CHAPTER 1.
PRODUCT SPECIFICATION

[1] SPECIFICATION

MODEL
Cooling Capacity BTU/h
Moisture Removal Pint/h
Electrical Data
Phase
Rated frequency Hz
Rated voltage V
Rated current A
Rated input W
Power factor %
EER BTU/Wh
Compressor
Type
Model, Motor Output
REFRIGERANT SYSTEM
Evaporator
Condenser
Control O.D. x I.D x Length(mm)
(Capillary Tube)
Refrigerant Volume R-22 (OZ)
(Factory Charge)
NET DIMENSIONS
Width Height Depth Inch (mm)
Net Weight Lbs
GROSS DIMENSIONS
Width Height Depth Inch (mm)
Gross Weight Lbs
FAN SYSTEM
Indoor side (Evaporator)
Outdoor side (Condenser)
Air Flow rate (Indoor side) CFM High
OTHERS
Safety devices
Air filter
Power cord length ft
Power plug type

[2] ELECTRICAL PARTS

Running capacitor 250V - 60μF
Fan capacitor (IN/OUT) 250V - 6μF / 250V - 8μF
Thermistor 10kΩ at 77°F (TH1), 4.431kΩ at 77°F (TH2, TH3)
Fan motor (IN) IBH-884-512 (MLB180)
Fan motor (OUT) PFU040ZREA/SHP (MLB178)
Overload relay MRA99239L-9054 or B380-150B-141E
Drain motor ORM-1524K1 (M-A438)
CV-P09LX
9000
2.5
Single
60
115
9.0
1010
98
8.9
(Hermetically sealed rotary type)
44R211AE-AJS (805W)
Louver fin, Grooved tube, 7mm, hair pin
Louver fin, Grooved tube, 7mm, hair pin
2.7 x 1.4 x 400
12.5
18.5" (470) x 32.3" (820) x 15.1" (383)
84
22.1" (561) x 35.8" (910) x 18.3" (465)
95
Centrifugal fan
Centrifugal fan
240
Med 190
Low 140
Compressor : Overload relay
Fan motor (IN/OUT) : Internal thermal fuse /
Internal thermal protector
Polypropylene net
4.6
NEMA 5-15P
CV-P09LX
Service Manual
CV-P10LC
9500
9.4
CV-P10LC
1 – 1
