Thank you for purchasing our fine product!
WARNING
: Failure to follow these directions and warnings can result in serious injury
and/or product damage.
Assistance is required to assemble this ottoman.
!
Never stand on the ottoman or use it as a ladder.
!
Do not tip the ottoman when seated.
!
Periodically re-tighten all bolts and legs.
!
If any parts become missing, damaged or worn, discontinue use until they are replaced with identical parts.
!
Always seek assistance before moving furniture.
!
#6040O Healy Leather Tufted Ottoman
Assembly Instructions
This package contains all tools necessary for assembly.
Give us a chance to make it right
Contact our friendly, U.S. based customer service department with any
problems or comments. Replacements for missing or damaged parts
will be shipped promptly.
Toll Free: 866-528-8364
Monday - Friday, 8am-5pm, ET. After business hours, leave a message.
We will return your call the next business day.
#6040O Healy Leather Tufted Ottoman
Page 1
Advertisement
Table of Contents
Related Manuals for µ-Dimension Healy 6040O
Summary of Contents for µ-Dimension Healy 6040O
- Page 1 #6040O Healy Leather Tufted Ottoman Assembly Instructions Thank you for purchasing our fine product! This package contains all tools necessary for assembly. Give us a chance to make it right Contact our friendly, U.S. based customer service department with any problems or comments.
- Page 2 #6040O Healy Leather Tufted Ottoman Assembly Instructions PARTS LIST Part Part Name Qty. Part Part Name Qty. Drawing Drawing Top Cross Seat Cushion Bottom Cross Bolt with Washers Side Frame Allen Wrench Step 1 - Remove all parts from their packaging and confirm that the quantities match those listed above. If any parts are damaged or missing, please call our Customer Service Department at 1-866-528-8364.
- Page 3 #6040O Healy Leather Tufted Ottoman Assembly Instructions Step 2 - Place one of the Side Frames (Part C) on a flat surface with the connection tabs facing up. Align the top connection tabs on the Side Frame with the ends of the Top Cross Bars (Part A) like shown below.
- Page 4 #6040O Healy Leather Tufted Ottoman Assembly Instructions Step 4 - Place the Seat Cushion (Part D) on a flat surface with the bottom facing up like shown below. With help, turn the assembled frame upside down. Align the bolt holes in the tabs on the Side Frames and Top Cross Bars with the corresponding threaded inserts in the Seat Cushion.
