Huffy SPORTS AWLC6045 Owner's Manual

Portable basketball system with elevator
Hide thumbs Also See for SPORTS AWLC6045:

Advertisement

Quick Links

A Huffy Company
Portable Basketball System with Elevator
SAFETY INSTRUCTIONS
FAILURE TO FOLLOW THESE SAFETY INSTRUCTIONS MAY
RESULT IN SERIOUS INJURY, PROPERTY DAMAGE AND WILL
VOID WARRANTY.
Owner must ensure that all players know and
follow these rules for safe operation of the system.
To ensure safety, do not attempt to assemble this system without
following the instructions carefully. Proper and complete assembly,
use and supervision is essential for proper operation and to reduce
the risk of accident or injury. A high probability of serious injury
exists if this system is not installed, maintained, and operated
properly. Check entire box and inside all packing material for parts
and/or additional instructional material.
assembly, read the instructions and identify parts using the
hardware identifier and parts list in this document
• If using a ladder during assembly, use extreme caution.
• Two (2) people are recommended for this operation.
• Check base regularly for leakage. Slow leaks could cause system to
tip over unexpectedly.
• Seat the pole sections properly (if applicable). Failure to do so could
allow the pole sections to separate during play and/or transport of the
system.
• Climate, corrosion or misuse could result in system failure.
• Minimum operational height is 6' 6" (1.98 m) to the bottom of
backboard.
• This equipment is intended for home recreational use only and NOT
excessive competitive play.
• Read and understand the warning label affixed to pole. Label is
shown on page 1.
• The life of your basketball pole depends on many conditions. The
climate, placement of the pole, the location of the pole, exposure to
corrosives such as pesticides, herbicides or salts are all important.
• If technical assistance is required, contact Huffy Sports.
• Adult supervision is recommended when adjusting height.
Most injuries are caused by misuse and/or not following instructions.
Use caution when using this system.
For more information on assembly, placement, proper use and
maintenance, visit The American Basketball Council website at
http://www.smarthoops.com.
Toll-Free Customer Service Number for U.S: 1-800-558-5234, For Canada: 1-800-284-8339, For Europe: 00 800 855 85234 (Sweden: 009 555 85234),
All manuals and user guides at all-guides.com
Owner's Manual
Before beginning
.
REQUIRED TOOLS AND
MATERIALS:
• Two People
• Tape Measure
• Wood Board (Scrap)
• Wrenches: (One) 3/8", 5/16",
(Two) 7/16", 1/2", 9/16",
3/4", or Large and Small
Adjustable Wrenches
• Sawhorse or Support Table
• Step Ladder 8 ft. (2.4 m)
• Garden Hose or
Sand, 225 lb. (102 kg)
• Hammer
• Tape
• Phillips Screwdriver
• Safety Goggles
For Australia: 1-800-333 061 - Internet Address: http://www.huffysports.com
WRITE IN YOUR
___________
MODEL NUMBER:
IMPORTANT
In U.S. and Canada only:
Have questions?...don't go back to
the store!
We appreciate your purchasing one of our
many fine products. We are sure that you will
be very satisfied with your selection. Although
great care and effort have been taken,
occasionally problems may occur. To ensure
prompt and correct handling of any problems,
or to answer any questions, please contact our
Toll-Free Customer Service Number listed
below. Service will be quicker if you have
your Model Number (found on carton) and
assembly instructions ready when calling.
PLEASE WRITE YOUR MODEL NUMBER IN
THE SPACE PROVIDED ABOVE.
47
HEIGHT ADJUSTMENT
TO ADJUST BACKBOARD:
1
3
1. While holding handle, remove pin.
2. Move elevator up or down to
2
desired height.
3. Replace pin full length to lock
system at desired height.
2
MOVING SYSTEM
1. Adjust basketball backboard
1
height to lowest position.
2. Rotate handles forward until
wheels engage ground.
3. Move basketball system to
desired location.
4. Rotate handle back to original
2
3
position.
5. Reattach ground restraint and
check system for stability.
201253
2/99
Customer Service Center
N53 W24700 South Corporate Circle
Sussex, WI 53089
U.S.A.
WARNING
FAILURE TO FOLLOW THESE WARNINGS MAY RESULT
IN SERIOUS INJURY AND/OR PROPERTY DAMAGE.
Owner must ensure that all players know and follow
these rules for safe operation of the system.
• DO NOT HANG on the rim or any part of the system
including backboard, support braces or net.
• During play, especially when performing dunk type
activities, keep player's face away from the backboard, rim
and net. Serious injury could occur if teeth/face come in
contact with backboard, rim or net.
• Do not slide, climb, shake or play on base and/or pole.
• After assembly is complete, fill system completely with
water or sand and stake to the ground. Never leave system
in an upright position without filling base with weight, as
system may tip over causing injuries.
• When adjusting height or moving system, keep hands and
fingers away from moving parts.
• Do not allow children to move or adjust system.
• During play, do not wear jewelry (rings, watches, necklaces,
etc.). Objects may entangle in net.
• Surface beneath the base must be smooth and free of
gravel or other sharp objects. Punctures cause leakage and
could cause system to tip over.
• Keep organic material away from pole base. Grass, litter,
etc. could cause corrosion and/or deterioration.
• Check pole system for signs of corrosion (rust, pitting,
chipping) and repaint with exterior enamel paint. If rust has
penetrated through the steel anywhere, replace pole
immediately.
• Check system before each use for proper ballast, loose
hardware, excessive wear and signs corrosion and repair
before use.
• Check system before each use for instability.
• Do not use system during windy and/or severe weather
conditions; system may tip over. Place system in the
storage position and/or in an area protected from the wind
and free from personal property and/or overhead wires.
• Never play on damaged equipment.
• See instruction manual for proper installation and
maintenance.
• When moving system, use caution to keep mechanism from
shifting.
• Keep pole top covered with cap at all times.
• Do not allow water in tank to freeze. During sub-freezing
weather add non-toxic antifreeze, sand or empty tank
completely and store. (Do not use salt.)
• While moving system, Do not allow anyone to stand or sit
on base or have added ballasting on base.
• Do not leave system unsupervised or play on system when
wheels are engaged for moving.
• Use Caution when moving system across uneven surfaces.
System may tip over.
• Use extreme caution if placing system on sloped surface.
System may tip over more easily.
In the U.S.:1-800-558-5234 and Canada: 1-800-284-8339
201246
2/99

