi-gas monitor M07995/Eng Issue 6 November 2013...
  • Page 2 NAVIGATION INSTRUCTIONS The symbols in the left-hand margin of each page of the manual will enable you to carry out the following functions: Contents Click on this button to display the Contents page. Click on this button to display the previous page. Click on this button to display the next page.

  • Page 3: Table Of Contents

    1.2 Gas-Pro orientation ........
  • Page 4 2.6 Gas-Pro functions ........
  • Page 5 3. Gas testing and calibration ......34 3.1 Introduction ..........34 3.2 Bump Test Functionality .
  • Page 6 10.4 Crowcon contacts ........

  • Page 7: Prologue

    Gas-Pro is a portable monitor capable of detecting up to 5 gases in a compact and wearable design application focused solutions giving greater operating time and reduced set up time.

  • Page 8: Safety Information

    Understand the screen display and alarm warnings prior to use. • • the manual and only by trained personnel. • The Gas-Pro re-chargeable battery must only be charged in non-hazardous (safe) areas. • Only connect to Gas-Pro in a safe area for charging or communications. • greater than +40°C.
  • Page 9 • • • • Applicable Standards IECEx IEC 60079-0:2004 4th Edition Electrical apparatus for explosive gas atmospheres Part 0: General requirements IEC 60079-0:2007 5th Edition Explosive atmospheres – Part 0: Equipment - General requirements IEC 60079-1:2007 6th Edition IEC 60079-11:2006 5th Edition Ex d ia IIC T4 Gb Tamb -20°C to +55°C...
  • Page 10 ATEX: EN 60079-0:2006 Electrical apparatus for explosive gas atmospheres Part 0: General requirements EN 60079-0:2009 Explosive atmospheres – Part 0: Equipment - General requirements EN 60079-1:2007 EN 60079-11:2007 II 2 G Ex d ia IIC T4 Gb Tamb -20°C to +55°C intrinsic safety.

  • Page 11: Unpacking

    Should the unit be deep discharged, the charging indication will not be shown until the unit has been charging for 1 hour and the operator button has been pressed. When on and charging a warning will advise the user to turn the Gas-Pro off after 12 hours or remove from charge.

  • Page 12: Set-Up

    1.1 Prior to use attain the full operating time (see Charging page 13). page The actual operating time will depend on the types of sensor installed. 1.2 Gas-Pro orientation Figure 1: Gas-Pro D-ring Sounder Sensor apertures Charging cable Alarm bars Operator button +ve Safety™...

  • Page 13: Charging

    1.3 Charging into the charging socket on the Gas-Pro and turn on the mains supply (see Figure 2 below). If a charging The charger must be able to supply 6.5V@ 450mA with an output voltage that does not exceed 9.1V (Um).
  • Page 14 process (see Pump test page 20). pump and a non-magnetic version for PC calibration or for manual sampling. Although there is no Figure 4). The pumped symbol in the top left corner to aid recognition. Figure 4: PC Cal/Test Flow Plate Figure 5 and tighten the securing screw Figure 5:...

  • Page 15: Quick View

    1.5 Quick view Figure 6 below will be displayed for 10 seconds. Figure 6: Gas type and unit detected Battery status Quickview icon ID or serial number The +ve Safety™ LED status is also shown (see Figure...

  • Page 16: Operation

    2. Operation 2.1 General Before turning the Gas-Pro on, ensure it is in ‘clean air’ (i.e. outside, in normal air, away from any plant process or suspected gas location). This will allow the Gas-Pro to be zeroed using clean air as the base point. If the Gas-Pro is zeroed in contaminated air a false gas reading can result, or the zero could fail.
  • Page 17 34). Figure 8: Gas test due screen The next screen indicates when the Gas-Pro was last calibrated. It also indicates when the next calibration is due with a warning symbol Figure 9: If the calibration due lockout feature has been enabled the lockout icon will be displayed and the Gas-Pro will not proceed past this point.
  • Page 18 Figure 10: Current settings screen Figure 11: An Autozero should not be performed unless the Gas-Pro is in clean air. Press the operator button to If the operator button is not pressed the countdown will complete and this function will be skipped.
  • Page 19 Battery level Pump present (rotating when on) The Gas-Pro is now ready for use. From the 1st November 2010, EN60079-29 part 1 has been harmonised under the ATEX directive 94/9/EC. Therefore to comply with the ATEX directive, portable apparatus sensing...

  • Page 20: Pump Test

    2.3 Pump test page 12) will run a pump test during the start up process. A pump test will also be run whenever a a Q-Test module during normal use (see page 33). The pump test ensures accurate sealing as well as monitoring pump performance. The user will need to cover the pump inlet (see Figure 13...

  • Page 21: Detecting Gas

    2.4.1 Diffusion monitoring clipping the strong alligator clip to clothing/overalls in the breathing zone or through the use of a chest harness. icon. Figure 14: Gas-Pro indicators will also be red and highlight the gas in alarm.

