This user's guide describes the operation of the evaluation module for the TAS5132
Digital Amplifier Power Output Stage using the TAS5086 Digital Audio PWM Processor
from Texas Instruments. The document also provides measurement data and design
information including the schematic, the bill of materials, and the PCB layout.
