Omntec EMLLD PROTEUS OEL8000III-X Installation & Operation Manual
Vaporless electro-mechanical line leak detection
Hide thumbs
Also See for EMLLD PROTEUS OEL8000III-X:
- System programming manual (37 pages) ,
- Programming manual (26 pages) ,
- System operating manual (24 pages)
Table of Contents
Advertisement
Quick Links
EMLLD
INSTALLATION & OPERATION
MANUAL
OMNTEC® Mfg., Inc. | 2420 Pond Road | Ronkonkoma | NY 11779 | (631) 981-2001 | OMNTEC@OMNTEC.com | www.OMNTEC.com
ELECTRO-MECHANICAL
LINE LEAK DETECTION
PROTEUS
Revision 2501
OMNTEC® Mfg., Inc. has been certified
by DQS Inc. to ISO 9001:2015
1. Open the camera app
2. Focus the camera on
the QR code by gently
tapping the code
3. Follow the instructions
on the screen to view
PDF file
VAPORLESS
For use with
OEL8000III-X
®
Document No. 550001
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Omntec EMLLD PROTEUS OEL8000III-X
Summary of Contents for Omntec EMLLD PROTEUS OEL8000III-X
- Page 1 For use with OEL8000III-X PROTEUS ® Revision 2501 Document No. 550001 OMNTEC® Mfg., Inc. has been certified by DQS Inc. to ISO 9001:2015 OMNTEC® Mfg., Inc. | 2420 Pond Road | Ronkonkoma | NY 11779 | (631) 981-2001 | OMNTEC@OMNTEC.com | www.OMNTEC.com...
-
Page 2: Table Of Contents
INSTALLATION AND WIRING ................................4 MENU AND PROGRAMMING ................................7 SYSTEM BLOCK DIAGRAM ................................7 BX-EPS FIELD CONNECTIONS TO OMNTEC OEL8000III-X ........................ 8 OEL8000III-X INTERNAL WIRING FOR THE EMLLD SYSTEM ......................9 EMLLD WIRING GUIDE FOR THE OEL8000III-X (NON-IS) ......................... 9 OEL8000III-X BX-EPS SENSOR WIRING (IS) ............................ -
Page 3: Description
The EMLLD is a three-part system that includes the components listed below: VMI LD-2000 or LD-3000 MLLD mechanical leak detector(s) • BX-EPS – MLLD piston position sensor(s) • OMNTEC OEL8000III-X Controller w/ XB-HV Board installed • The EMLLD system includes the following features: Automatic fuel line re-pressurization •... -
Page 4: Installation And Wiring
E. BX-EPS SENSOR DETAILS & WIRING: REFER TO THE OEL8000III-X INSTALLATION MANUAL 1. All BX-EPS sensor wiring must enter the OMNTEC OEL8000III-X on the right side of enclosure (IS Section). 2. Low voltage intrinsically safe communications wiring connects to the terminal blocks located in the IS Section of the OEL8000III-X enclosure labeled sensor inputs. - Page 5 BX-EPS sensor(s) thread into the top of the MLLD, a minimum clearance of five inches is required on the top side of each MLLD to provide the necessary clearance needed for the proper installation of the BX-EPS sensor(s) onto the MLLD(s). Document No.: 550001 www.OMNTEC.com Page 5 of 19 Revision Date: 4-28-2025...
