Omntec PROTEUS Series System Operating Manual

Tank gauging system
Hide thumbs Also See for PROTEUS Series:
Table of Contents

Advertisement

Quick Links

OEL8000III-K | OEL8000III-X
SYSTEM OPERATING MANUAL
OMNTEC Mfg., Inc. | 2420 Pond Road | Ronkonkoma | NY 11779 | (631) 981-2001 | Email: OMNTEC@OMNTEC.com | www.OMNTEC.com
PROTEUS
TANK GAUGING SYSTEM
OMNTEC Mfg., Inc. has been certified
by DQS Inc. to ISO 9001:2015
1. Open the camera app
2. Focus the camera on
the QR code by gently
tapping the code
3. Follow the instructions
on the screen to view
PDF file
Series
®
GenIV
Revision 1.1
Document No. DI00009

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the PROTEUS Series and is the answer not in the manual?

Questions and answers

Related Manuals for Omntec PROTEUS Series

Summary of Contents for Omntec PROTEUS Series

  • Page 1 TANK GAUGING SYSTEM GenIV Revision 1.1 Document No. DI00009 OMNTEC Mfg., Inc. has been certified by DQS Inc. to ISO 9001:2015 OMNTEC Mfg., Inc. | 2420 Pond Road | Ronkonkoma | NY 11779 | (631) 981-2001 | Email: OMNTEC@OMNTEC.com | www.OMNTEC.com...

  • Page 2: Table Of Contents

    For PROTEUS® OEL8000III-X Installation Manual: Refer to document number DI00011 For PROTEUS® System Programming Manual: Refer to document number DOC00008 For PROTEUS® Thermal Paper Installation: Refer to document number DI00002 The above documents can be found at www.omntec.com/support/documents Document No.: DOC00009 _1.1.docx www.OMNTEC.com Revision Date: 8-7-2023...

  • Page 3: Main Menu

    • ALARMS Figure 1.2 • COMPLIANCE • SENSOR STATUS • UTILITIES. You can also acknowledge alarms, open the print menu, and perform a system test. (See Figure 1.2) Document No.: DOC00009 _1.1.docx www.OMNTEC.com Revision Date: 8-7-2023 Page 3 of 24...

  • Page 4: Inventory

    GROSS VOLUME and PERCENTAGE, GROSS HEIGHT, and ULLAGE. You can change the ullage percentage, between 80 - 100%, from within the SETUP MENU. (See Figure 2.3) Figure 2.3 Document No.: DOC00009 _1.1.docx www.OMNTEC.com Revision Date: 8-7-2023 Page 4 of 24...

  • Page 5: Reports

    SYSTEM TEST: Displays the current system test results without printing or checking relays. f) CITLD LOG: Displays CITLD (Continuous In-Tank Leak Detection) results for each tank. CITLD is only available with controllers that upgraded with an optional CITLD-enabled code. Document No.: DOC00009 _1.1.docx www.OMNTEC.com Revision Date: 8-7-2023 Page 5 of 24...

  • Page 6: Alarm Log

    STOP DATE drop down (˅) selection options for the selected tanks and sensors. c) SHOW LOGS: After pressing SHOW LOGS, the following screen will appear and show the alarm reports. (See Figure 3.1.2) Figure 3.1.2 Document No.: DOC00009 _1.1.docx www.OMNTEC.com Revision Date: 8-7-2023 Page 6 of 24...

  • Page 7: Delivery Log

    DATE drop down (˅) selection options for selected tanks. c) SHOW LOGS (yellow button): After pressing, the following screen will appear and show the logs for the selected tank. (See Figure 3.2.2) Figure 3.2.2 Document No.: DOC00009 _1.1.docx www.OMNTEC.com Page 7 of 24 Revision Date: 8-7-2023...

  • Page 8: Shift Log

    SHOW LOGS (yellow button): After pressing, the following screen will appear and show the logs for the selected tank. (See Figure 3.3.2) Figure 3.3.2 Document No.: DOC00009 _1.1.docx www.OMNTEC.com Revision Date: 8-7-2023 Page 8 of 24...

  • Page 9: Vld (Volumetric Leak Detection) Log

    DATE drop down (˅) selection options for selected tanks. SHOW LOGS (yellow button): After pressing, the following screen will appear and show logs for the selected tank. (See Figure 3.4.2) Figure 3.4.2 Document No.: DOC00009 _1.1.docx www.OMNTEC.com Revision Date: 8-7-2023 Page 9 of 24...

  • Page 10: System Test

    (See Figure 3.5.1) a) Use the UP and DOWN arrows to scroll through the completed test results. Figure 3.5.1 Document No.: DOC00009 _1.1.docx www.OMNTEC.com Revision Date: 8-7-2023 Page 10 of 24...