  • Page 22: Pumped Mode

    33). Gas-Pro can either be worn or used with hoses and probes to sample from spaces prior to entry. The pump capacity in the Gas-Pro is 0.5l/m and will draw a sample of gas from 30m within 80 seconds. Please note the expected losses for some gases below. Please allow at least 3 seconds per meter of hose used.

  • Page 23: Manual Sampling

    2.4.3 Manual sampling If the internal pump option has not been chosen the hand aspirator may be used for pre-entry checks and remote sampling. This is not however recommended for sample hoses longer than 5 meters due to the amount of time (and therefore squeezes) it would take to get a repeatable sample to the 2.4.3.1 Using the Hand Aspirator and the user should accept this.

  • Page 24: Alarms

    20 minutes of battery life remaining. After 20 minutes the Gas-Pro will enter full power off without further warning unless charged. 2.5.2 Instantaneous alarm other gases the Gas-Pro will go into alarm state 1 or 2 according to which level has been exceeded. to indicate which level 2.5.3 Time weighted average alarm (TWA) information about gas levels detected.

  • Page 25: Accepting And Clearing Alarms

    Alarm can be turned off only when gas Alarm can be turned off only when gas has returned to acceptable levels has returned to acceptable levels While in alarm, the Gas-Pro will continue to record levels of all the gases being monitored. 2.5.5 Sensor types • Oxygen •...

  • Page 26: Pellistor Sensors

    2.5.5.5 Pellistor saver mode will indicate over range. If the alarm is so severe as to cause a sensor over-range the Gas-Pro should have a gas test to ensure no lasting damage has occurred. S or silicones.

  • Page 27: Pid

    The sensor becomes sensitive to humidity • The baseline is unstable or shifts when the sensor is moved • Sensitivity of the sensor has dropped Please refer to Crowcon application note PID-AN-001 for further details on maintenance and cleaning of the PID sensor.

  • Page 28: Gas-Pro Functions

    2.6.2 Home screen 2.6.3 Manual zero time. Certain operations will only take place if the Gas-Pro has been recently calibration after failing a gas test if the unit has been manually zeroed in the last 15 minutes. 2.6.4 Time weighted average This function allows the 8 hour TWA to be reviewed.

  • Page 29: Pre-Entry Check (Pec)

    The Gas-Pro (and any sampling probe) should be in a clean air when the PEC starts and If Gas-Pro is operated in pumped mode in combination with an exhaust pipe, a set of maximum tube).

  • Page 30: Carrying Out A Pre-Entry Check

    TWA calculations. The Gas-Pro will remain in the peak stage for a maximum of 5 minutes. When accessing the Peak Review screen the peak displayed will be the gas peak (trough for O ) seen in the selected time period;...

  • Page 31: Peak Review

    2.6.6 Peak review Select this option from the Menu Screen to see the highest level of each gas detected during the session. The menu offers the choice to display the peak gas level since the Gas-Pro was powered . The peaks are cleared when Gas-Pro is turned off.

  • Page 32: Shut Down

    2.7 Shut down 2.8 Additional Features 2.8.1 +ve Safety™ 2.8.1.1 +ve Safety™ indicator meanings Detector is operational but requires attention. One or more of the pre-set Red constant not be used. through the use of Portables-Pro and/or the I-Test.

  • Page 33: Data And Event Logging

    2.8.2 Data and event logging Events include: • • • • Fault • User Acknowledgements • • Pellistor saver • Time change/set • Alarm 1 • Alarm 2 • STWA • • Zero • Calibration • Zero (auto or manual) •...

  • Page 34: Gas Testing And Calibration

    Powered Q-Test allows gives a permanent home to monitors as it can be mounted in a vehicle and easily powered via a standard in-vehicle power socket. I-Test Flow Plate If Gas-Pro is operated in pumped mode in combination with an exhaust pipe, a set of maximum tube)

  • Page 35: Bump Test Functionality

    Figure 16: Gas test due screen Gas-Pro will not inform the user of a need for a gas test until the interval period from the last the Q-Test the user will be given the option to complete a gas test (or proceed to pumped operation).

  • Page 36: Speedy Bump

    3.2.1 Speedy bump Gas is presented across/over the sensor for a designated time (dependent on sensor gas type) during which alarm level one should be activated. It is a fail if the detector does not go into alarm. 3.2.1.1 Procedure Select Bump (see page 33 Attach the gas bottle and turn it on.

  • Page 37: Calibration After Bump Fail

    Wait for the calibration result screen indicated by the • The Gas-Pro then returns to normal operation. During this process the new calibration values are stored to the instrument memory and the not been through a formal service/calibration routine (dependant upon region/setting).
  • Page 38 and the decisions made. Figure 17: Bump/Pump Gas Groups Gas On Gas Off Pass One gas fail Fail If enabled & manual zero <15mins prior Calibration after bump fail Pass One gas fail Fail...

  • Page 39: Icon Overview

    4. Icon overview The table below details the icons shown during regular operation as well as warning messages. This for further details. Icon Description Icon Description functionality Time Date...

  • Page 40: Service And Maintenance

    5. Service and maintenance Gas-Pro is designed to require minimal service and maintenance. As with all electrochemical Ensure maintenance, service and calibration are carried out in accordance with the procedures in the manual and only by trained personnel.

