88 5804 80
Lounge Chair
Important NOTE
Carefully remove all the parts from the carton and put
them individually on a soft cloth to prevent scratches
or other damage occurring to the parts.
We have taken great care in the design of this
product and request that you carefully and strictly
follow our assembly instructions to ensure a
completed product as it was designed.
Part List
A.
Seat Cushion
1 Pc.
B.
Back Cushion
1 Pc.
Hardware List
Key Wrench
1 Pc.
C.
Side Frame
1 Pc.
Spring Washer
Flat Washer
14 Pcs. (+1 extra)
14 Pcs. (+1 extra)
Home Styles Consumer Assistance: www.homestyles-furniture.com,
servicedesk@homestyles-furniture.com, 888-680-7460, 877-831-0319
D.
Side Frame
1 Pc.
E.
Stretcher
1 Pc.
Cap
14 Pcs. (+1 extra)
Tools recommended for assembly : Level
F.
Back Frame
1 Pc.
G.
Seat Frame
1 Pc.
M6x18
M6x30
Botl (short)
Botl (long)
6 Pcs. (+1 extra)
8 Pcs. (+1 extra)
Advertisement
Table of Contents
Related Manuals for Home Styles 88 5804 80
Summary of Contents for Home Styles 88 5804 80
- Page 1 Botl (short) Botl (long) 1 Pc. 14 Pcs. (+1 extra) 14 Pcs. (+1 extra) 14 Pcs. (+1 extra) 6 Pcs. (+1 extra) 8 Pcs. (+1 extra) Tools recommended for assembly : Level Home Styles Consumer Assistance: www.homestyles-furniture.com, servicedesk@homestyles-furniture.com, 888-680-7460, 877-831-0319...
- Page 2 Assembly Instructions 2 IMPORTANT * Please keep Key Wrench in a safe place as you may need to tighten up the Bolts in the future. * Do not tighten up all the bolts until each part is properly assembled. * Use a soft cloth between these parts and the fl oor. * After assembly item must be level to work properly.
- Page 3 Assembly Instructions 3 /3 STEP 3 Attach Side Frame (D) to unit with Flat Washers, Spring Washers, Bolts (long), Bolts (short) and Caps. Bolt (long) Bolt (short) Spring Washer Flat Washer Flat Washer Spring Washer STEP 4 Turn the unit to its’ upright position. Place Seat Cushion (A) and then Back Cushion (B) onto unit.
