AG Neovo 17" Dental LCD Display DR-17 Specifications

17" DENTAL LCD DISPLAY
DR-17
FEATURES
Distinctive metal housing for added
strength
DC 24V medical-grade power adaptor
allows longer distance connection
A display handler* for easy display
movement
TM
NeoV Optical Glass
Swift 3 ms response time
High 3000:1 contrast ratio
DVI ready for high quality signal
S-Video and CVBS inputs
Auto-adjustment for optimal setting

Kensington security socket
VESA standard arm mount
SPECIFICATION
Panel Panel Type
Panel Size
Max. Resolution
Pixel Pitch
Brightness
Contrast Ratio
Viewing Angle (H/V) 160°/160° (Typical)
Display Color
Response Time
Panel Life Time
Frequency (H/V)
Max. Pixel Clock
Input Analogue
Digital
S-Video
CVBS
Power AC-DC Adaptor
Power
Consumption
TM
NeoV Thickness
Optical Glass Reflection Rate
Transmission Rate
Hardness
Plug & Play VESA
Operating Temperature
Condition Humidity
Storage Temperature
Condition Humidity
Mounting VESA FPMPMI
Tilt Tilt
Dimensions Product (W x H x D)
Packaging (W x H x
D)
Weight Product Weight
Packaging Weight
Regulation Certifications &
Approval Compliance
Accessories Supplied
Optional*
"＊" indicates an optional accessory
All specifications are subject to change without prior notice
The name AG Neovo is a trademark of Associated Industries China, Inc.
All other trademarks are the property of their respective owners.
TFT LCD
17.0" (432mm)
SXGA 1280 x 1024
0.264 mm
300 cd/m 2 (Typical)
3000:1 (DCR)
16.2 M
3 ms (GTG)
50,000 hrs (Minimum)
H: 30 kHz – 80 kHz
V: 56 Hz – 76 Hz
160 MHz
15-Pin D-Sub
24-Pin DVI-D
4-Pin Mini Din S-Video
CVBS Jack
External
AC 100 – 240 V, 50 – 60 Hz
<48 W (On)
<2 W (Stand-by)
<1 W (Off)
3.0 mm (0.18")
<1%
>96%
>6 H (MOH's Rating)
DDC 2B/DDC/CI
0 ℃~40 ℃
10% ~ 90%
-20 ℃~60 ℃
5% ~ 95%
Yes (100mm)
0° ~ +15°
408 x 398 x 175 mm
(16.1" x 15.7" x 6.9")
495 x 510 x 228 mm
(19.5" x 20.0" x 9.0")
6.8 kg (13.9 lbs)
9.5 kg (20.9 lbs)
FCC, UL/CUL, TUV/Baurt, CE,
BSMI, CB, ISO 13406-2,
Energy Star, GOST, WEEE,
RoHS, NOM
D-Sub cable, DVI cable,
warranty card, user manual, AC
power cord 1.8M, DC power
cord 5M, AC-DC-Adapter
Display handler, display base
www.agneovo.com
Copyright © 2008 AG Neovo. All rights reserved.
P/C: DR1700 Version 0.0, 20080530