  • Page 41: Pc Interface And Portables-Pro

    6.2 PC interface cable Portables-Pro allows the download and viewing of data and event logs from the Gas-Pro using an interface cable via the USB socket on a laptop or desktop computer. Please see Portables-Pro instructions for details.

  • Page 42: Accessories

    Charging lead CH0103 USB communications lead (not powered) CH0104 USB communication and power lead CH0105 Gas-Pro charger cradle (no power) CH0106 CH0107 5 Way multi-region power supply (Note: only for use with charging leads with serial numbers greater than Wxxxxx) CH0200...
  • Page 43 Part Number Description AC0301 1m reactive gas tubing (Tygothane® 3.2mm ID including tube insert) AC0303 3m reactive gas tubing (Tygothane® 3.2mm ID including tube insert) AC0512 AC0103...
  • Page 44 Detector type Multi-gas monitor Gases* Size (d x l x w) 43 x 130 x 84 mm (1.7 x 5.1 x 3.3 inches) Weight 5 gas (pump) 362g (12.7oz) 5 gas (un pumped) 333g (11.7oz) 4 gas (pump) 340g (11.9oz) 4 gas (un pumped) 309g (10.8oz) Alarms Audible>95dB...

  • Page 45: Troubleshooting

    9. Troubleshooting 9.1 Pump test failure • • • Run the test again and ensure the test is carried out in the required time If the pump still fails the test it may require servicing. 9.2 Fault screens A fault screen (see Figure 18 for an example) overwrites the normal screen.

  • Page 46: Fault Descriptions

    9.2.1 Fault Descriptions Fault Symtom/Error Icon Cause Action codes Message 0 or 9 Flat Battery. Recharge battery. switch on. Function disabled. software. Gas Reading with Zero drifted. Zero the instrument in 58 - 62 no gas present. clean air. Unstable/ Sensor failure.
  • Page 47 Display shows Battery depleted. Recharge battery. empty battery symbol during startup. Switched on and Unit full and on charge Remove Gas-Pro from fully charged. for over 12 hrs. charge. Cannot switch off. Move to clean air then switch off. alarm”.

  • Page 48: Fault Codes

    Fault Symtom/Error Icon Cause Action codes Message Bump Test Fail The monitor has not The monitor needs been gas tested in the calibration. gas test lock function has been activated. Battery low Exit the hazardous area to 30 minutes before as soon as possible and switch off) recharge battery.

  • Page 49: Appendices

    10. Appendices 10.1 Sensors 10.1.1 Toxic Crowcon Sensor part no Range CO/H SS0300 0-500/0-100PPM SS0306 0-100PPM SS0305 0-5PPM SS0308 0-1PPM SS0304 0-20PPM SS0309 0-1PPM SS0301 0-500PPM SS0301 0-2000PPM SS0302 0-2000PPM (H Filtered) SS0303 0-100PPM SS0310 0-100PPM SS0311 0-20PPM...

  • Page 50: Flammable Sensors

    10.1.2 Flammable Sensors Flammable sensors MUST only be used with the PCB P/N as detailed below in the ‘PCB P/N Suitability” Column. Failure to do so may impair intrinsic safety and invalidate safety Crowcon Sensor Part No. Range Crowcon PCB P/N Suitability...

  • Page 51: Sensor Limitations

    10.2 Sensor Limitations The instrument is not suitable for use in ambient temperatures above 55°C and electrochemical toxic collect on the sensors as this may impede gas diffusion. Use with care in wet or humid environments Persistent exposure to high levels of toxic gas can shorten the life of toxic sensors. Toxic sensors Use of high power radio transmitters in close proximity to the instrument may exceed RFI immunity reasonable distance from the instrument (e.g.

  • Page 52: Charging And Run Times

    Run Time (IR) 11 hrs Pumped 10 hrs (IR) 14 hrs Pumped 13 hrs Run time is equal to the expected operating time following a full charge/discharge cycle. Gas-Pro in a fully charged state will last for 3 months from new.

  • Page 53: Crowcon Contacts

    10.4 Crowcon contacts +44 (0) 1235 557700 sales@crowcon.com +1 800 527 6926 salesusa@crowcon.com +31 10 421 1232 eu@crowcon.com 2936 sales@crowcon.com.sg +86 10 6787 0335 saleschina@crowcon.com www.crowcon.com www.crowcon.us...

  • Page 54: Warranty

    Warranty This equipment leaves our factory fully tested and calibrated. If within the warranty period of two Battery Warranty All batteries degrade in performance over time and usage. For the purpose of this warranty it is considered that two years use equates to 500 full charge / discharge cycles (fully empty to full) and users should expect to see no greater than a 20% decline in run time after either this time or number Sensor Warranty Sensor...
  • Page 55 Instrument serial number(s). • Reason for return. Gas-Pro will not be accepted for warranty without a Crowcon Returns Number (CRN). It is essential that the address label is securely attached to the outer packaging of the returned goods. Warranty Disclaimer...
