Greenwich Dining Chairs
601 Side Chair
602 Arm Chair
1
PLEASE READ INSTRUCTIONS COMPLETELY BEFORE BEGINNING.
Carefully remove contents from box. Make sure that all parts and hardware
are included using the Parts List below.
Tools Required:
Back Assembly
Long Front Apron
601
602
x 0
x 1
1-3/4" Phillips Head Screw
Actual Size
Part Code: 316-8X1-3/4PFDS
50mm Hex Lag
Part Code: 316-1/4-10-50HL
WARRANTY QUESTIONS OR COMMENTS PLEASE CALL TOLL FREE AT 1-800-809-3114
Seaside Casual Furniture | 11 Industrial Drive Coventry, RI 02816 | 800-809-3114 | sales@seasidecasual.com
ASSEMBLY INSTRUCTIONS
4mm Allen Wrench (included); #2 Phillips Head Screwdriver;
(Recommended: Rubber Mallet; High Powered Drill)
x 1
Short Rear Apron
601
x 2
Actual Size
Seat Assembly
x 1
5/8" TAPS
602
x 1
x 4
x 14
Left and Right Side Assemblies
Right
x 10
4mm Allen Wrench
Actual Size
Part Code: 4MMALLEN
Left
x 1ea
x 1
Page 1
601 & 602