  • Page 11: Citld (Continuous In-Tank Leak Detection) Log

    (See Figure 3.6.2) Selecting a specific report will display more detailed information about each CITLD test. (See Figure 3.6.3) Figure 3.6.3 Document No.: DOC00009 _1.1.docx www.OMNTEC.com Revision Date: 8-7-2023 Page 11 of 24...

  • Page 12: Alarms

    Figure 4.2 The controller will also sound an audible horn. The ALARM ACK button will acknowledge the alarm and display the current alarms log. (Figure 4.3) Figure 4.3 Document No.: DOC00009 _1.1.docx www.OMNTEC.com Revision Date: 8-7-2023 Page 12 of 24...

  • Page 13: Compliance

    CITLD LOG: As described in Section 3.6, this will allow CITLD log selection. VLD LOG: As described in Section 3.4, this will allow VLD log selection. Figure 5.3 Document No.: DOC00009 _1.1.docx www.OMNTEC.com Revision Date: 8-7-2023 Page 13 of 24...

  • Page 14: Sensor Status

    (See Figure 5.3; previous page) TEMPERATURE SENSORS: Used to view temperature sensors (BX-TC-1) and their status. Also shows the actual temperature for each temperature sensor. (See Figure 6.2) Figure 6.2 Document No.: DOC00009 _1.1.docx www.OMNTEC.com Revision Date: 8-7-2023 Page 14 of 24...

  • Page 15: Utilities

    TIME & DATE: Used to set the current time and date. b) DIAGNOSTICS: Opens a diagnostic input screen, helpful for troubleshooting with OMNTEC Technical Support. c) HELP MENU: Offers wiring diagrams and helpful information about the controller. d) SYSTEM BOARDS: Shows the system boards and their status.

  • Page 16: Time & Date

    SETUP MENU (page 2). Press the SAVE button to save any changes made to this screen. Figure 7.1.2 Document No.: DOC00009 _1.1.docx www.OMNTEC.com Revision Date: 8-7-2023 Page 16 of 24...

  • Page 17: Help Menu

    Displays how to add and delete BX sensors from the system. It also gives a list of compatible sensors and where they would be placed in the tank field. (See Figure 7.2.3) Figure 7.2.3 Document No.: DOC00009 _1.1.docx www.OMNTEC.com Revision Date: 8-7-2023 Page 17 of 24...
  • Page 18 Displays the current settings for the COM1, OPTION BUS 1 and OPTION BUS 2, IP ADDRESS, TELNET PORT AND PROTOCOL and MODBUS ADDRESS. ( See Figure 7.2.6) Figure 7.2.6 Document No.: DOC00009 _1.1.docx www.OMNTEC.com Revision Date: 8-7-2023 Page 18 of 24...
  • Page 19 ( See Figure 7.2.8) Figure 7.2.8 Scrollable description detailing the probe and sensor functional tests that can be performed from the DIAGNOSTICS menu. (See Figure 7.2.9) Figure 7.2.9 Document No.: DOC00009 _1.1.docx www.OMNTEC.com Revision Date: 8-7-2023 Page 19 of 24...
  • Page 20 The Mini-Me can also connect to any industry-standard ATG. This is an optional remote and may be added after the initial installation. ( See Figure 7.2.12) Figure 7.2.12 Document No.: DOC00009 _1.1.docx www.OMNTEC.com Revision Date: 8-7-2023 Page 20 of 24...

  • Page 21: System Boards

    Boards you may find installed are: • MCU Figure 7.3.1 • XB-416 • XB-800 • XB-RB8 (PROTEUS® X; also listed for XC-R8 with a PROTEUS® K) • XB-4IO • XB-416DC • XB-800DC Document No.: DOC00009 _1.1.docx www.OMNTEC.com Revision Date: 8-7-2023 Page 21 of 24...

  • Page 22: Setup

    7.4 SETUP Used to enter the SETUP MENU. Accessed by OMNTEC Authorized Service Contractors (ASC), or if instructed by OMNTEC Technical Support. (See Figure 7.4.1) Figure 7.4.1 8. PRINT Brings up a submenu with different items to print. From here you...
  • Page 23 Tank/Sensor/Date Range selections (like Report options) before preparing the data for printout, which may require up to 6 minutes or more to complete. (See Figure 8.3) Figure 8.3 Document No.: DOC00009 _1.1.docx www.OMNTEC.com Revision Date: 8-7-2023 Page 23 of 24...

  • Page 24: Test

    Site Information, System ID, and date of the test. The user may keep these for their records. (See Figures 9.1, 9.2, and 9.3) Figure 9.2 Figure 9.3 Document No.: DOC00009 _1.1.docx www.OMNTEC.com Revision Date: 8-7-2023 Page 24 of 24...