-
Page 6: Field Connections
FIELD CONNECTIONS Intrinsically-Safe Connections Non-Intrinsically-Safe Connections 4 Wire Cable (EC-4) to BX-EPS(s) (A, B, C, D, E) Sensors (F, G, H, I, J, K) Knockout for 3/4" conduit 11PL Power Document No.: 550001 www.OMNTEC.com Page 6 of 19 Revision Date: 4-28-2025... -
Page 7: Menu And Programming
Before proceeding with the Set-up and Programming of the OEL8000III-X - EMLLD System, ensure the circuit breakers for the pumps connected to this system are OFF. Preconfigured software may authorize pump(s) unexpectedly. SYSTEM BLOCK DIAGRAM OEL8000III-X Chassis Document No.: 550001 www.OMNTEC.com Page 7 of 19 Revision Date: 4-28-2024... -
Page 8: Bx-Eps Field Connections To Omntec Oel8000Iii-X
Only a qualified electrician familiar with the site should make the electrical connections outlined below. Please contact OMNTEC technical support if you have any questions or concerns regarding the proper field wiring of the EMLLD System. Note: The following pages outline the various wiring configurations available for the EMLLD System. These field connections are internal to the OMNTEC OEL8000III-X. -
Page 9: Oel8000Iii-X Internal Wiring For The Emlld System
3. Neutral Connection (Circuit Breaker Panel) 4. Authorization Input (Dispenser Hook Signal) Note: 120 VAC @ 60 Hz is the standard line power supplied to the OMNTEC OEL8000III-X. For additional power options, please consult OMNTEC technical support. EMLLD WIRING GUIDE FOR THE OEL8000III-X (NON-IS) -
Page 10: Oel8000Iii-X Bx-Eps Sensor Wiring (Is)
OEL8000III-X BX-EPS SENSOR WIRING (IS) Document No.: 550001 www.OMNTEC.com Page 10 of 19 Revision Date: 4-28-2024... -
Page 11: High Voltage Board
HIGH VOLTAGE BOARD A. HIGH VOLTAGE BOARD TO PUMP CONTROLLER IMPORTANT COMPLY WITH LOCAL ELECTRICAL CODES B. HIGH VOLTAGE BOARD TO PUMP CONTROL RELAY IMPORTANT COMPLY WITH LOCAL ELECTRICAL CODES Document No.: 550001 www.OMNTEC.com Page 11 of 19 Revision Date: 4-28-2025... -
Page 12: Calibration And Testing
The following procedure measures the resiliency for a single product line. If the site contains multiple products, this procedure must be repeated for each product. CAUTION Eye protection required during the calibration & testing process. Document No.: 550001 www.OMNTEC.com Page 12 of 19 Revision Date: 4-28-2025... -
Page 13: Power Off
PRESSURE STEP TEST position. 12. Note the volume of fuel collected. This volume is referred to as resiliency. Repeat the collection process several times to confirm the resiliency volume. Document No.: 550001 www.OMNTEC.com Page 13 of 19 Revision Date: 4-28-2025... - Page 14 Adjust the ORIFICE knob first, turn counterclockwise to increase flow and clockwise to decrease flow. Adjust the PRESSURE knob second, turn counterclockwise to reduce pressure and clockwise to increase pressure. Document No.: 550001 www.OMNTEC.com Page 14 of 19 Revision Date: 4-28-2025...
- Page 15 Step 8. This is the indication that the mechanical leak detector has properly transferred from its leak test position to its full flow position. Document No.: 550001 www.OMNTEC.com Page 15 of 19 Revision Date: 4-28-2025...
- Page 16 Turn on the power breaker. If necessary, press the RESET touchscreen icon on the OEL8000III-X to reset all active product channels. This completes the test procedure. The EMLLD system integration is now fully functional. Document No.: 550001 www.OMNTEC.com Page 16 of 19 Revision Date: 4-28-2025...
-
Page 17: Technical Specifications And Nrtl Approvals
2. There are no user serviceable parts contained within the OEL8000III-X enclosure. If the unit malfunctions, it must be returned to the manufacturer for diagnosis, repair, and/or replacement Document No.: 550001 www.OMNTEC.com Page 17 of 19 Revision Date: 4-28-2025... - Page 18 E. OMNTEC OEL8000III-X NRTL APPROVALS • UL508, 18 • UL913, 8 • UL60079-0, 7 • UL60079-11, 6 • CAN/CSA C22.2 No. 157-92, 2012 • CAN/CSA C22.2 No. 60079-0:19, 4 • CAN/CSA C22.2 No. 60079-11:14, 2 • CSA C22.2 No. 14, 13...
-
Page 19: Site Resiliency Recording
_____________________________________________________________________________________________________ _____________________________________________________________________________________________________ _____________________________________________________________________________________________________ _____________________________________________________________________________________________________ _____________________________________________________________________________________________________ _____________________________________________________________________________________________________ _____________________________________________________________________________________________________ _____________________________________________________________________________________________________ _____________________________________________________________________________________________________ Manufactured by: OMNTEC Manufacturing, Inc. 2420 Pond Road Ronkonkoma, NY 11779 Phone: +1 631-981-2001 Website: www.omntec.com VMI Manufacturing, LLC 8700 East Long Mesa Drive Prescott Valley, AZ 86314 Phone: +1 928-775-5191 Website: www.vaporless.com...
Need help?
Do you have a question about the EMLLD PROTEUS OEL8000III-X and is the answer not in the manual?
Questions and answers
