Enable Connect to APs in
Remote Bridge List to connect
to the other APs in your list.
If you want to allow anonymous user to login your network, you can select Yes
in Allow anonymous ﬁeld. In this example, we do not allow anonymous users.
Enter the MAC address of
AP2, i.e. 000ea6a13f87.
Press Add button to add the
MAC address to your list.
Press Finish button.
Press Save & Start botton.
Then, we are to setup AP2.
Enter the web-based conﬁguration page on AP2.
Repeat step 1-2 to setup the same SSID with AP1.
Then select WAN & LAN page in IP Conﬁg folder.
Set the LAN IP address of
AP2 to 192.168.1.2.
Next, we are to disable the DHCP server function of
AP2 since AP1 is the only DHCP server in the wireless
LAN. Enter the DHCP Server page in IP Conﬁg folder.
Choose No to disable DHCP
Server and press Apply
Repeat step 5-10. Then enter the MAC address of AP1, i.e., 000ea6a13f6e.
Repeat step 11-12. After reboot, WDS would work.
WL-520g Wireless Router User Manual
