Motortech MIC6 Quick Start Manual

Status-Bits EN
Product: P920380 - MIC6
Revision: 33493
Date: 2017-09-28 14:48:17
Distribution and release list (alphabetical)
Name
History of changes
Revision Date
33493 2017-09-28
32106 2017-05-30
27906 2016-06-09
27007 2016-04-15
27005 2016-04-14
26399 2016-02-25
25923 2015-12-17
25342 2015-10-30
24151 2015-07-06
19485 2014-03-12
Copyright  2014 Motortech GmbH
Author Knapwost, Carsten
Department <Department>
Signature
URL ( Revision ) svn://motdev01/development/projects/P920380/branches/mtu/900-Software/930-
Design/Status-Bits_EN.odt ( 33493 )
Creation Date 2013-05-30
Hogrevestr. 21 – 23  DE 29223 Celle  phone: +49-5141 9399-0  fax: +49-5141 9399-98
Company and Department
Changes
Changed the supply voltage limit for the status
bits (Warning:) Power Output Limit Exceeded
from 20 V to 17 V.
Changed temperature warning (110 °C) and
error (120 °C) thresholds.
Added Auxiliary Pickup Supply Voltage 2
Failure to General Status 2.
Added status bits regarding pickup redundancy
to General Status 2.
Added Testbed Operation to General Status 1. CK
Added GPO2 and GPO3 to General Status 1.
Added "Cylinder Individual Timing Limited" to
General Status 2.
Updated Temperature limits.
Updated overload limits.
Initial version (based on Status-Bits.odt)