Advertisement

loading
Need help?

Need help?

Do you have a question about the SPORTS AWLC6045 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Huffy SPORTS AWLC6045

  • Page 1 Adjustable Wrenches • If technical assistance is required, contact Huffy Sports. • Keep pole top covered with cap at all times. • Sawhorse or Support Table 1. Adjust basketball backboard •...
  • Page 2 All manuals and user guides at all-guides.com HARDWARE IDENTIFIER (CONTINUED) Item #7 (1) Item #10 (3) Item #8 (1) Item #13 (10)* Item #12 (1) Item #16 (2) Item #15 (1) Item #14 (13)* Item #19 (1) Item #18 (2) Item #22 (4) HARDWARE IDENTIFIER (CONTINUED) * You may have extra parts with this model.
  • Page 3: Hardware Identifier

    All manuals and user guides at all-guides.com HARDWARE IDENTIFIER Item #31 (4) Item #30 (2) Item #32 (4) Item #33 (4) Item #37 (4) Item #34 (5) Item #43 (12) Item #39 (1) Item #38 (6) Item #36 (6) Item #50 (1) Item #54 (2) Item #57 (4) Item #55 (2)
  • Page 4 All manuals and user guides at all-guides.com INSTRUCTIONS NOTE: Assemble lanyard (27) to locking pin (28) as shown. IMPORTANT! WRITE MODEL NUMBER FROM BOX ONTO PAGE 1 19. Apply logo and height indicator labels (52) to adjustment rod (51) as OF THIS OWNERS MANUAL shown.
  • Page 5 All manuals and user guides at all-guides.com PARTS LIST - See Hardware Identifier Item Qty. Part No. Description Item Qty. Part No. Description 904847 Top Pole Section (Black) 904821 Elevator Tubes, Lower - Long 978482 Middle Pole Section (Black) 206304 Bolt, Hex Head, 1/2-13 x 6-5/16 Long 900284 Bottom Pole Section (Black)
  • Page 6 All manuals and user guides at all-guides.com IMPORTANT! WRITE MODEL NUMBER FROM BOX ONTO PAGE 1 OF THIS OWNERS MANUAL P/N 214949A 01/03...
  • Page 7 All manuals and user guides at all-guides.com IMPORTANT! WRITE MODEL NUMBER FROM BOX ONTO PAGE 1 OF THIS OWNERS MANUAL IMPORTANT! SEE TEXT PAGE Note (See Text Page) MIDDLE 5" (13 cm) WOOD SCRAP BOTTOM 5" (13 cm) IMPORTANT! (See Text Page) Note (See Text Page) WOOD SCRAP...
  • Page 8 All manuals and user guides at all-guides.com IMPORTANT! SEE TEXT PAGE IMPORTANT! SEE TEXT PAGE FRONT SIDE P/N 214949A 01/03...
  • Page 9 All manuals and user guides at all-guides.com IMPORTANT! (See Text Page) IMPORTANT! (See Text Page) Note (See Text Page) Note (See Text Page) 01/03 P/N 214949A...
  • Page 10: Elevator Installation

    All manuals and user guides at all-guides.com ELEVATOR INSTALLATION IMPORTANT! For spring loaded rim assembly, refer to instructions included with rim hardware. P/N 214949A 01/03...
  • Page 11 All manuals and user guides at all-guides.com IMPORTANT! SEE TEXT PAGE Note (See Text Page) WARNING (See Text Page) 01/03 P/N 214949A...
  • Page 12: Height Adjustment

    All manuals and user guides at all-guides.com HEIGHT ADJUSTMENT WARNING (See Text Page) NOTE: Peel protective film from surface of acrylic backboard prior to use. 10 ft. (3.05 m) P/N 214949A 01/03...
  • Page 13 All manuals and user guides at all-guides.com WARNING: Install net clips. Use of this product without proper installation of net clips, or when all net clips are not present could result in bodily harm. Be sure to follow directions carefully. CLIP “ARM”...
  • Page 14: Side View

    All manuals and user guides at all-guides.com NET INSTALLATION SIDE VIEW NETCLIP Insert net into bottom of clip as shown. SIDE VIEW Twist net until it snaps into position. Net must be centered through clip. NETCLIP P/N 214949A 01/03...
