Omntec Proteus Series System Programming Manual

Tank gauging system
Hide thumbs Also See for Proteus Series:
Table of Contents

Advertisement

Quick Links

Download this manual
SYSTEM PROGRAMMING
MANUAL
PART NO. OEL8000III-B, OEL8000III-K, & OEL8000III-X
SOFTWARE RELEASE 9.0 / 9.1
OMNTEC Mfg., Inc. | 2420 Pond Road | Ronkonkoma | NY 11779 | (631) 981-2001 | Email: omntec@omntec.com | www.omntec.com
PROTEUS
TANK GAUGING SYSTEM
OMNTEC Mfg., Inc. has been certified
by DQS Inc. to ISO 9001:2015
1. Open the camera app
2. Focus the camera on
the QR code by gently
tapping the code
3. Follow the instructions
on the screen to view
PDF file
Series
®
Revision 1.1
Document No. DOC00007 rev1.1
