3.2.3.3 Terminal Overview of Enclosure Size H6

95
1
2 3
Illustration 3: Enclosure Size H6
1 Mains
2 Ground

3.2.3.4 Connecting to Mains and Compressor Terminals

• Tighten all terminals in accordance with the information provided in
• Keep the compressor cable as short as possible to reduce the noise level and leakage currents.
• Use a shielded/armored compressor cable to comply with the EMC emission specifications and connect this cable to both the
decoupling plate and the compressor. Also see
1. Connect the ground cable to the ground terminal, then connect the mains supply to terminals L1, L2, and L3.
16 | Danfoss A/S © 2021.06
99
4
3.2.5 EMC-compliant Electrical
3 Compressor
4 Relays
3.2.1.1 Fastener Torque Ratings.
Installation.
